Shop Fox   |  SKU: W1812  |  Model: G0680
2 HP 7" Planer / Moulder with Stand
Price: $1,650.00
Recently Added ×
You May Also Like ×

Shop Fox G0680 - 2 HP 7" Planer / Moulder with Stand

click to zoom

    See this item in our 2016 Main Catalog!
    50 51 313
    Write a review
    SKU: W1812
    Model: G0680

    Showroom Availability

    Missouri In Stock
    Washington Temporarily Out of Stock
    Showroom Pickup
    This next generation Planer/Moulder features precision-ground cast-iron wings for increased work support, T-slots for easy guide rail adjustment, a one-piece enclosed stand, and a pedestal-mounted control switch with variable-speed feed motor for unsurpassed control over planing and moulding cutting results. Open-end design allows you to make curved mouldings with the optional elliptical jig. If you make your own mouldings and frames, you need this machine!

    Certified to UL & CSA standards!

    SPECIFICATIONS:

    • Motor: 2 HP, single-phase, 240V, 10.8A
    • Variable-speed feed motor: 1/8 HP
    • Power transfer: cutterhead is belt drive, feed rollers are chain drive
    • Cutterhead speed: 7000 RPM
    • Cuts per minute: 14,000
    • Cuts per inch: 64-300
    • Feed rate: 0-18 FPM
    • Max. profile depth: 3/4"
    • Max. profile width: 6-3/4"
    • Planing width: 7"
    • Min. stock length: 9"
    • Min. stock thickness: 1/4"
    • Max. stock thickness: 7-1/2"
    • Dust port: 4"
    • Footprint: 21" x 19"
    • Overall size: 36-1/4"L x 22"W x 34-1/2"H
    • Approximate shipping weight: 324 lbs.

    FEATURES:

    • Heavy-duty cast-iron handwheel and table
    • Precision-ground cast-iron infeed and outfeed extension wings
    • Dovetailed way for cutterhead housing with precision gib adjustments
    • Pedestal-mounted controls with variable-speed dial
    • Precision-ground cast-iron table and wings
    • Rubberized steel feed rollers
    • Powder-coated finish
    • One-piece base cabinet

    :

    :
