Enter the quantity next to the part you are ordering and press the "Add To Cart" button. If you cannot locate your part below, click on the appropriate diagram at the top of the page or contact our tech support department at techsupport@grizzly.com or 570-546-9663.


G0690 CABINET DIAGRAM


Ref # Part # Description Price Qty
1 P0690001 CABINET $543.50
2 PCAP88M CAP SCREW M10-1.25 X 25 $1.25
3 PLW06M LOCK WASHER 10MM $1.00
4 PW04M FLAT WASHER 10MM $1.00
5 P0690005 ANGLE SCALE $19.00
6 P0690006 STRAIN RELIEF $1.75
7 P0690007 CABINET PLATE $49.75
8 PS14M PHLP HD SCR M6-1 X 12 $1.00
9 PW03M FLAT WASHER 6MM $1.00
10 PLW03M LOCK WASHER 6MM $1.00
14 P0690014 MOTOR COVER $39.00
15 P0690015 KNOB M6-1 $6.00
18 P0690018 CLEANOUT DOOR $13.75
19 P0690019 DOOR LATCH $1.50
20 P0690020 KNOB M8-1.25 $7.00
21 PW01M FLAT WASHER 8MM $1.00
22 PLW04M LOCK WASHER 8MM $1.00
23 PN03M HEX NUT M8-1.25 $3.00
24 P0690024 DUST HOOD $3.75
25 PS05M PHLP HD SCR M5-.8 X 8 $1.00
26 P0690026 TABLE $606.00
27 P0690027 EXTENSION WING $258.00
28 PCAP13M CAP SCREW M8-1.25 X 30 $1.00
31 P0690031 STD TABLE INSERT $57.00
32 PSS53M SET SCREW M5-.8 X 12 $1.00
33 PS08M PHLP HD SCR M5-.8 X 12 $2.50
34 PS06M PHLP HD SCR M5-.8 X 20 $1.00
36 P0690036 DADO TABLE INSERT $44.50
40 P0690040 NAME PLATE RIVET $1.00
41 P0690041 SHIPPING BRACE $5.25
42 PB74M HEX BOLT M10-1.5 X 20 $1.00
45 PN02M HEX NUT M10-1.5 $1.00
46 P0690046 DUST CLIP $10.25
46-1 P0690046-1 UPPER BRUSH $5.50
46-2 P0690046-2 BRUSH LOWER $6.00
47 PS02M PHLP HD SCR M4-.7 X 12 $1.00
48 PW05M FLAT WASHER 4MM $1.00
49 PLW02M LOCK WASHER 4MM $1.00
50 P0690050 HOOK $1.00
51 PTLW13M INT TOOTH WASHER 6MM $1.00
52 P0690052 LIMIT PLATE $7.00
53 PN06M HEX NUT M5-.8 $1.00
56 P0690056 SWITCH BRACKET $24.25
63 P0690063 STRAIN RELIEF $1.75
64 P0690064 MOTOR CORD 14AWG X 3C $24.25
65 P0690065 POWER CORD 14AWG X 3C V1.01.09 $9.25
65V2 P0690065V2 POWER CORD W/PLUG V2.12.09 $20.75
66 P0690066 GREEN TRIM TAPE $13.25
68 PB02M HEX BOLT M6-1 X 12 $1.00
69 PBHS16M BUTTON HD CAP SCR M5-.8 X 16 $1.00
70 PLW01M LOCK WASHER 5MM $1.00
71 PW02M FLAT WASHER 5MM $1.00
72 P0690072 PUSH STICK $6.25
Ref # Part # Description Price Qty
