Amana T32920 Insert Carbide Mini Spoilboard Surfacing Rabbeting Slab Leveler 1/2" Shank Router Bit

Mini insert carbide spoilboard surfacing & rabbeting with scorer, great for cutting tight corners.

Features unique 2+2 insert knife design that contains two cutting flutes and two up-shear scorers, which provide a smoother finish at the bottom of the cut than traditional two-knife style router bits. Great for surface planing.

Also suitable for router sled machines. Make sure that your router sled is fully stable and squared.

Perfect for:

Resurfacing spoilboards using CNC

2+2 spoilboards contain two bottom scorers for better performance, finer surface finish and better clearance for 90° corners.

Planing large glued up panels using CNC

Surfacing and finishing wood using timber slab machines

Rabbeting or slotting

Designed for planing & rabbeting the following materials:

MDF

Fiberboard

HDF/LDF

Balsa Core

Epoxy (Epoxy Resins)

High Density Urethane (HDU Board)

Plastic/Acrylic

Plywood/Chipboard

Hardwood/Softwood

Ultra-High-Molecular-Weight Polyethylene (UHMWPE)*

* Use lower CNC spindle RPM and adjusted feed-rate to prevent Melting and adhesion of the acrylic material to the tool.

Featuring:

2+2 design

4-sided solid carbide insert knives

Exclusive carbide grade for highest quality of cut

Maximum cutting efficiency

Faster material removal process

Max RPM: 24,000

These industrial router bits feature solid carbide insert knives with four cutting edges that allow users to rotate the knife when one side becomes dull providing the highest-quality finish available on woodworking tools. See T33209 and T33210 for replacement carbide inserts for this router bit.
Recommendations: For surfacing solid woods it is recommended to remove both bottom scorers
