Parts for G0506 18" Heavy-Duty Bandsaw - 2 HP

IMPORTANT

Parts may have multiple versions that have changed over time. This will be indicated by V1, V2, V3, etc. in the parts description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 of a part went into use in January 2017. Please reference the manufacture date on the ID Label for your machine to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

1
FRAME
Item is no longer available
Price
N/A
2
HINGE
Item is no longer available
Price
N/A
3
WHEEL GUARD UPPER
4
WHEEL GUARD LOWER
5
CAP SCREW 1/4-20 X 3/8
Price
N/A
6
WHEEL GUARD LOCK KNOB
7
CAP SCREW 1/4-20 X 3/4
Price
N/A
8
Now: PN05
HEX NUT 1/4-20
Price
N/A
9
*DISCD*MOTOR 2HP 220V 1-PH
9-1
*DISCD*S CAPACITOR 400M 250V 2 X 3-1/2
9-2
FAN COVER
9-3
*DISCD*MOTOR FAN
10
Now: PK43M
KEY 8 X 8 X 45
Price
N/A
11
MOTOR PULLEY
12
Now: PSS08
SET SCREW 5/16-18 X 1/2
Price
N/A
13
MOTOR FLANGE
Item is no longer available
Price
N/A
14
Now: PB24
HEX BOLT 3/8-16 X 1-1/4
Price
N/A
15
Now: PN08
HEX NUT 3/8-16
Price
N/A
16
Now: PB24
HEX BOLT 3/8-16 X 1-1/4
Price
N/A
17
Now: PW02
FLAT WASHER 3/8
Price
N/A
18
Now: PLW04
LOCK WASHER 3/8
Price
N/A
19
Now: PN08
HEX NUT 3/8-16
Price
N/A
20
Now: PB60
HEX BOLT 3/8-16 X 3
Price
N/A
21
Now: PN08
HEX NUT 3/8-16
Price
N/A
23
Now: PVA37
V-BELT A37
Price
N/A
24
DUST BOARD
Item is no longer available
Price
N/A
25
WOOD BOARD
Item is no longer available
Price
N/A
26
Now: PB03
HEX BOLT 5/16-18 X 1
Price
N/A
27
Now: PW07
FLAT WASHER 5/16
Price
N/A
28
Now: PN02
HEX NUT 5/16-18
Price
N/A
29
Now: PS06
PHLP HD SCR 10-24 X 3/8
Price
N/A
30
CHIP CHUTE
Item is no longer available
Price
N/A
31
Now: PS06
PHLP HD SCR 10-24 X 3/8
Price
N/A
32
BLADE TENSION INDICATOR W/CABLE & SCREW
Item is no longer available
Price
N/A
32-1
INDICATOR CABLE
33
CAP SCREW 1/4-20 X 1/2
Price
N/A
34
WIRE BRACKET
35
Now: PS06
PHLP HD SCR 10-24 X 3/8
Price
N/A
36
Now: PB58
HEX BOLT 3/8-16 X 2
Price
N/A
37
Now: PN08
HEX NUT 3/8-16
Price
N/A
38
1-PH MAG SWITCH
Item is no longer available
Price
N/A
38-1
*DISCD*CONTACTOR/THERMAL OVRLD 220V NHD
39
*DISCD*ON SWITCH GREEN
40
*DISCD*OFF SWITCH RED
41
POWER CONTROL PANEL
Item is no longer available
Price
N/A
42
Now: PS06
PHLP HD SCR 10-24 X 3/8
Price
N/A
43
CONNECTION PLATE
Item is no longer available
Price
N/A
44
BRAKE LINING
45
Now: PB18
HEX BOLT 3/8-16 X 1
Price
N/A
46
Now: PB19
HEX BOLT 1/4-20 X 1/2
Price
N/A
47
FOOT BRAKE PEDAL
Item is no longer available
Price
N/A
48
Now: PLW04
LOCK WASHER 3/8
Price
N/A
49
Now: PN08
HEX NUT 3/8-16
Price
N/A
50
SPRING HELICAL 110MM
Item is no longer available
Price
N/A
51
Now: PN08
HEX NUT 3/8-16
Price
N/A
52
Now: PB21
HEX BOLT 3/8-16 X 3/4
Price
N/A
53
*DISCD*STOP SWITCH
54
CAP SCREW M4-.7 X 30
Price
N/A
55
WHEEL UPPER
Item is no longer available
Price
N/A
56
WHEEL SHAFT UPPER
57
BALL BEARING 6205ZZ
Price
N/A
58
*DISCD*IN BUSHING
Item is no longer available
Price
N/A
59
*DISCD*OUT BUSHING
Item is no longer available
Price
N/A
60
Now: PR26M
INT RETAINING RING 52MM
Price
N/A
61
LOWER WHEEL FLAT WASHER 10MM
62
Now: PB03
HEX BOLT 5/16-18 X 1
Price
N/A
63
*DISCD*RUBBER CROWN
64
*DISCD*WHEEL LOWER
65
WHEEL SHAFT LOWER
66
BRUSH BRACKET
Item is no longer available
Price
N/A
67
BRUSH
Item is no longer available
Price
N/A
68
Now: PB03
HEX BOLT 5/16-18 X 1
Price
N/A
69
Now: PW07
FLAT WASHER 5/16
Price
N/A
70
Now: PN02
HEX NUT 5/16-18
Price
N/A
71
LOWER WHEEL SHAFT WASHER 3/8-2"
72
Now: PB24
HEX BOLT 3/8-16 X 1-1/4
Price
N/A
73
Now: PB24
HEX BOLT 3/8-16 X 1-1/4
Price
N/A
74
Now: PN08
HEX NUT 3/8-16
Price
N/A
75
ARBOR BRACKET
76
Now: PB24
HEX BOLT 3/8-16 X 1-1/4
Price
N/A
77
Now: PN08
HEX NUT 3/8-16
Price
N/A
78
BLADE TENSION SHAFT
79
THRUST BEARING 51104
Price
N/A
82
INDICATOR WIRE PULLER
83
SPRING HELICAL 50MM
84
BRACKET HOLDER
85
Now: PN08
HEX NUT 3/8-16
Price
N/A
86
Now: PW02
FLAT WASHER 3/8
Price
N/A
87
BRACKET SHAFT
88
Now: PN08
HEX NUT 3/8-16
Price
N/A
89
TENSION HANDWHEEL
90
Now: PSS08
SET SCREW 5/16-18 X 1/2
Price
N/A
91
*DISCD*TABLE
Item is no longer available
Price
N/A
92
*DISCD*FENCE RAIL
Item is no longer available
Price
N/A
93
Now: PB18
HEX BOLT 3/8-16 X 1
Price
N/A
94
Now: PW02
FLAT WASHER 3/8
Price
N/A
95
*DISCD*FENCE
96
*DISCD*FENCE KNOB 3/8"-16 X 1-1/4"
97
*DISCD*TRUNNION W/BRACKET
98
CAP SCREW 3/8-16 X 1-1/4
Price
N/A
99
Now: PLW04
LOCK WASHER 3/8
Price
N/A
100
HEX BOLT 1/2-12 X 1-3/4
101
Now: PW01
FLAT WASHER 1/2
Price
N/A
102
TRUNNION BRACKET
Item is no longer available
Price
N/A
103
HEX BOLT 1/2-12 X 1-3/4
Price
N/A
104
Now: PLW07
LOCK WASHER 1/2
Price
N/A
105
BLADE GUIDE FORK
Item is no longer available
Price
N/A
106
Now: PB07
HEX BOLT 5/16-18 X 3/4
Price
N/A
107
Now: PW02
FLAT WASHER 3/8
Price
N/A
108
*DISCD*SHAFT CUP
Item is no longer available
Price
N/A
109
Now: PB03
HEX BOLT 5/16-18 X 1
Price
N/A
110
Now: PLW01
LOCK WASHER 5/16
Price
N/A
111
*DISCD*LOCK KNOB 3/8-16 X 2-1/4"
112
GUIDE SHAFT
113
C-CLIP
114
ELEVATION GEAR SHAFT
115
*DISCD*GEAR SHAFT BASE
116
Now: PB03
HEX BOLT 5/16-18 X 1
Price
N/A
117
Now: PLW01
LOCK WASHER 5/16
Price
N/A
118
*DISCD*HANDWHEEL
119
*DISCD*SPRING KEY M4 X 40
120
*DISCD*TRACK KNOB 1/2 - 12 X 2-1/2
121
Now: PN08
HEX NUT 3/8-16
Price
N/A
122
BLADE GUIDE GUARD
123
BLADE GUARD BRACKET
124
Now: PB19
HEX BOLT 1/4-20 X 1/2
Price
N/A
125
Now: PLW02
LOCK WASHER 1/4
Price
N/A
126
Now: PW06
FLAT WASHER 1/4
Price
N/A
127
*DISCD*BLADE GUIDE HOLDER
Item is no longer available
Price
N/A
128
Now: PB03
HEX BOLT 5/16-18 X 1
Price
N/A
129
Now: PW07
FLAT WASHER 5/16
Price
N/A
130
Now: PB07
HEX BOLT 5/16-18 X 3/4
Price
N/A
131
*DISCD*ADJUSTMENT BRACKET
132
*DISCD*BRACKET ARBOR
133
*DISCD*BLADE GUIDE BASE
Item is no longer available
Price
N/A
134
CAP SCREW 5/16-18 X 3/4
Price
N/A
135
*DISCD*GUIDE WHEEL BRACKET
Item is no longer available
Price
N/A
136
*DISCD*GUIDE WHEEL
Price
N/A
137
*DISCD*GUIDE WHEEL NUT 7/8-14
Price
N/A
138
BALL BEARING 6202ZZ
Price
N/A
140
MITER GAUGE BODY
Item is no longer available
Price
N/A
140A
*DISCD*COMPLETE MITER GAUGE
141
T-SLOT WASHER 13MM
Item is no longer available
Price
N/A
142
Now: PFH09
FLAT HD SCR 1/4-20 X 5/16
Price
N/A
143
MITER BAR
Item is no longer available
Price
N/A
144
MITER GAUGE BOLT 1/4-20 X 7/16
Item is no longer available
Price
N/A
145
STOP PIN
Item is no longer available
Price
N/A
146
BLOCK
Item is no longer available
Price
N/A
147
*DISCD*INDICATOR
148
Now: PS29
PHLP HD SCR 6-32 X 5/8
Price
N/A
149
Now: PS06
PHLP HD SCR 10-24 X 3/8
Price
N/A
150
HANDLE 5/16-18 X 1-1/2
Item is no longer available
Price
N/A
151
Now: PW07
FLAT WASHER 5/16
Price
N/A
152
Now: PN12
HEX NUT 6-32
Price
N/A
160
Now: G8589
Nameplate - Large
Price
N/A
161
TAP SCREW M4 X 11
Price
N/A
162
MACHINE ID LABEL
Item is no longer available
Price
N/A
163
ELECTRICITY 1.4W X 1.2H
Price
N/A
164
UNPLUG BANDSAW 2W X 3.3H
Price
N/A
165
***USE PLABEL-19A***
Price
N/A
166
DONT OPEN 2W X 3.3H
Price
N/A
167
READ MANUAL 2W X 3.3H V2.07.05
Price
N/A
168
SAFETY GLASSES 2W X 3.3H V2.04.08
Price
N/A
169
BS MOVING/ADJUST 2W X 3.3H
Price
N/A
174
*DISCD*THRUST BEARING SHAFT
175
BALL BEARING 6202RS
Price
N/A
176
E-CLIP 15MM
Price
N/A
177
CABLE CLIP
178
CABLE NUT 6-32
179
Now: PS37
PHLP HD SCR 6-32 X 5/16
Price
N/A
180
Now: PS06
PHLP HD SCR 10-24 X 3/8
Price
N/A
181
TERMINAL BLOCK
181A
JUNCTION BOX ASSEMBLY
Item is no longer available
Price
N/A
182
TERMINAL BLOCK
Price
N/A
183
TERMINAL BLOCK
Price
N/A
184
TERMINAL BLOCK
Price
N/A
185
TERMINAL BLOCK
Price
N/A
186
TERMINAL BLOCK
Price
N/A
188
TAP SCREW 10-24 X 1/2
Price
N/A
189
MOTOR POWER CORD
189A
CONTROL PANEL POWER CORD
Item is no longer available
Price
N/A
190
HARDWARE BAG
Item is no longer available
Price
N/A
3X038A-3
THERMAL OVERLOAD RELAY SHIHL 220V 1PH 60
Price
N/A
MANUAL
MANUAL FOR G0506 12/03
