Parts for G0517 6" x 16" Mill/Drill with Stand

IMPORTANT

Parts may have multiple versions that have changed over time. This will be indicated by V1, V2, V3, etc. in the parts description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 of a part went into use in January 2017. Please reference the manufacture date on the ID Label for your machine to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

1
*DISCD*BASE
2
*DISCD*DOOR
Item is no longer available
Price
N/A
3
*DISCD*HINGE
4
CAP SCREW M6-1 X 20
Price
N/A
5
*DISCD*OIL PLATE
6
*DISCD*BASE
Item is no longer available
Price
N/A
7
*DISCD*SCREW M12 X 40
Item is no longer available
Price
N/A
8
*DISCD*SADDLE
Item is no longer available
Price
N/A
9
*DISCD*NUT TR20 X 4-9H
Item is no longer available
Price
N/A
10
Now: PW01M
FLAT WASHER 8MM
Price
N/A
11
Now: PS16M
PHLP HD SCR M8-1.25 X 16
Price
N/A
12
*DISCD*NUT TR20 X 4-9H
Item is no longer available
Price
N/A
13
*DISCD*TABLE
Item is no longer available
Price
N/A
14
*DISCD*BEVEL IRON LONG
Item is no longer available
Price
N/A
15
*DISCD*ADJUST SCREW M8-69
Price
N/A
16
*DISCD*LONGITUDINAL LEADSCREW
Item is no longer available
Price
N/A
17
*DISCD*SUPPORT
Item is no longer available
Price
N/A
18
Now: PB83M
HEX BOLT M6-1 X 16
Price
N/A
19
THRUST BEARING 51102
Price
N/A
20
*DISCD*SCALE RING
Item is no longer available
Price
N/A
20-1
*DISCD*THUMB SCREW M6 X 10
21
*DISCD*HANDLE WHEEL
Item is no longer available
Price
N/A
22
Now: PK54M
KEY 3 X 3 X 19
Price
N/A
23
LOCK WASHER 12MM
Price
N/A
24
*DISCD*CAP NUT M12
25
*DISCD*HANDLE COLLAR
Price
N/A
26
*DISCD*HANDLE
Price
N/A
27
*DISCD*SCREW BRACKET
Item is no longer available
Price
N/A
28
*DISCD*DOG
Item is no longer available
Price
N/A
29
Now: PB04M
HEX BOLT M6-1 X 10
Price
N/A
30
*DISCD*SUPPORT
Item is no longer available
Price
N/A
31
Now: PB83M
HEX BOLT M6-1 X 16
Price
N/A
32
THRUST BEARING 51102
Price
N/A
33
*DISCD*SCALE RING
34
*DISCD*HANDLE WHEEL
Item is no longer available
Price
N/A
35
Now: PW06M
FLAT WASHER 12MM
Price
N/A
36
*DISCD*NUT 5 X 16
Item is no longer available
Price
N/A
37
*DISCD*HANDLE COLLAR
Price
N/A
38
*DISCD*HANDLE
Price
N/A
39
*DISCD*COVER
Item is no longer available
Price
N/A
40
*DISCD*SCREW M5 X 12
Item is no longer available
Price
N/A
41
*DISCD*SCREW M6 X 12
Item is no longer available
Price
N/A
42
*DISCD*HANDBOARD
Item is no longer available
Price
N/A
43
*DISCD*PIN
Item is no longer available
Price
N/A
44
*DISCD*CROSSWISE LEADSCREW
Item is no longer available
Price
N/A
45
*DISCD*SHORT BEVEL IRON
Item is no longer available
Price
N/A
46
*DISCD*ADJUST SCREW M8-69
Item is no longer available
Price
N/A
47
THRUST BEARING 51102
Price
N/A
48
*DISCD*SUPPORT
49
Now: PB83M
HEX BOLT M6-1 X 16
Price
N/A
50
THRUST BEARING 51102
Price
N/A
51
*DISCD*SCALE RING
Item is no longer available
Price
N/A
52
*DISCD*HANDLE WHEEL
53
Now: PK54M
KEY 3 X 3 X 19
Price
N/A
54
*DISCD*CAP NUT M12
55
*DISCD*HANDLE COLLAR
56
*DISCD*HANDLE
57
*DISCD*SUPPORT REST
Item is no longer available
Price
N/A
58
Now: PB07M
HEX BOLT M8-1.25 X 25
Price
N/A
59
*DISCD*WORM GEAR
60
*DISCD*HANDLE
61
*DISCD*PIN
62
*DISCD*GEAR
63
*DISCD*CLAMP HANDLE
Item is no longer available
Price
N/A
64
*DISCD*RACK
65
*DISCD*COLUMN
66
*DISCD*DUST COVER
67
Now: PB12M
HEX BOLT M12-1.75 X 55
Price
N/A
68
*DISCD*BODY
Item is no longer available
Price
N/A
68-1
*DISCD*SPINDLE SPEED CHART LABEL
Item is no longer available
Price
N/A
69
*DISCD*SCREW 12 X 40
71
ROLL PIN 5 X 16
Price
N/A
72
ROLL PIN 5 X 20
Price
N/A
73
*DISCD*FEED SHAFT
Item is no longer available
Price
N/A
74
*DISCD*PIN
Item is no longer available
Price
N/A
75
*DISCD*SCALE RING
Item is no longer available
Price
N/A
76
*DISCD*HANDLE BODY
Item is no longer available
Price
N/A
77
*DISCD*SCALE
Item is no longer available
Price
N/A
78
CAP SCREW M6-1 X 20
Price
N/A
79
*DISCD*HANDLE BAR
80
*DISCD*KNOB
81
CAP SCREW M6-1 X 20
Price
N/A
82
CAP SCREW M6-1 X 20
Price
N/A
83
*DISCD*CLAMP HANDLE
Item is no longer available
Price
N/A
84
*DISCD*SPRING HANDLE
85
*DISCD*SPRING PLATE
Item is no longer available
Price
N/A
86
*DISCD*SPRING CAP
87
CAP SCREW M6-1 X 20
Price
N/A
88
CAP SCREW M6-1 X 16
Price
N/A
89
Now: PS17M
PHLP HD SCR M4-.7 X 6
Price
N/A
90
*DISCD*SWITCH
Item is no longer available
Price
N/A
91
*DISCD*WIRE
Item is no longer available
Price
N/A
92
Now: PS08M
PHLP HD SCR M5-.8 X 12
Price
N/A
93
*DISCD*BUSHING RUBBER
Item is no longer available
Price
N/A
94
*DISCD*WIRE CLIP
Item is no longer available
Price
N/A
95
*DISCD*SHIFT
Item is no longer available
Price
N/A
96
*DISCD*PIN
Item is no longer available
Price
N/A
97
CAP SCREW M10-1.5 X 40
Price
N/A
98
*DISCD*HEX NUT M12
Item is no longer available
Price
N/A
99
Now: PW01M
FLAT WASHER 8MM
Price
N/A
100
*DISCD*MOTOR BASE
Item is no longer available
Price
N/A
101
*DISCD*MOTOR V1.06.03
101B
*DISCD*MOTOR 1/2HP V2.05.06
Item is no longer available
Price
N/A
102
Now: PB07M
HEX BOLT M8-1.25 X 25
Price
N/A
103
*DISCD*MOTOR PULLEY
104
SET SCREW M4-.7 X 10
Price
N/A
105
*DISCD*HEX NUT M12
Item is no longer available
Price
N/A
106
*DISCD*HEX NUT M12
Item is no longer available
Price
N/A
107
*DISCD*SLIDE BAR
Item is no longer available
Price
N/A
108
*DISCD*PULLEY COVER
Price
N/A
109
Now: PW03M
FLAT WASHER 6MM
Price
N/A
110
CAP SCREW M6-1 X 12
Price
N/A
111
Now: PVA27
V-BELT A27
Price
N/A
112
*DISCD*SPANNER NUT
113
*DISCD*SPINDLE PULLEY
Item is no longer available
Price
N/A
114
*DISCD*SPRING SLEEVE
115
Now: PR24M
INT RETAINING RING 42MM
Price
N/A
116
BALL BEARING 6204ZZ
Price
N/A
117
*DISCD*COLLAR
118
BALL BEARING 6204ZZ
Price
N/A
119
*DISCD*RETAINING RING
Item is no longer available
Price
N/A
120
*DISCD*NUT
Item is no longer available
Price
N/A
121
*DISCD*WASHER
Item is no longer available
Price
N/A
122
BALL BEARING 6203ZZ
Price
N/A
123
*DISCD*SLEEVE
124
BALL BEARING 6205ZZ
Price
N/A
125
*DISCD*DUST COVER
Item is no longer available
Price
N/A
126
*DISCD*SPINDLE
Item is no longer available
Price
N/A
127
*DISCD*SPINDLE BAR
Item is no longer available
Price
N/A
127-1
*DISCD*DRAWBAR 6MM
Item is no longer available
Price
N/A
127-2
*DISCD*DRAWBAR 12 X 1.75
128
*DISCD*DRILL CHUCK
129
*DISCD*WEDGE SHIFTER
130
Now: PK54M
KEY 3 X 3 X 19
Price
N/A
131
*DISCD*CENTER PULLEY SHAFT
Item is no longer available
Price
N/A
132
BALL BEARING 6201ZZ
Price
N/A
133
*DISCD*COLLAR
Item is no longer available
Price
N/A
134
BALL BEARING 6201ZZ
Price
N/A
135
*DISCD*RETAINING RING
Item is no longer available
Price
N/A
136
*DISCD*RETAINING RING
Item is no longer available
Price
N/A
137
*DISCD*CENTER PULLEY
138
Now: PVA31
V-BELT A31
Price
N/A
139
*DISCD*PULLEY COVER
MANUAL
*DISCD*MANUAL FOR G0517 05/06
