Parts for G0546 20" Planer w/ Spiral Cutterhead

IMPORTANT

Parts may have multiple versions that have changed over time. This will be indicated by V1, V2, V3, etc. in the parts description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 of a part went into use in January 2017. Please reference the manufacture date on the ID Label for your machine to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

1
*DISCD*HEAD CASTING
Price
N/A
2
SET SCREW M10-1.5 X 12
Price
N/A
3
Now: H7656
20" Indexable Spiral Cutterhead
Price
N/A
4
COMPRESSION SPRING 0.6 X 5.9 X 16
Price
N/A
5
Now: D3097
20" x 1" x 1/8" HSS Planer Knives, Set of 4
Price
N/A
6
*DISCD*GIB
Price
N/A
7
Now: PB17M
HEX BOLT M8-1.25 X 10
Price
N/A
8
*DISCD*KNIFE GAUGE W/BAR
Price
N/A
9
*DISCD*JACK SCREW
Price
N/A
12
BALL BEARING 6206-2RS
Price
N/A
13
Now: PK09M
KEY 8 X 8 X 35
Price
N/A
14
*DISCD*CUTTERHEAD PULLEY
Price
N/A
15
*DISCD*PULLEY WASHER 5/16 X 1-3/16"
Price
N/A
16
SET SCREW M6-1 X 25
Price
N/A
17
*DISCD*MOTOR PULLEY
Item is no longer available
Price
N/A
18
*DISCD*INFEED ROLLER
Price
N/A
19
*DISCD*BUSHING BLOCK
Price
N/A
20
*DISCD*SPRING
Price
N/A
21
*DISCD*OILER SETSCREW
Price
N/A
22
*DISCD*PLATE
Price
N/A
23
Now: PB09M
HEX BOLT M8-1.25 X 20
Price
N/A
24
SET SCREW M6-1 X 16
Price
N/A
25
Now: PN01M
HEX NUT M6-1
Price
N/A
26
Now: PK21M
KEY 5 X 5 X 23
Price
N/A
29
Now: PB18M
HEX BOLT M6-1 X 15
Price
N/A
30
OUTFEED ROLLER
Price
N/A
32
*DISCD*LOCK ROD
Price
N/A
33
Now: PR03M
EXT RETAINING RING 12MM
Price
N/A
34
*DISCD*CHIP BREAKER
Price
N/A
35
Now: PN09M
HEX NUT M12-1.75
Price
N/A
36
*DISCD*CHIP BREAKER SPRING
Price
N/A
37
Now: PW03M
FLAT WASHER 6MM
Price
N/A
38
Now: PB02M
HEX BOLT M6-1 X 12
Price
N/A
39
*DISCD*SHAFT
Price
N/A
40
*DISCD*BRACKET
Price
N/A
41
*DISCD*PRESSURE BAR
Price
N/A
42
LOCK WASHER 8MM
Price
N/A
43
*DISCD*SHAFT
Price
N/A
44
SET SCREW M6-1 X 16
Price
N/A
46
*DISCD*SPRING PLATE
Price
N/A
47
CHIP DEFLECTOR
Price
N/A
48
*DISCD*ANTI KICKBACK FINGER
Price
N/A
49
*DISCD*SPACER
Price
N/A
50
*DISCD*SHAFT
Price
N/A
51
E-CLIP 20MM
Price
N/A
52
*DISCD*DEPTH LIMITER
Price
N/A
53
FLAT HD SCR M6-1 X 12
Price
N/A
54
*DISCD*UPPER COVER
Price
N/A
55
*DISCD*GASKET
Price
N/A
56
*DISCD*DUST HOOD
Price
N/A
57
*DISCD*ROLLER STAND
Price
N/A
58
*DISCD*ROLLER
Price
N/A
59
CAP SCREW M6-1 X 16
Price
N/A
60
*DISCD*WORM GEAR BOX
Price
N/A
61
CAP SCREW M6-1 X 50
Price
N/A
62
*DISCD*WORM
Price
N/A
63
BALL BEARING 6201ZZ
Price
N/A
64
Now: PR29M
INT RETAINING RING 32MM
Price
N/A
65
Now: PK05M
KEY 4 X 4 X 10
Price
N/A
66
*DISCD*HANDWHEEL
Price
N/A
67
*DISCD*HANDWHEEL WASHER 1/2 X 1-1/8
Price
N/A
68
*DISCD*HANDLE
Price
N/A
69
*DISCD*SCALE
Price
N/A
70
Now: PS08M
PHLP HD SCR M5-.8 X 12
Price
N/A
73
*DISCD*COVER
Price
N/A
75
*DISCD*SAFETY HATCH
Price
N/A
76
Now: PB04M
HEX BOLT M6-1 X 10
Price
N/A
77
*DISCD*SAFETY HATCH
Price
N/A
78
Now: PB11M
HEX BOLT M5-.8 X 8
Price
N/A
79
*DISCD*PULLEY GUARD
Price
N/A
80
*DISCD*STANDOFF ROUND STUD
Price
N/A
81
Now: PW07
FLAT WASHER 5/16
Price
N/A
82
Now: PN02
HEX NUT 5/16-18
Price
N/A
83
Now: PVM59
V-BELT M59 3L590
Price
N/A
84
*DISCD*PULLEY COVER
Price
N/A
85
KNOB 5/16-18, D1-3/4, ROUND
Price
N/A
86
*DISCD*SWITCH BRACKET
Price
N/A
87
*DISCD*MAG SWITCH
Price
N/A
88
Now: PN06M
HEX NUT M5-.8
Price
N/A
89
Now: D3377
Nameplate - Large
Price
N/A
90
*DISCD*RIVET
Price
N/A
92
*DISCD*STRAIN RELIEF
Price
N/A
93
*DISCD*POWER CORD
Price
N/A
94
*DISCD*STAR WASHER #10
Price
N/A
95
CAP SCREW M6-1 X 10
Price
N/A
96
SET SCREW M8-1.25 X 12
Price
N/A
97
*DISCD*RETAINER
Price
N/A
98
*DISCD*COLLAR
Price
N/A
100
MACHINE ID/WARNING LABEL
Price
N/A
101
READ MANUAL LABEL
Price
N/A
102
SAFETY GLASSES LABEL
Price
N/A
103
EAR PROTECTION LABEL
Price
N/A
104
COVER REMOVAL LABEL
Price
N/A
105
ELECTRICITY LABEL
Price
N/A
107
LOCK WASHER 6MM
Price
N/A
108
Now: PS09M
PHLP HD SCR M5-.8 X 10
Price
N/A
109
WHITE SWITCH COVER SCREW V1.12.95
Price
N/A
110
Now: H7319
Indexable Carbide Inserts - 14 x 14 x 2mm, 10-Pk.
Price
N/A
111
FLAT HD TORX SCR T20 M6-1 X 16
Price
N/A
113
T-20 TORX BIT
Price
N/A
114
CHEATER BAR FOR T-20 BIT
Price
N/A
115
T-20 TORX DRIVER
Price
N/A
116
*DISCD*WRENCH T-HANDLE TORX
Item is no longer available
Price
N/A
201
*DISCD*TABLE MIDDLE
Price
N/A
202
*DISCD*ROLLER
Price
N/A
203
BALL BEARING 6201ZZ
Price
N/A
204
*DISCD*ECCENTRIC SHAFT
Price
N/A
205
SET SCREW M6-1 X 12
Price
N/A
206
*DISCD*THREADED GIB
Price
N/A
207
*DISCD*LOCK ROD
Price
N/A
208
GIB
Price
N/A
209
KNOB 6-LOBE M12-1.75, D53
Price
N/A
210
CAP SCREW M10-1.5 X 20
Price
N/A
211
*DISCD*EXT ROLLER BAR
Price
N/A
212
*DISCD*EXTENSION ROLLER, CHROME
Price
N/A
213
Now: PB32M
HEX BOLT M10-1.5 X 25
Price
N/A
214
Now: PW04M
FLAT WASHER 10MM
Price
N/A
215
*DISCD*POINTER
Price
N/A
216
CAP SCREW M6-1 X 10
Price
N/A
217
LOCK WASHER 6MM
Price
N/A
301
*DISCD*BASE
Price
N/A
302
SET SCREW M10-1.5 X 12
Price
N/A
303
*DISCD*COLUMN
Price
N/A
304
*DISCD*COLUMN
Price
N/A
305
*DISCD*LEADSCREW
Price
N/A
306
*DISCD*LEADSCREW
Price
N/A
307
*DISCD*LEADSCREW NUT
Price
N/A
308
*DISCD*BUSHING
Price
N/A
309
Now: PR22M
INT RETAINING RING 38MM
Price
N/A
310
Now: PK10M
KEY 5 X 5 X 12
Price
N/A
311
*DISCD*gear
Price
N/A
312
Now: PR03M
EXT RETAINING RING 12MM
Price
N/A
313
BALL BEARING 6202ZZ
Price
N/A
314
Now: PR21M
INT RETAINING RING 35MM
Price
N/A
315
Now: PK08M
KEY 5 X 5 X 16
Price
N/A
316
*DISCD*SPROCKET
Price
N/A
317
*DISCD*WASHER
Price
N/A
318
Now: PN08M
HEX NUT M10-1.25
Price
N/A
319
Now: PW01M
FLAT WASHER 8MM
Price
N/A
320
Now: PB07M
HEX BOLT M8-1.25 X 25
Price
N/A
321
*DISCD*BRACKET W/SHAFT
Price
N/A
323
*DISCD*SPROCKET
Price
N/A
324
Now: PR05M
EXT RETAINING RING 15MM
Price
N/A
325
*DISCD*CHAIN
Price
N/A
326
*DISCD*CRANE POST
Price
N/A
327
Now: PR08M
EXT RETAINING RING 19MM
Price
N/A
328
*DISCD*PIPE BAND
Price
N/A
329
TAP SCREW 10-24 X 1/2
Price
N/A
330
*DISCD*EXPANSION BAND
Price
N/A
331
Now: PB33M
HEX BOLT M12-1.75 X 50
Price
N/A
332
Now: PW06M
FLAT WASHER 12MM
Price
N/A
333
LOCK WASHER 12MM
Price
N/A
334
Now: PN09M
HEX NUT M12-1.75
Price
N/A
401
*DISCD*STAND
Price
N/A
402
*DISCD*COVER
Price
N/A
403
FLAT HD SCR M6-1 X 20
Price
N/A
404
*DISCD*BAR
Price
N/A
405
*DISCD*MOTOR MOUNT
Price
N/A
406
SET SCREW M8-1.25 X 8
Price
N/A
407
*DISCD*COLLAR
Price
N/A
408
*DISCD*ADJUSTABLE BOLT
Price
N/A
409
Now: PN09M
HEX NUT M12-1.75
Price
N/A
410
Now: PW01
FLAT WASHER 1/2
Price
N/A
411
Now: PB07M
HEX BOLT M8-1.25 X 25
Price
N/A
412
*DISCD*MOTOR MOUNT WASHER 5/16 X 7/8
Price
N/A
413
Now: PN03M
HEX NUT M8-1.25
Price
N/A
414
*DISCD*MOTOR 5HP 22.225MM SHAFT V1.08.03
Price
N/A
415
Now: PK36M
KEY 5 X 5 X 50
Price
N/A
417
*DISCD*POWER CORD
Price
N/A
418
*DISCD*STRAIN RELIEF
Price
N/A
419
Now: PW01M
FLAT WASHER 8MM
Price
N/A
501
*DISCD*GEAR BOX
Price
N/A
502
*DISCD*OIL SEAL 28 X 40 X 8
Price
N/A
503
BALL BEARING 6204ZZ
Price
N/A
504
*DISCD*GEAR
Price
N/A
505
CAP SCREW M6-1 X 20
Price
N/A
506
*DISCD*GEAR BOX WASHER 1/4 X 7/8
Price
N/A
507
CAP SCREW M6-1 X 15
Price
N/A
508
BALL BEARING 6201ZZ
Price
N/A
509
*DISCD*GEAR
Price
N/A
510
*DISCD*GEAR AND SHAFT
Price
N/A
511
Now: PK10M
KEY 5 X 5 X 12
Price
N/A
512
*DISCD*GEAR
Price
N/A
513
Now: PK06M
KEY 5 X 5 X 10
Price
N/A
514
*DISCD*GEAR 2-SPEED
Price
N/A
517
*DISCD*DOUBLE GEAR
Price
N/A
520
Now: PK11M
KEY 6 X 6 X 40
Price
N/A
521
BALL 6MM
Price
N/A
522
*DISCD*SPRING
Price
N/A
523
*DISCD*SHAFT
Price
N/A
524
*DISCD*OIL SEAL 25 X 47 X 7
Price
N/A
529
*DISCD*SHIFTER
Price
N/A
530
*DISCD*SHIFTING SHAFT HANDLE
Price
N/A
531
Now: PW03M
FLAT WASHER 6MM
Price
N/A
532
Now: PB02M
HEX BOLT M6-1 X 12
Price
N/A
533
O-RING 12 X 1.5 S12.5
Price
N/A
534
KNOB 3/8-16, D1-1/4, BALL
Price
N/A
535
*DISCD*PIN
Price
N/A
536
*DISCD*GASKET
Price
N/A
537
*DISCD*GEAR CASE
Price
N/A
538
CAP SCREW M6-1 X 25
Price
N/A
539
*DISCD*OIL PLUG
Price
N/A
540
CAP SCREW M8-1.25 X 50
Price
N/A
601
*DISCD*SPROCKET
Price
N/A
602
*DISCD*SPROCKET WASHER 1/4 X 7/8
Price
N/A
603
CAP SCREW M4-.7 X 8
Price
N/A
604
*DISCD*SPROCKET
Price
N/A
605
ROLL PIN 6 X 20
Price
N/A
606
*DISCD*CHAIN 33 LINKS
Price
N/A
607
CAP SCREW M6-1 X 10
Price
N/A
608
*DISCD*CHAIN TENSIONER
Price
N/A
609
*DISCD*SHAFT
Price
N/A
610
*DISCD*HANGER
Price
N/A
611
*DISCD*SPRING
Price
N/A
612
*DISCD*SPACER
Price
N/A
613
*DISCD*OUTER CHAIN TENSIONER
Price
N/A
614
*DISCD*SPROCKET
Price
N/A
615
*DISCD*CHAIN 25 LINKS
Price
N/A
616
CAP SCREW M6-1 X 35
Price
N/A
617
Now: PW03M
FLAT WASHER 6MM
Price
N/A
MANUAL
MANUAL FOR G0546 08/03
