Parts for G0713 - 10" 1-3/4 HP Left-Tilting Contractor Style Table Saw with Riving Knife

1/7

IMPORTANT: Parts may have multiple versions. This will be indicated by V1, V2, or V3 on the part number and/or description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 beginning in January 2017. Please reference your machine's manufacture date on the ID Label to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

Ref #
Part #
Description
1
*DISCD*FENCE ASSEMBLY
Price
N/A
1-1
PLATE CAP
Price
N/A
1-10
FENCE
Price
N/A
1-11
HEX NUT M6-1
Price
N/A
1-12
RAIL WHEEL REAR
Price
N/A
1-13
HEX NUT M8-1.25
Price
N/A
1-14
FLAT WASHER 8MM
Price
N/A
1-15
SET SCREW PLASTIC
Price
N/A
1-16
HEX BOLT M10-1.5 X 50
Price
N/A
1-17
FENCE HANDLE
Price
N/A
1-18
CAM ASSEMBLY
Price
N/A
1-19
PLATE
Price
N/A
1-2
PLATE
Price
N/A
1-20
PHLP HD SCR M6-1 X 10
Price
N/A
1-21
BRACKET
Price
N/A
1-22
LOCK NUT M10-1.5
Price
N/A
1-23
LOCK NUT M6-1
Price
N/A
1-24
SET SCREW M8-1.25 X 8
Price
N/A
1-26
FLAT HD SCR M3-.5 X 6
Price
N/A
1-3
HEX BOLT M6-1 X 45
Price
N/A
1-4
CLAMPING BRACKET
Price
N/A
1-5
PLATE
Price
N/A
1-6
FENCE SCREW
Price
N/A
1-7
POINTER 2PCS V2.12.09
Price
N/A
1-7V2
POINTER 2PCS V2.12.09
Price
N/A
1-9
PHLP HD SCR M6-1 X 10
Price
N/A
1-9V2
PHLP HD SCR M6-1 X 6
Price
N/A
2V2
BLADE GUARD ASSY V2.01.10
Price
N/A
2V2-1
LEFT PLATE V2.01.10
Price
N/A
2V2-10
RIGHT BRACKET V2.01.10
Price
N/A
2V2-11
BUTTON HD CAP SCR M4-.7 X 10
Price
N/A
2V2-12
MOUNTING PIN V2.01.10
Price
N/A
2V2-13
RIGHT COVER V2.01.10
Price
N/A
2V2-14
RIGHT PLATE V2.01.10
Price
N/A
2V2-15
PUSH NUT 4MM V2.01.10
Price
N/A
2V2-16
LEFT PAWL V2.01.10
Price
N/A
2V2-17
RIGHT TORSN SPRING V2.01.10
Price
N/A
2V2-18
PAWL MOUNTING BRKT V2.01.10
Price
N/A
2V2-19
MOUNTING BRKT PIN V2.01.10
Price
N/A
2V2-2
LOCK NUT M5-.8
Price
N/A
2V2-20
MOUNTING BRKT SHFT V2.01.10
Price
N/A
2V2-21
SHAFT SPRING V2.01.10
Price
N/A
2V2-22
E-CLIP 7MM
Price
N/A
2V2-23
LEFT TORSION SPRING V2.01.10
Price
N/A
2V2-24
RIGHT PAWL V2.01.10
Price
N/A
2V2-25
RIGHT PAWL SHAFT V2.01.10
Price
N/A
2V2-26
SPREADER V2.01.10
Price
N/A
2V2-27
O-RING 2.8 X 1.9 P3
Price
N/A
2V2-28
AMPUTATION HAZ LABEL V2.01.10
Price
N/A
2V2-3
FLAT HD SCR M5-.8 X 15
Price
N/A
2V2-4
LEFT COVER V2.01.10
Price
N/A
2V2-5
ROD CENTER PIN V2.01.10
Price
N/A
2V2-6
PHLP HD SCR M5-.8 X 6
Price
N/A
2V2-7
KNOB BOLT V2.01.10
Price
N/A
2V2-8
ROD V2.01.10
Price
N/A
2V2-9
LEFT BRACKET V2.01.10
Price
N/A
3
MITER GAUGE ASSEMBLY
Price
N/A
4
SET SCREW M5-.8 X 5
Price
N/A
5V2
Zero Clearance Table Saw Insert for G0661, G0713 & G0732
Price
N/A
6V2
LOCK KNOB M5-.8 V2.01.10
Price
N/A
7
RAIL
Price
N/A
7-1
RAIL CAP SCREW M8-1.25 X 25
Price
N/A
7-2
*DISCD*REAR RAIL
Price
N/A
7-3
END CAP
Price
N/A
7-4
RAIL TUBE
Price
N/A
7-5
FLAT HD SCR M8-1.25 X 25
Price
N/A
7-6
FRONT RAIL
Price
N/A
7-7
FLANGE BOLT M8-1.25 X 10
Price
N/A
7-8
LOCK WASHER 8MM
Price
N/A
7-9
HEX NUT M8-1.25
Price
N/A
8
EXTENSION TABLE
Price
N/A
9
HEX BOLT M8-1.25 X 20
Price
N/A
10
LOCK WASHER 8MM
Price
N/A
11
TABLE
Price
N/A
12
Paddle Switch 120/230V
Price
N/A
12-1
PHLP HD SCR M4-.7 X 25
Price
N/A
12-2
LOCK WASHER 4MM
Price
N/A
12-3
Paddle Switch 120/230V
Price
N/A
12-4
SWITCH BRACKET
Price
N/A
12-5
SWITCH BOX
Price
N/A
12-6
STRAIN RELIEF M16 TYPE-1 SNAP-IN
Price
N/A
12-7
POWER CORD 12AWG X 10' 5-15 PLUG
Item is no longer available
Price
N/A
12-8
MOTOR CORD 12AWG X 4'
Price
N/A
12-9
SWITCH DISABLING PIN 3/16 X 2-1/8"
Price
N/A
13
HEX BOLT M6-1 X 12
Price
N/A
14
RIBBED BELT 170J6
Price
N/A
15
SET SCREW M8-1.25 X 8
Price
N/A
16
SPINDLE PULLEY
Price
N/A
17
KEY 5 X 5 X 20
Price
N/A
18
BALL BEARING 6203-2RS
Price
N/A
19
CAP SCREW M8-1.25 X 16
Price
N/A
20
LEADSCREW WASHER 8MM
Price
N/A
21
ELEVATION LEADSCREW
Price
N/A
22
BUSHING
Price
N/A
23
GASKET
Price
N/A
24
THRUST BEARING 51102
Price
N/A
25
SET SCREW M5-.8 X 8
Price
N/A
26
SET SCREW M8-1.25 X 20
Price
N/A
27
CAP SCREW M8-1.25 X 35
Price
N/A
28
COLUMN FRONT
Price
N/A
29
REAR COLUMN
Price
N/A
30
BRACKET
Price
N/A
31
CAP SCREW M8-1.25 X 20
Price
N/A
32
HEX NUT M8-1.25
Price
N/A
33
EXTENSION SPRING
Price
N/A
34
FLANGE BOLT M6-1 X 40
Price
N/A
35
COMPRESSION SPRING
Price
N/A
36
FLAT WASHER 6MM
Price
N/A
37
EXT TOOTH WASHER 8MM
Price
N/A
38
HEX BOLT M8-1.25 X 25
Price
N/A
39
TRUNNION BRACKET
Price
N/A
40
TRUNNION
Price
N/A
42V2
RIVING KNIFE V2.01.10
Price
N/A
44V2
BRACKET V2.01.10
Price
N/A
44V2-1
MOUNTING BASE V2.01.10
Price
N/A
44V2-10
SET SCREW M5-.8 X 8
Price
N/A
44V2-2
CAP SCREW M8-1.25 X 20
Price
N/A
44V2-3
COMPRESSION SPRING V2.01.10
Price
N/A
44V2-4
LOCKING BOLT V2.01.10
Price
N/A
44V2-5
MOUNTING BRACKET PLATE V2.01.10
Price
N/A
44V2-6
BUTTON HD CAP SCR M5-.8 X 12
Price
N/A
44V2-7
LOCK WASHER 5MM
Price
N/A
44V2-8
HANDLE V2.01.10
Price
N/A
44V2-9
BUTTON HD CAP SCR M5-.8 X 16
Price
N/A
45
*DISCD* SPINDLE
Price
N/A
46
BLADE 10" X 40T
Price
N/A
47
BLADE MOUNTING FLANGE
Price
N/A
48
ARBOR NUT 5/8"-12
Price
N/A
49
BLADE COVER
Price
N/A
50
PHLP HD SCR M5-.8 X 35
Price
N/A
51
LEFT BEVEL GEAR
Price
N/A
52
KEY 4 X 4 X 10
Price
N/A
53
FLAT WASHER 8MM
Price
N/A
54
LOCK NUT M8-1.25
Price
N/A
55
EXT TOOTH WASHER 5MM
Price
N/A
56
RIGHT BEVEL GEAR
Price
N/A
57
FLAT WASHER 16MM
Price
N/A
58
*DISCD*SHAFT
Price
N/A
59
EXT TOOTH WASHER 16MM ZY CHROMATE
Price
N/A
60
SHAFT
Price
N/A
61
COLLAR
Price
N/A
62
SUPPORT PLATE
Price
N/A
63
COLLAR
Price
N/A
64
POINTER
Price
N/A
65
FLANGE SCREW M5-.8 X 10
Price
N/A
66
HANDWHEEL
Price
N/A
67
HANDLE 3/8-16
Price
N/A
68
LOCKING KNOB 5/16-18
Price
N/A
69
FLAT WASHER 8MM
Price
N/A
70
E-CLIP 8MM
Price
N/A
71
COMPRESSION SPRING
Price
N/A
72
HANDLE W/BUSHING
Price
N/A
73
SHAFT
Price
N/A
74
KEY 4 X 4 X 12
Price
N/A
75
HEX BOLT M8-1.25 X 16
Price
N/A
76
CABINET
Price
N/A
77
REUSABLE BEADED CABLE TIE
Price
N/A
78
STRAIN RELIEF 3/4" TYPE-1 SNAP-IN
Price
N/A
79
PLATE
Price
N/A
80
BRACKET
Price
N/A
81
LOCK NUT M5-.8
Price
N/A
82
MOTOR 1-3/4HP 110V/220V 1-PH
Price
$304.50
82-1
KEY 5 X 5 X 20
Price
N/A
82-10
R CAPACITOR 35M 300V 1-1/2 X 2-3/4 V1
Item is no longer available
Price
N/A
82-10V2
R CAPACITOR 35M 300V 1-1/2 X 2-3/4 V1
Price
N/A
82-2
SET SCREW M8-1.25 X 8
Price
N/A
82-3
MOTOR PULLEY
Price
N/A
82-4
STRAIN RELIEF 3/4" TYPE-1 SNAP-IN
Price
N/A
82-5
JUNCTION BOX
Price
N/A
82-6
MOTOR FAN COVER
Price
N/A
82-7
MOTOR FAN
Price
N/A
82-8
CAPACITOR COVER
Price
N/A
82-9
S CAPACITOR 200M 125V 1-1/2 X 2-3/4
Price
N/A
82-9V2
S CAPACITOR 200M 125V 1-1/2 X 2-3/4
Price
N/A
83
FLAT WASHER 10MM
Price
N/A
84
LOCK WASHER 10MM
Price
N/A
85
HEX BOLT M10-1.5 X 30
Price
N/A
86
SHAFT
Price
N/A
87
LOCK NUT M10-1.5
Price
N/A
88
PHLP HD SCR M5-.8 X 10
Price
N/A
89
HINGE
Price
N/A
90
HEX NUT M5-.8
Price
N/A
91
COVER
Price
N/A
92
KNOB BOLT M8-1.25 X 30
Price
N/A
93
PHLP HD SCR M5-.8 X 12
Price
N/A
94
TAP SCREW M5 X 12
Price
N/A
95
*DISCD*TILT LEADSCREW
Price
N/A
96
FLAT WASHER 8MM
Price
N/A
97
HEX NUT M8-1.25
Price
N/A
98
CARRIAGE BOLT M8-1.25 X 12
Price
N/A
99
RIGHT STAND LEG
Price
N/A
100
UPPER STAND BRACE
Price
N/A
101
LOWER STAND BRACE
Price
N/A
102
SIDE STAND BRACE
Price
N/A
103
LEFT STAND LEG
Price
N/A
104
FOOT
Price
N/A
105
FLAT WASHER 8MM
Price
N/A
106
LEADSCREW NUT
Price
N/A
107
LOCK WASHER 6MM
Price
N/A
108
CAP SCREW M6-1 X 30
Price
N/A
114
FLAT WASHER 8MM
Price
N/A
115
HEX WRENCH 6MM
Price
N/A
116
ARBOR WRENCH
Price
N/A
117
WRENCH 11 X 13MM OPEN-ENDS
Price
N/A
118-1V2
DADO TABLE INSERT V2.01.10
Price
N/A
118-2V2
SET SCREW M5-.8 X 12
Price
N/A
118V2
*DISCD*DADO TBL INSERT ASSY V2.01.10
Price
N/A
119
HEX WRENCH 5MM
Price
N/A
135
PUSH STICK HOLDER
Price
N/A
141
PUSH STICK
Price
N/A
145
SET SCREW M5-.8 X 12
Price
N/A
203
ELECTRICITY 1.4W X 1.2H
Price
N/A
204
Name Plates - Mini
Price
N/A
205
MODEL NUMBER LABEL
Item is no longer available
Price
N/A
206
MACHINE ID LABEL
Item is no longer available
Price
N/A
207
READ MANUAL 2W X 3.3H V2.07.05
Price
N/A
208
GLASSES/RESPIRATOR 2W X 3.3H
Price
N/A
209
GREY PUTTY REF G0504
Price
N/A
210
N/S GRIZZLY GREEN G1023S
Price
N/A
211
BLADE TILT SCALE
Price
N/A
212
FENCE SCALE 36"
Price
N/A
212A
FENCE SCALE SET 36" & 12"
Price
N/A
212A-1
FENCE SCALE 12"
Price
N/A
213
UL 987 WARNING LABEL
Price
N/A
MAN
MANUAL FOR G0661 04/10
Price
N/A
