Parts for G9744Z 10 x 18" Metal Cutting Bandsaw

IMPORTANT

Parts may have multiple versions that have changed over time. This will be indicated by V1, V2, V3, etc. in the parts description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 of a part went into use in January 2017. Please reference the manufacture date on the ID Label for your machine to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

1
*DISCD*SLIDE SET
Item is no longer available
Price
N/A
1-1
*DISCD*SLIDE
Item is no longer available
Price
N/A
1-10
*DISCD*SLIDE SCREW
Item is no longer available
Price
N/A
1-11
*DISCD*SCALE
Item is no longer available
Price
N/A
1-12
Now: PS05M
PHLP HD SCR M5-.8 X 8
Price
N/A
1-13
Now: PB32M
HEX BOLT M10-1.5 X 25
Price
N/A
1-14
LOCK WASHER 10MM
Price
N/A
1-15
*DISCD*GIB
Item is no longer available
Price
N/A
1-16
*DISCD*BRACKET
Item is no longer available
Price
N/A
1-2
*DISCD*SLIDE SET SCREW
1-3
Now: PN10
HEX NUT 7/16-20
Price
N/A
1-4
Now: PW04M
FLAT WASHER 10MM
Price
N/A
1-5
CAP SCREW M10-1.5 X 65
Price
N/A
1-6
*DISCD*DISC SPRING
Item is no longer available
Price
N/A
1-7
*DISCD*INDICATOR DIAL
Item is no longer available
Price
N/A
1-8
THRUST BEARING 51204
Price
N/A
1-9
Now: PW01
FLAT WASHER 1/2
Price
N/A
2
ROLL PIN 5 X 25
Price
N/A
3
*DISCD*COLLAR
Item is no longer available
Price
N/A
4
*DISCD*LEADSCREW
Item is no longer available
Price
N/A
5
Now: PB20M
HEX BOLT M8-1.25 X 35
Price
N/A
6
*DISCD*HANDWHEEL & HANDLE
Item is no longer available
Price
N/A
7
*DISCD*COMPRESSION SPRING
Item is no longer available
Price
N/A
8
ROLL PIN 5 X 50
Price
N/A
9
*DISCD*BRACKET
10
*DISCD*SHAFT
Item is no longer available
Price
N/A
41
CAP SCREW M10-1.5 X 30
Price
N/A
42
LOCK WASHER 10MM
Price
N/A
43
*DISCD*IDLER WHEEL BOX
Item is no longer available
Price
N/A
44
CAP SCREW M10-1.5 X 16
Price
N/A
45
*DISCD*TENSION LABEL
Item is no longer available
Price
N/A
46
RIVET 2
Price
N/A
47
Now: PS68M
PHLP HD SCR M6-1 X 10
Price
N/A
48
*DISCD*BRACKET
Item is no longer available
Price
N/A
49
CAP SCREW M12-1.75 X 30
Price
N/A
50
CAP SCREW M6-1 X 25
Price
N/A
51
*DISCD*BUSHING
52
*DISCD*IDLER WHEEL
Item is no longer available
Price
N/A
52-1
Now: PB70M
HEX BOLT M10-1.5 X 16
Price
N/A
52-2
Now: PW04M
FLAT WASHER 10MM
Price
N/A
53
CAP SCREW M8-1.25 X 16
Price
N/A
54
HANDLE
Price
N/A
55
*DISCD*SPEED INDICATOR LABEL
Item is no longer available
Price
N/A
56
*DISCD*IDLER WHEEL COVER
57
*DISCD*PLASTIC BUSHING
Item is no longer available
Price
N/A
58
CAP SCREW M6-1 X 10
Price
N/A
59
Now: PLW02
LOCK WASHER 1/4
Price
N/A
60
*DISCD*HEX NUT M8
Item is no longer available
Price
N/A
61
Now: PLW01
LOCK WASHER 5/16
Price
N/A
63
*DISCD*BLADE GUARD
Item is no longer available
Price
N/A
64
*DISCD*BLADE LABEL
Item is no longer available
Price
N/A
67
Now: PLW02
LOCK WASHER 1/4
Price
N/A
68
CAP SCREW M6-1 X 10
Price
N/A
69
*DISCD*SCALE
Item is no longer available
Price
N/A
70
RIVET 2
Price
N/A
71
CAP SCREW M12-1.75 X 30
Price
N/A
72
SET SCREW M8-1.25 X 20
Price
N/A
73
*DISCD*COLUMN
Item is no longer available
Price
N/A
74
CAP SCREW M10-1.5 X 35
Price
N/A
75
Now: PW04M
FLAT WASHER 10MM
Price
N/A
76
ROLL PIN 5 X 25
Price
N/A
77
*DISCD*COLUMN SUPPORT LEFT
78
CAP SCREW M8-1.25 X 50
Price
N/A
79
LOCK WASHER 8MM
Price
N/A
80
Now: PLW01
LOCK WASHER 5/16
Price
N/A
81
*DISCD*SUPPORT SEAT
Item is no longer available
Price
N/A
82
*DISCD*ADJUSTABLE FIXING PLATE IDLER
Item is no longer available
Price
N/A
83
Now: PLW02
LOCK WASHER 1/4
Price
N/A
84
CAP SCREW M6-1 X 20
Price
N/A
85
Now: PN03M
HEX NUT M8-1.25
Price
N/A
86
SET SCREW M8-1.25 X 20
Price
N/A
87
*DISCD*BLADE ADJUSTABLE KNOB
Item is no longer available
Price
N/A
88
Now: PW04M
FLAT WASHER 10MM
Price
N/A
89
*DISCD*ARM LEFT
Item is no longer available
Price
N/A
90
GIB
Price
N/A
91
*DISCD*HOSE CLAMP
Item is no longer available
Price
N/A
92
Now: PS05M
PHLP HD SCR M5-.8 X 8
Price
N/A
93
*DISCD*ARM RIGHT
Item is no longer available
Price
N/A
94
Now: PW04M
FLAT WASHER 10MM
Price
N/A
95
CAP SCREW M10-1.5 X 60
Price
N/A
100
*DISCD*BEARING SPACER
Item is no longer available
Price
N/A
103
*DISCD*BEARING BRACKET IDLER
104
SET SCREW M8-1.25 X 8
Price
N/A
105
*DISCD*CARBIDE GUIDE
Item is no longer available
Price
N/A
106
CAP SCREW M6-1 X 20
Price
N/A
107
*DISCD*ECCENTRIC SHAFT SET
Item is no longer available
Price
N/A
108
*DISCD*BEARING SHAFT ASSY
Item is no longer available
Price
N/A
109
*DISCD*MICRO CONTROL BLOCK
116
***USE P9744Z2328***
Item is no longer available
Price
N/A
117
*DISCD*PIVOT SHAFT
118
CAP SCREW M10-1.5 X 30
Price
N/A
119
*DISCD*DRIVE WHEEL BOX
Item is no longer available
Price
N/A
120
Now: PR05M
EXT RETAINING RING 15MM
Price
N/A
121
SET SCREW M8-1.25 X 20
Price
N/A
122
CAP SCREW M10-1.5 X 16
Price
N/A
123
*DISCD*BELT TENSION KNOB
Item is no longer available
Price
N/A
124
Now: PW04M
FLAT WASHER 10MM
Price
N/A
125
*DISCD*MOTOR ADJUSTABLE ROD
Item is no longer available
Price
N/A
126
Now: PN03M
HEX NUT M8-1.25
Price
N/A
127
Now: PW07
FLAT WASHER 5/16
Price
N/A
128
*DISCD*BRACKET
Item is no longer available
Price
N/A
129
Now: PB15M
HEX BOLT M8-1.25 X 40
Price
N/A
130
Now: PB15M
HEX BOLT M8-1.25 X 40
Price
N/A
131
Now: PW07
FLAT WASHER 5/16
Price
N/A
132
*DISCD*MOTOR PLATE
Item is no longer available
Price
N/A
133
Now: PW07
FLAT WASHER 5/16
Price
N/A
134
Now: PN03M
HEX NUT M8-1.25
Price
N/A
135
SET SCREW M6-1 X 10
Price
N/A
136
*DISCD*PIVOT SHAFT
Item is no longer available
Price
N/A
137
*DISCD*MOTOR 1.5HP 220V 1-PH V1
Item is no longer available
Price
N/A
137A
*DISCD*MOTOR 2HP 220V 1-PH V2.07.05
Item is no longer available
Price
N/A
137A-1
*DISCD*MOTOR COVER
137A-2
*DISCD*MOTOR FAN
Item is no longer available
Price
N/A
137A-3
*DISCD*CAPACITOR COVER
Item is no longer available
Price
N/A
137A-4
*DISCD*S CAPACITOR 800M 125V
Item is no longer available
Price
N/A
137A-5
*DISCD*JUNCTION BOX
Item is no longer available
Price
N/A
138
Now: PB20M
HEX BOLT M8-1.25 X 35
Price
N/A
140
*DISCD*HOSE 5/8 X 6000MM
Item is no longer available
Price
N/A
141
*DISCD*HOSE FITTING PT 1/2"
Item is no longer available
Price
N/A
142
LOCK WASHER 10MM
Price
N/A
143
CAP SCREW M10-1.5 X 20
Price
N/A
144
CAP SCREW M6-1 X 25
Price
N/A
145
*DISCD*BRACKET
Item is no longer available
Price
N/A
146
*DISCD*COLUMN RIGHT SUPPORT
147
ROLL PIN 5 X 25
Price
N/A
148
CAP SCREW M10-1.5 X 35
Price
N/A
149
Now: PW04M
FLAT WASHER 10MM
Price
N/A
152
*DISCD*STAR WASHER AW05
Item is no longer available
Price
N/A
153
*DISCD*COLLAR
Item is no longer available
Price
N/A
154
SET SCREW M8-1.25 X 8
Price
N/A
155
Now: G6436
129-3/8" x 1" x .035" x 5-8 TPI VP Bi-Metal Bandsaw Blade
Price
N/A
156
DRIVE WHEEL
Price
N/A
157
Now: PK28M
KEY 7 X 7 X 29
Price
N/A
158
*DISCD*WHEELCOVER
Item is no longer available
Price
N/A
159
*DISCD*WARNING LABEL
Item is no longer available
Price
N/A
160
Now: PS68M
PHLP HD SCR M6-1 X 10
Price
N/A
161
*DISCD*BRUSH COVER
Item is no longer available
Price
N/A
162
Now: PLW02
LOCK WASHER 1/4
Price
N/A
163
Now: PN03M
HEX NUT M8-1.25
Price
N/A
170
Now: PN09M
HEX NUT M12-1.75
Price
N/A
171
*DISCD*COMPRESSION SPRING
172
*DISCD*BLADE ADJUSTABLE DRIVE
Item is no longer available
Price
N/A
173
SET SCREW M8-1.25 X 8
Price
N/A
174
ROLL PIN 3 X 10
Price
N/A
175
*DISCD*ADJUSTABLE FIXING PLATE DRIVE
Item is no longer available
Price
N/A
176
Now: PLW02
LOCK WASHER 1/4
Price
N/A
177
CAP SCREW M6-1 X 20
Price
N/A
178
Now: PN03M
HEX NUT M8-1.25
Price
N/A
179
SET SCREW M6-1 X 10
Price
N/A
180
*DISCD*BEARING SPACER
Item is no longer available
Price
N/A
181
*DISCD*BRUSH ASSY
Price
N/A
185
*DISCD*MOTOR PULLEY COVER
Item is no longer available
Price
N/A
185-1
*DISCD*PULLEY BOTTOM COVER ASSY
Item is no longer available
Price
N/A
187
*DISCD*SPINDLE PULLEY
188
*DISCD*MOUNT PULLEY
Item is no longer available
Price
N/A
189
Now: PS39M
PHLP HD SCR M8-1.25 X 10
Price
N/A
191
Now: PB20M
HEX BOLT M8-1.25 X 35
Price
N/A
192
SET SCREW M8-1.25 X 10
Price
N/A
193
Now: PVA32
V-BELT A32
Price
N/A
194
Now: PS39M
PHLP HD SCR M8-1.25 X 10
Price
N/A
194-1
Now: PN02
HEX NUT 5/16-18
Price
N/A
195
Now: PW07
FLAT WASHER 5/16
Price
N/A
196
*DISCD*SPEED INDICATOR LABEL
Item is no longer available
Price
N/A
216
*DISCD*HOSE CLAMP 1/2"
Item is no longer available
Price
N/A
217
*DISCD*HOSE 5/16 X 600MM
Item is no longer available
Price
N/A
218
*DISCD*HOSE FITTING PT1/4 X 1/4
Item is no longer available
Price
N/A
219
*DISCD*VALVE PT 1/4
Item is no longer available
Price
N/A
220
*DISCD*HOSE FITTING PT 1/4 X 1/2
Item is no longer available
Price
N/A
221
*DISCD*HOSE 1/4 X 1400MM
Item is no longer available
Price
N/A
222
*DISCD*NOZZLE PT 1/4
230
*DISCD*SPRING COVER
Item is no longer available
Price
N/A
231
Now: PB26M
HEX BOLT M8-1.25 X 30
Price
N/A
232
Now: PW07
FLAT WASHER 5/16
Price
N/A
233
Now: PN03M
HEX NUT M8-1.25
Price
N/A
234
Now: PW01
FLAT WASHER 1/2
Price
N/A
235
Now: PN06
HEX NUT 1/2-12
Price
N/A
236
*DISCD*SPRING BRACKET
Item is no longer available
Price
N/A
237
Now: PB15M
HEX BOLT M8-1.25 X 40
Price
N/A
238
*DISCD*EYE BOLT
Item is no longer available
Price
N/A
239
*DISCD*EXTENSION SPRING
Item is no longer available
Price
N/A
240
ROLL PIN 5 X 36
Price
N/A
241
*DISCD*BRACKET
Item is no longer available
Price
N/A
242
*DISCD*ACME NUT ASSY
Item is no longer available
Price
N/A
243
*DISCD*ACME SCREW
Item is no longer available
Price
N/A
244
Now: PB20M
HEX BOLT M8-1.25 X 35
Price
N/A
245
*DISCD*PIN
Item is no longer available
Price
N/A
246
*DISCD*RACK HOOK
Item is no longer available
Price
N/A
247
*DISCD*BRACKET
Item is no longer available
Price
N/A
248
*DISCD*RACK SUPPORT
Item is no longer available
Price
N/A
250
CAP SCREW M6-1 X 25
Price
N/A
251
LOCK WASHER 8MM
Price
N/A
252
CAP SCREW M8-1.25 X 25
Price
N/A
253
*DISCD*ACME SCREW
Item is no longer available
Price
N/A
254
Now: PK20M
KEY 5 X 5 X 15
Price
N/A
255
*DISCD*RACK
258
Now: PB87M
HEX BOLT M8-1.25 X 15
Price
N/A
259
*DISCD*FIXED PLATE
Item is no longer available
Price
N/A
260
*DISCD*FIXED PLATE
Item is no longer available
Price
N/A
261
Now: PB17M
HEX BOLT M8-1.25 X 10
Price
N/A
262
Now: PW07
FLAT WASHER 5/16
Price
N/A
263
Now: PN03M
HEX NUT M8-1.25
Price
N/A
264
*DISCD*BRACKET
Item is no longer available
Price
N/A
265
CAP SCREW M6-1 X 35
Price
N/A
266
CAP SCREW M8-1.25 X 30
Price
N/A
267
*DISCD*DISTANCE SET ROD
Item is no longer available
Price
N/A
268
Now: PB32M
HEX BOLT M10-1.5 X 25
Price
N/A
269
Now: PN03M
HEX NUT M8-1.25
Price
N/A
270
DISTANCE SET BRACKET
Price
N/A
271
SUPPORT ROD
Price
N/A
272
Now: PLW02
LOCK WASHER 1/4
Price
N/A
273
*DISCD*THUMB SCREW
274
SET SCREW M6-1 X 10
Price
N/A
275
Now: PR11M
EXT RETAINING RING 25MM
Price
N/A
278
Now: PB14M
HEX BOLT M10-1.5 X 35
Price
N/A
279
LOCK WASHER 10MM
Price
N/A
280
*DISCD*BUSHING
Item is no longer available
Price
N/A
281
*DISCD*REAR PIVOT BRACKET
Item is no longer available
Price
N/A
282
*DISCD*COLLAR
Item is no longer available
Price
N/A
283
*DISCD*STAR WASHER AW05
Item is no longer available
Price
N/A
284
*DISCD*BEARING 6904RNA
Item is no longer available
Price
N/A
285
HEX BOLT M12-1.75 X 80
Price
N/A
286
Now: PN09M
HEX NUT M12-1.75
Price
N/A
287
*DISCD*POSITION SET BRACKET
Item is no longer available
Price
N/A
288
Now: PW07
FLAT WASHER 5/16
Price
N/A
289
CAP SCREW M8-1.25 X 20
Price
N/A
290
*DISCD*GREASE NIPPLE
Item is no longer available
Price
N/A
291
*DISCD*BUSHING
Item is no longer available
Price
N/A
294
Now: PW04
FLAT WASHER 7/16
Price
N/A
295
*DISCD*BASE
Item is no longer available
Price
N/A
296
Now: PS05M
PHLP HD SCR M5-.8 X 8
Price
N/A
297
*DISCD*DEGREE SCALE
Item is no longer available
Price
N/A
298
SET SCREW M8-1.25 X 10
Price
N/A
299
FRONT VISE JAW
Price
N/A
300
Now: PW04M
FLAT WASHER 10MM
Price
N/A
301
VISE FENCE LOCK KNOB
Price
N/A
302
CAP SCREW M10-1.5 X 30
Price
N/A
303
Now: PW04M
FLAT WASHER 10MM
Price
N/A
304
BUSHING
Price
N/A
305
SET SCREW M6-1 X 10
Price
N/A
306
BUSHING
Price
N/A
307
SET SCREW M8-1.25 X 30
Price
N/A
308
REAR VISE JAW
Price
N/A
310
Now: PB02M
HEX BOLT M6-1 X 12
Price
N/A
311
Now: PLW02
LOCK WASHER 1/4
Price
N/A
312
*DISCD*CONTROL BOX
312-1
E-STOP BUTTON KEDU HY57B
Price
N/A
312-30
FEED/SPEED CONTROL DIAL V2.12.08
Price
N/A
312-5
PUMP ON/OFF SWITCH
Price
N/A
313
Now: PS14M
PHLP HD SCR M6-1 X 12
Price
N/A
315
*DISCD*NAME PLATE
Item is no longer available
Price
N/A
316
Now: PS70M
PHLP HD SCR M5-1 X 8
Price
N/A
317
*DISCD*COLUMN
Item is no longer available
Price
N/A
318
*DISCD*BLADE LOWER GUARD
Item is no longer available
Price
N/A
319
Now: PLW01
LOCK WASHER 5/16
Price
N/A
320
Now: PB03M
HEX BOLT M8-1.25 X 16
Price
N/A
321
CAP SCREW M6-1 X 10
Price
N/A
322
*DISCD*UPPER BLADE COVER
Item is no longer available
Price
N/A
323
Now: PS70M
PHLP HD SCR M5-1 X 8
Price
N/A
326
Now: PS70M
PHLP HD SCR M5-1 X 8
Price
N/A
328
*DISCD*NAME PLATE
Item is no longer available
Price
N/A
329
*DISCD*ELECTRICAL BOX
Item is no longer available
Price
N/A
329-1
*DISCD*COMPLETE FUSE HOLDER
Item is no longer available
Price
N/A
329-2
*DISCD*CONTACTOR LCK09 RF 220V
Item is no longer available
Price
N/A
329-3
*DISCD*THERMAL OL LR7K0332 RF 220V V1
Item is no longer available
Price
N/A
329-4
*DISCD*RELAY 240/24V 220V RF
Item is no longer available
Price
N/A
329-5
*DISCD*RELAY RECEPTACLE
Item is no longer available
Price
N/A
329A
*DISCD*COMPLETE ELECTRICAL BOX
Item is no longer available
Price
N/A
329V2-3
*DISCD*THERMAL OVERLOAD RHN-10K TECO V2.
331
*DISCD*STAND
Item is no longer available
Price
N/A
331-1
*DISCD*STAND
Price
N/A
331-2
*DISCD*STAND
Price
N/A
332
Now: PS68M
PHLP HD SCR M6-1 X 10
Price
N/A
333
LOCK WASHER 6MM
Price
N/A
334
Now: PB18M
HEX BOLT M6-1 X 15
Price
N/A
335
*DISCD*FILTER
Item is no longer available
Price
N/A
336
*DISCD*HEX NUT M6
Item is no longer available
Price
N/A
337
Now: PB26M
HEX BOLT M8-1.25 X 30
Price
N/A
338
Now: PN03M
HEX NUT M8-1.25
Price
N/A
339
Now: PW07
FLAT WASHER 5/16
Price
N/A
340
CAP SCREW M8-1.25 X 40
Price
N/A
341
CAP SCREW M6-1 X 45
Price
N/A
342
Now: PB22M
HEX BOLT M8-1.25 X 50
Price
N/A
343
*DISCD*CHIP TRAY
Item is no longer available
Price
N/A
346
COOLANT TANK
Price
N/A
347
*DISCD*COOLANT PUMP
Item is no longer available
Price
N/A
348
Now: PW06
FLAT WASHER 1/4
Price
N/A
349
Now: PS07
PHLP HD SCR 1/4-20 X 3/8
Price
N/A
350
*DISCD*COUPLER PT 1/2 X 1/4
Item is no longer available
Price
N/A
351
*DISCD*HOSE 3/4 X 1.5
Item is no longer available
Price
N/A
356
Now: PS68M
PHLP HD SCR M6-1 X 10
Price
N/A
357
Now: PLW02
LOCK WASHER 1/4
Price
N/A
358
*DISCD*SWITCH PLATE
Item is no longer available
Price
N/A
359
*DISCD*PIVOT PIN
Item is no longer available
Price
N/A
360
CAP SCREW M8-1.25 X 30
Price
N/A
361
Now: PLW01
LOCK WASHER 5/16
Price
N/A
362
*DISCD*CYLINDER UPPER BRACKET
363
SET SCREW M6-1 X 10
Price
N/A
370
*DISCD*HYDRAULIC CYLINDER ASSEMBLY
Price
N/A
371
*DISCD*HYDRAULIC CYLINDER ASSEMBLY
Price
N/A
372
*DISCD*HYDRAULIC CYLINDER ASSEMBLY
Price
N/A
373
Now: PB03M
HEX BOLT M8-1.25 X 16
Price
N/A
374
Now: PW07
FLAT WASHER 5/16
Price
N/A
375
*DISCD*HYDRAULIC CYLINDER ASSEMBLY
Price
N/A
375A
*DISCD*HYDRAULIC CYLINDER ASSEMBLY
Item is no longer available
Price
N/A
376
*DISCD*HYDRAULIC CYLINDER ASSEMBLY
Price
N/A
477
READ MANUAL 2W X 3.3H V2.07.05
Price
N/A
478
GRIZZLY INDUSTRIAL 5.63W X 1H
Price
N/A
479
GRIZZLY INDUSTRIAL 9W X 1.6H
Price
N/A
480
*DISCD*MACHINE ID LABEL
Item is no longer available
Price
N/A
482
*DISCD*BLADE SAFETY LABEL
Item is no longer available
Price
N/A
483
Now: G8588
Nameplate - Small
Price
N/A
MANUAL
*DISCD*MANUAL FOR G9744Z 07/06
