Parts for G9970 14" Bandsaw

IMPORTANT

Parts may have multiple versions that have changed over time. This will be indicated by V1, V2, V3, etc. in the parts description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 of a part went into use in January 2017. Please reference the manufacture date on the ID Label for your machine to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

101
Now: PB03
HEX BOLT 5/16-18 X 1
Price
N/A
102
Now: PW07
FLAT WASHER 5/16
Price
N/A
103
*DISCD*SPRING 1.2 X 8.5 X 4 X 13
Item is no longer available
Price
N/A
104
*DISCD*BRACKET 14L
Item is no longer available
Price
N/A
105
*DISCD*BAR SETTING PLATE
Price
N/A
106
Now: PW07
FLAT WASHER 5/16
Price
N/A
107
*DISCD*UPPER WHEEL BASE WASHER
Item is no longer available
Price
N/A
108
*DISCD*BODY
Item is no longer available
Price
N/A
109
*DISCD*UPPER WHEEL BASE NUT
Item is no longer available
Price
N/A
110
*DISCD*SPRING 3.8 X 76 X 18
Item is no longer available
Price
N/A
111
*DISCD*QUICK HANDLE LEVER
Price
N/A
112
ROLL PIN 5 X 26
Price
N/A
113
*DISCD*TENSION BOLT
Item is no longer available
Price
N/A
114
*DISCD*GUIDE ROD 8MM
Item is no longer available
Price
N/A
115
Now: PR39M
EXT RETAINING RING 8MM
Price
N/A
116
*DISCD*UPPER WHEEL BASE
Item is no longer available
Price
N/A
117
*DISCD*UPPER WHEEL SHAFT 14L
Item is no longer available
Price
N/A
118
*DISCD*UPPER WHEEL 14"
Item is no longer available
Price
N/A
119
Now: PR21M
INT RETAINING RING 35MM
Price
N/A
120
BALL BEARING 6202ZZ
Price
N/A
121
Now: PW06
FLAT WASHER 1/4
Price
N/A
122
TIRE RUBBER
Price
N/A
123
Now: D3377
Nameplate - Large
Price
N/A
125
*DISCD*UPPER WHEEL GUARD
Price
N/A
126
*DISCD*HINGE PIN
Price
N/A
127
Now: D2751
Paddle Switch 125V/250V
Price
N/A
127-1
SWITCH PLATE
Price
N/A
127-2
PADDLE SWITCH KEY
Price
N/A
127A
Now: D2751
Paddle Switch 125V/250V
Price
N/A
127B
SWITCH PLATE
Price
N/A
127C
PADDLE SWITCH KEY
Price
N/A
128
Now: PS01
PHLP HD SCR 10-24 X 1/2
Price
N/A
129
*DISCD*TRACKING KNOB 5/16 X 2
Price
N/A
130
Now: PN02
HEX NUT 5/16-18
Price
N/A
131
Now: PN06
HEX NUT 1/2-12
Price
N/A
132
Now: PLW07
LOCK WASHER 1/2
Price
N/A
133
Now: PLW02
LOCK WASHER 1/4
Price
N/A
134
CAP SCREW 1/4-20 X 5/8
Price
N/A
135
BALL BEARING 6004ZZ
Price
N/A
136
Now: PK12M
KEY 5 X 5 X 30
Price
N/A
138
*DISCD*DRIVE WHEEL
Price
N/A
139
Now: PN42
HEX NUT 3/4-10 (LH)
Price
N/A
140
*DISCD*LOWER WHEEL GUARD
Item is no longer available
Price
N/A
141
Now: PB35
HEX BOLT 3/8-16 X 2-1/2
Price
N/A
142
Now: PN08
HEX NUT 3/8-16
Price
N/A
143
Now: PB09
HEX BOLT 5/16-18 X 1/2
Price
N/A
144
Now: PLW01
LOCK WASHER 5/16
Price
N/A
145
ROLL PIN 6 X 16
Price
N/A
146
*DISCD*GUARD LOCKING KNOB
Price
N/A
147
Now: PS19
PHLP HD SCR 1/4-20 X 1
Price
N/A
148
*DISCD*STRAIN RELIEF
Item is no longer available
Price
N/A
149
*DISCD*KNOB
Price
N/A
150
POWER CORD 16G X 3W 73"L
Price
N/A
151
*DISCD*POWER CORD IEC FEMALE
Price
N/A
152
POWER CORD 16G X 3W 73"L
Price
N/A
153
Now: PLW03
LOCK WASHER #10
Price
N/A
155
Now: PB11
HEX BOLT 5/16-18 X 1-1/2
Price
N/A
156
*DISCD*ADJUSTING SCREW
Item is no longer available
Price
N/A
157
Now: PN04
HEX NUT 5/8-11
Price
N/A
158
*DISCD*BEARING HOUSING
Item is no longer available
Price
N/A
159
Now: W1042
2-1/2" Universal Dust Port for Shop-Vac & Sears
Price
N/A
162
Now: PSS11
SET SCREW 1/4-20 X 1/4
Price
N/A
163
*DISCD*IDLER PULLEY
Item is no longer available
Price
N/A
164
Now: PVM29
V-BELT M29 3L290
Price
N/A
201
Now: PCB11
CARRIAGE BOLT 5/16-18 X 1
Price
N/A
202
Now: PW02
FLAT WASHER 3/8
Price
N/A
203
Now: PLN03
LOCK NUT 5/16-18
Price
N/A
206
*DISCD*KNOB 5/16 X 5/8
Price
N/A
207
*DISCD*GUARD
Price
N/A
211
Now: PK34M
KEY 5 X 5 X 20
Price
N/A
213
*DISCD*MOTOR PULLEY
Price
N/A
214
*DISCD*MOTOR 1HP 110V/220V 1-PH
Item is no longer available
Price
N/A
214-1
*DISCD*CAPACITOR
Item is no longer available
Price
N/A
214-2
*DISCD*CENTRIFUGAL SWITCH
Item is no longer available
Price
N/A
215
Now: PLW01
LOCK WASHER 5/16
Price
N/A
222
*DISCD*STAND
Price
N/A
222A
*DISCD*COMPLETE STAND ASSY BOX 2
Item is no longer available
Price
N/A
301
*DISCD*GUIDE BAR
Item is no longer available
Price
N/A
302
Now: PB19
HEX BOLT 1/4-20 X 1/2
Price
N/A
303
Now: PB05
HEX BOLT 1/4-20 X 3/4
Price
N/A
304
*DISCD*BLADE COVER
Price
N/A
305
THUMBSCREW 1/4-20 X 5/8
Price
N/A
306
Now: PW06
FLAT WASHER 1/4
Price
N/A
307
Now: PB19
HEX BOLT 1/4-20 X 1/2
Price
N/A
308
*DISCD*TABLE
Price
N/A
309
*DISCD*TABLE PIN
Price
N/A
310
Now: PB35
HEX BOLT 3/8-16 X 2-1/2
Price
N/A
311
TRUNNION CLAMPSHOE
Price
N/A
312
TRUNNION
Price
N/A
313
THUMBSCREW 1/4-20 X 3/4
Price
N/A
314
Now: PB02
HEX BOLT 1/4-20 X 5/8
Price
N/A
315
Now: PB12
HEX BOLT 5/16-18 X 1-1/4
Price
N/A
316
*DISCD*TABLE BRACKET
Price
N/A
317
*DISCD*TABLE LOCKING KNOB
Item is no longer available
Price
N/A
318
*DISCD*UPPER BRACKET
Item is no longer available
Price
N/A
319
*DISCD*BEARING BRACKET
Price
N/A
320
BALL BEARING 6200-2RS
Price
N/A
321
Now: PR01M
EXT RETAINING RING 10MM
Price
N/A
322
*DISCD*BLADE GUIDE BODY
Price
N/A
323
BLADE GUIDE BLOCK ROUND
Price
N/A
324
ROLL PIN 3 X 10
Price
N/A
325
***USE P1019Z077***
Price
N/A
326
*DISCD*GAUGE
Price
N/A
329
POINTER
Price
N/A
330
Now: PS18
PHLP HD SCR 10-24 X 1/4
Price
N/A
331
*DISCD*BRACKET LOWER
Price
N/A
332
*DISCD*MITER GAUGE
Price
N/A
407
*DISCD*REAR CLAMP KNOB
Item is no longer available
Price
N/A
408
*DISCD*FENCE ROD
Item is no longer available
Price
N/A
409
Now: PB02M
HEX BOLT M6-1 X 12
Price
N/A
410
Now: PW03M
FLAT WASHER 6MM
Price
N/A
411
*DISCD*REAR FENCE BRACKET
Item is no longer available
Price
N/A
412
*DISCD*REAR CLAMP
Item is no longer available
Price
N/A
413
ROLL PIN 5 X 30
Price
N/A
414
*DISCD*FENCE BODY
Item is no longer available
Price
N/A
467
Now: PCB12
CARRIAGE BOLT 3/8-16 X 2
Price
N/A
468
Now: PW02
FLAT WASHER 3/8
Price
N/A
486
SPACER
Price
N/A
487
*DISCD*GUIDE RAIL
Item is no longer available
Price
N/A
488
CAP SCREW M6-1 X 30
Price
N/A
489
*DISCD*GUIDE RAIL CAP
Item is no longer available
Price
N/A
490
*DISCD*FENCE HEADSTOCK
Item is no longer available
Price
N/A
491
*DISCD*FRONT CLAMP KNOB
Item is no longer available
Price
N/A
494
Now: PN08
HEX NUT 3/8-16
Price
N/A
495
*DISCD*DO NOT OPEN COVER LABEL
Item is no longer available
Price
N/A
496
*DISCD*ID/WARNING LABEL
Item is no longer available
Price
N/A
497
SAFETY GLASSES 2W X 3.3H V2.04.08
Price
N/A
498
ELECTRICITY 1.4W X 1.2H
Price
N/A
MANUAL
MANUAL FOR G9970 2001
Item is no longer available
Price
N/A
