Parts for G9971 16" Bandsaw

IMPORTANT

Parts may have multiple versions that have changed over time. This will be indicated by V1, V2, V3, etc. in the parts description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 of a part went into use in January 2017. Please reference the manufacture date on the ID Label for your machine to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

101
Now: PB03
HEX BOLT 5/16-18 X 1
Price
N/A
102
Now: PW07
FLAT WASHER 5/16
Price
N/A
103
*DISCD*SPRING
Item is no longer available
Price
N/A
104
*DISCD*BRACKET
Item is no longer available
Price
N/A
105
*DISCD*BAR SETTING PLATE
Price
N/A
106
Now: PW07
FLAT WASHER 5/16
Price
N/A
107
*DISCD*UPPER WHEEL BASE WASHER
Item is no longer available
Price
N/A
108
*DISCD*BODY
Item is no longer available
Price
N/A
109
*DISCD*UPPER WHEEL BASE NUT
Item is no longer available
Price
N/A
110
*DISCD*SPRING
Item is no longer available
Price
N/A
111
*DISCD*QUICK HANDLE LEVER
Item is no longer available
Price
N/A
112
ROLL PIN 5 X 25
Price
N/A
113
*DISCD*TENSION BOLT
Item is no longer available
Price
N/A
114
*DISCD*GUIDE ROD
Item is no longer available
Price
N/A
115
Now: PR39M
EXT RETAINING RING 8MM
Price
N/A
116
*DISCD*UPPER WHEEL BASE
Item is no longer available
Price
N/A
117
*DISCD*UPPER WHEEL SHAFT
Item is no longer available
Price
N/A
118
*DISCD*UPPER WHEEL
Item is no longer available
Price
N/A
119
Now: PR21M
INT RETAINING RING 35MM
Price
N/A
120
Now: P6202
***SEE EXT DESCRIPTION***
Price
N/A
122
*DISCD*RUBBER TIRE
Price
N/A
123
*DISCD*SHOP FOX PLAQUE
Item is no longer available
Price
N/A
125
*DISCD*UPPER WHEEL GUARD
Item is no longer available
Price
N/A
126
*DISCD*HINGE PIN
Item is no longer available
Price
N/A
127
Now: G8988
Safety Paddle Switch
Price
N/A
127-1
SWITCH PLATE
Price
N/A
127-2
Now: G8988
Safety Paddle Switch
Price
N/A
128
Now: PS01
PHLP HD SCR 10-24 X 1/2
Price
N/A
129
*DISCD*TRACKING KNOB
Item is no longer available
Price
N/A
130
Now: PN02
HEX NUT 5/16-18
Price
N/A
131
Now: PN06
HEX NUT 1/2-12
Price
N/A
132
Now: PLW07
LOCK WASHER 1/2
Price
N/A
133
Now: PLW02
LOCK WASHER 1/4
Price
N/A
134
CAP SCREW 1/4-20 X 3/8
Price
N/A
135
Now: P6204
***SEE EXT DESCRIPTION***
Price
N/A
136
Now: PK12M
KEY 5 X 5 X 30
Price
N/A
137
*DISCD*SHAFT
Item is no longer available
Price
N/A
138
*DISCD*DRIVE WHEEL
Item is no longer available
Price
N/A
139
Now: PN03
HEX NUT 3/4-16
Price
N/A
140
*DISCD*LOWER WHEEL GUARD
Item is no longer available
Price
N/A
141
Now: PB35
HEX BOLT 3/8-16 X 2-1/2
Price
N/A
142
Now: PN08
HEX NUT 3/8-16
Price
N/A
143
Now: PB09
HEX BOLT 5/16-18 X 1/2
Price
N/A
144
Now: PLW01
LOCK WASHER 5/16
Price
N/A
145
*DISCD*PIN 6 X 16
Item is no longer available
Price
N/A
146
*DISCD*GUARD LOCKING KNOB
Price
N/A
147
*DISCD*GUARD LOCKING KNOB SCREW
Item is no longer available
Price
N/A
148
*DISCD*STRAIN RELIEF
Item is no longer available
Price
N/A
149
*DISCD*KNOB
Item is no longer available
Price
N/A
150
*DISCD*POWER CORD LONG 110V
Item is no longer available
Price
N/A
151
*DISCD*POWER CORD IEC FEMALE
Price
N/A
152
POWER CORD 16G X 3W 73"L
Price
N/A
153
FENDER WASHER 8MM
Price
N/A
155
Now: PB11
HEX BOLT 5/16-18 X 1-1/2
Price
N/A
156
*DISCD*ADJUSTING SCREW
Item is no longer available
Price
N/A
157
Now: PN04
HEX NUT 5/8-11
Price
N/A
158
*DISCD*BEARING HOUSING
Item is no longer available
Price
N/A
159
Now: W1042
2-1/2" Universal Dust Port for Shop-Vac & Sears
Price
N/A
160
Now: PSS11
SET SCREW 1/4-20 X 1/4
Price
N/A
162
Now: PSS11
SET SCREW 1/4-20 X 1/4
Price
N/A
163
*DISCD*IDLER PULLEY
Price
N/A
164
Now: PVA31
V-BELT A31
Price
N/A
201
Now: PCB11
CARRIAGE BOLT 5/16-18 X 1
Price
N/A
202
Now: PW02
FLAT WASHER 3/8
Price
N/A
203
Now: PLN03
LOCK NUT 5/16-18
Price
N/A
206
*DISCD*KNOB 5/16 X 5/8
Price
N/A
207
*DISCD*GUARD
Item is no longer available
Price
N/A
211
Now: PK34M
KEY 5 X 5 X 20
Price
N/A
212
Now: PSS11
SET SCREW 1/4-20 X 1/4
Price
N/A
213
*DISCD*MOTOR PULLEY
Price
N/A
214
*DISCD*MOTOR 1-1/2HP 110V/220V 1-PH
Item is no longer available
Price
N/A
215
Now: PLW01
LOCK WASHER 5/16
Price
N/A
222
*DISCD*STAND
Item is no longer available
Price
N/A
301
*DISCD*GUIDE BAR
Item is no longer available
Price
N/A
302
Now: PB19
HEX BOLT 1/4-20 X 1/2
Price
N/A
303
Now: PB05
HEX BOLT 1/4-20 X 3/4
Price
N/A
304
*DISCD*BLADE COVER
Price
N/A
305
THUMBSCREW 1/4-20 X 5/8
Price
N/A
306
Now: PW06
FLAT WASHER 1/4
Price
N/A
307
Now: PB51
HEX BOLT 1/4-20 X 3/8
Price
N/A
308
*DISCD*TABLE
Item is no longer available
Price
N/A
309
*DISCD*TABLE PIN
Item is no longer available
Price
N/A
310
Now: PB66
HEX BOLT 3/8-16 X 2-1/4
Price
N/A
311
*DISCD*TRUNNION CLAMP
Item is no longer available
Price
N/A
312
*DISCD*TRUNNION
Price
N/A
313
THUMBSCREW 1/4-20 X 3/4
Price
N/A
314
*DISCD*CPTD HEX SCREW 1/4"-20 X 5/8"
Price
N/A
315
Now: PB12
HEX BOLT 5/16-18 X 1-1/4
Price
N/A
316
*DISCD*TABLE BRACKET
Item is no longer available
Price
N/A
317
*DISCD*TABLE LOCKING KNOB
Item is no longer available
Price
N/A
318
*DISCD*UPPER BRACKET
Price
N/A
319
*DISCD*BEARING BRACKET
Item is no longer available
Price
N/A
320
BALL BEARING 6200-OPEN
Price
N/A
321
Now: PR01M
EXT RETAINING RING 10MM
Price
N/A
322
*DISCD*BLADE GUIDE BODY
Price
N/A
323
*DISCD*GUIDE BLOCK
Price
N/A
324
ROLL PIN 3 X 10
Price
N/A
325
***USE P1019Z077***
Price
N/A
326
SCALE
Price
N/A
329
*DISCD*INDICATOR
Item is no longer available
Price
N/A
330
Now: PS18
PHLP HD SCR 10-24 X 1/4
Price
N/A
331
*DISCD*BRACKET LOWER
Item is no longer available
Price
N/A
332
*DISCD*MITER GAUGE
Item is no longer available
Price
N/A
467
Now: PCB03
CARRIAGE BOLT 3/8-16 X 3/4
Price
N/A
481
SPACER
Price
N/A
486
*DISCD*SLEEVE M6 X 15
Price
N/A
487
*DISCD*GUIDE RAIL
Item is no longer available
Price
N/A
488
CAP SCREW M6-1 X 30
Price
N/A
489
*DISCD*GUIDE RAIL CAP
Item is no longer available
Price
N/A
490
*DISCD*FENCE HEADSTOCK
Item is no longer available
Price
N/A
491
*DISCD*KNOB
Price
N/A
494
Now: PN08
HEX NUT 3/8-16
Price
N/A
495
DO NOT OPEN COVER LABEL
Item is no longer available
Price
N/A
496
MACHINE ID/WARNING LABEL
Item is no longer available
Price
N/A
497
WEAR SAFETY GLASSES LABEL
Item is no longer available
Price
N/A
498
CAUTION ELECTRICITY LABEL
Item is no longer available
Price
N/A
MANUAL
MANUAL FOR G9971 2001
Item is no longer available
Price
N/A
