T34412 Harlingen® CCMT Carbide Inserts for Stainless Steel, 10-Pk.

Specifically designed for demanding turning, facing, and boring of stainless steel with boring bars, these carbide inserts are engineered to deliver robust performance and withstand the challenges of machining tough alloys.

Each insert is engineered with a dual-layer defense of titanium aluminum nitride (TiAlN) and titanium silicon nitride (TiSiN) coatings. This powerful combination delivers a significant boost in overall hardness, alongside exceptional abrasion and heat resistance. That translates directly into a longer cutting lifespan, less downtime, and ultimately, a more productive and cost-effective machining process.

These inserts provide a reliable and cost-effective solution, ensuring performance you can depend on.

FITS:

• H8276 Boring Bars
• H8277 Boring Bars

SPECIFICATIONS:

• Designation: CCMT09T304-NTF
• Manufacturer grade: HP1215
• Insert shape: Diamond (Rhombic)
• Insert angle: 80°
• Clearance angle: 7° Positive
• Tolerance class: M
• Insert size: 9.525mm (3/8") I.C.
• Insert thickness: 3.18mm (1/8")
• Nose radius: 0.4mm
• Chipbreaker: NTF
• Insert material: Carbide
• Insert coating: TiAlN, TiSiN
• Target materials: Stainless steel
• Quantity: 10

Upgrade your machining operations with these CCMT09T304 carbide inserts.
