T34417 Harlingen® CNMG Carbide Inserts for Cast Iron, 10-Pk.

Specifically designed for facing, turning, and contouring lathe tool holders, these carbide inserts offer exceptional cast-iron cutting.

Each insert is enhanced with titanium carbonitride (TiCN) and aluminum oxide (Al2O3) ceramic coatings. These advanced, multi-layer coatings significantly boost overall hardness and provide exceptional abrasion and heat resistance, translating directly to increased productivity and a longer tool lifespan for your operations, especially when machining cast iron.

These inserts provide a reliable and cost-effective solution, ensuring performance you can depend on.

FITS:

• H8283 Lathe Tool Holder
• H8284 Lathe Tool Holder

SPECIFICATIONS:

• Designation: CNMG120408-K-1
• Manufacturer grade: HC3220
• Insert shape: Diamond (Rhombic)
• Insert angle: 80°
• Clearance angle: 0° Negative
• Tolerance class: M
• Insert size: 12.7mm (1/2") I.C.
• Insert thickness: 4.76mm (3/16")
• Nose radius: 0.8mm
• Chipbreaker: K-1
• Insert material: Carbide
• Insert coating: TiCN, Al2O3
• Target materials: Cast iron
• Quantity: 10

Upgrade your machining operations with these CNMG120408 carbide inserts.
