T34431 Harlingen® TNMG160408-NMF Carbide Inserts for Stainless Steel, 10-Pk.

These TNMG triangular carbide inserts are for turning and facing operations on stainless steel, delivering exceptional performance in demanding applications. Their strong, negative geometry makes them highly durable and provides six usable cutting edges per insert (three on each side), maximizing tool life and efficiency. They are perfectly compatible with our T10378 Boring Bar.

Each insert is engineered with a dual-layer defense of titanium aluminum nitride (TiAlN) and titanium silicon nitride (TiSiN) coatings. This powerful combination delivers a significant boost in overall hardness, alongside exceptional abrasion and heat resistance. That translates directly into a longer cutting lifespan, less downtime, and ultimately, a more productive and economical machining process.

These inserts provide a reliable and cost-effective solution, ensuring performance you can depend on.

SPECIFICATIONS:

• Designation: TNMG160408-MAL
• Manufacturer grade: HP1215
• Insert shape: Triangular
• Insert angle: 60°
• Clearance angle: 0° Negative
• Tolerance class: M
• Insert size: 15.875mm (5/8") I.C.
• Insert thickness: 4.76mm (3/16")
• Nose radius: 0.8mm
• Chipbreaker: NMF
• Insert coating: AlTiN
• Target materials: Stainless steel
• Quantity: 10

Upgrade your machining operations with these TNMG160408 carbide inserts.
