T34433 Harlingen® VCGT160404-AK Carbide Inserts for Aluminum, 10-Pk.

These VCGT 35° diamond carbide inserts are specifically engineered for high-performance turning, profiling, and boring of aluminum and other non-ferrous materials. Their ultra-sharp cutting edge and specialized chipbreaker design promote excellent chip flow and prevent built-up edge, resulting in superior surface finishes. Designed with a positive geometry, they are perfectly compatible with our T10453 Profiling Tool Holder.

Being uncoated, these inserts maintain an exceptionally sharp cutting edge critical for preventing material adhesion (built-up edge) and achieving a smooth, mirror-like finish when machining aluminum. This specialized design ensures maximum productivity and extended tool life in non-ferrous applications.

These inserts provide a reliable and cost-effective solution, ensuring performance you can depend on.

SPECIFICATIONS:

• Designation: VCGT160404-AK
• Manufacturer grade: HK434
• Insert shape: Diamond (Rhombic)
• Insert angle: 35°
• Clearance angle: 7° Positive
• Tolerance class: G
• Insert size: 9.525mm (3/8") I.C.
• Insert thickness: 4.76mm (3/16")
• Nose radius: 0.4mm
• Chipbreaker: AK
• Insert material: Carbide
• Insert coating: Uncoated
• Target materials: Aluminum
• Quantity: 10

Upgrade your machining operations with these VCGT160404 carbide inserts.
