South Bend SB1072 25" A2-15 3-Jaw Self-Centering Scroll Chuck

An A2-15 direct mount 25" chuck offering precision, rigidity, and longevity.

Precision engineered for generations to come, the SB1072 25" chuck is the pinnacle of workpiece holding.

This monster chuck fits our entire line of South Bend Big Bore lathes as either an outboard A2-15 spindle chuck, inboard A2-15 spindle chuck, or both!

Its A2-15 direct mount ensures rock-solid stability for even the most demanding applications.

This self-centering scroll chuck offers unparalleled concentricity, superior gripping power, and is made with a cast-iron body and 2-piece, hardened jaws.

This chuck needs to be ordered when you purchase your Big Bore lathe, as it will be installed at the factory.

Made in an ISO 9001 factory

SPECIFICATIONS:

• Chuck diameter: 24.8"
• Spindle bore diameter: 9"
• Spindle taper: MT#7/1/20 OPT
• Spindle type: A2-15
• Maximum speed: 850 RPM
• Jaw type: 2-Piece jaws
• Number of jaws: 3
• Body material: Cast iron

FITS:

• SB1065F
• SB1066F
• SB1067F
• SB1068F
• SB1069F
• SB1070F
• SB1071F

Need help?

South Bend offers U.S.-based customer service and technical support to get your questions answered and help keep your equipment running in top condition. And to ensure your satisfaction, the SB1072 comes with a 1-year warranty.
