Parts for W1688 6" x 80" Edge Sander

IMPORTANT

Parts may have multiple versions that have changed over time. This will be indicated by V1, V2, V3, etc. in the parts description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 of a part went into use in January 2017. Please reference the manufacture date on the ID Label for your machine to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

1
*DISCD*PLATEN COVER
Item is no longer available
Price
N/A
2
PLATEN COVER
3
DRIVER ROLLER
Item is no longer available
Price
N/A
4
Now: PLW06
LOCK WASHER 5/8
Price
N/A
5
BALL BEARING 6204-2RS
Price
N/A
6
ROLLER AXLE
7
Now: PLW06
LOCK WASHER 5/8
Price
N/A
8
AUXILIARY TABLE
9
KNOB BOLT
10
ROLLER SUPPORT BRACKET
11
Now: PW06
FLAT WASHER 1/4
Price
N/A
12
Now: PSS03
SET SCREW 1/4-20 X 3/8
Price
N/A
13
BELT ADJUST SHAFT
Item is no longer available
Price
N/A
14
CAP SCREW 5/16-18 X 1
Price
N/A
15
Now: PB07
HEX BOLT 5/16-18 X 3/4
Price
N/A
16
SLEEVE
17
SPRING 3 X 44
18
TILT KNOB
Price
N/A
19
KNOB
20
COLLAR
20A
ROLLER SUPPORT BRACKET
20B
ROLLER BLOCK BRACKET
21
SWIVEL SADDLE
Item is no longer available
Price
N/A
22
KNOB
23
KNOB
Item is no longer available
Price
N/A
24
Now: PW07
FLAT WASHER 5/16
Price
N/A
25
TRUNNION-LEFT
26
Now: PSS01
SET SCREW 5/16-18 X 1
Price
N/A
27
LEVER SCREW 3/8-16
28
KNOB BOLT 1/4-20 X 1/2
29
Now: PB16
HEX BOLT 3/8-16 X 1-1/2
Price
N/A
30
Now: PLW04
LOCK WASHER 3/8
Price
N/A
31
LEVER BOLT 5/16-18 X 55
32
Now: PS08
PHLP HD SCR 10-24 X 3/4
Price
N/A
33
TILT KNOB
34
MOTOR BRACKET
35
Now: PB12
HEX BOLT 5/16-18 X 1-1/4
Price
N/A
36
Now: PW07
FLAT WASHER 5/16
Price
N/A
37
Now: PLW01
LOCK WASHER 5/16
Price
N/A
38
DUST COLLECTION HOOD
39
BELT TRACKING KNOB LABEL
40
BELT LOCK KNOB LABEL
41
Now: PN13
HEX NUT 1/2-13
Price
N/A
42
POWER CORD 12G X 3W 86"L
Price
N/A
43
BRACKET
Item is no longer available
Price
N/A
44
CAP SCREW 3/8-16 X 1
Price
N/A
45
STAND LOCK BOLT 5/8-11 X 24-1/8
46
MACHINE DATA LABEL
Item is no longer available
Price
N/A
47
PLATEN
48
Now: PB24
HEX BOLT 3/8-16 X 1-1/4
Price
N/A
49
LEFT TRUNNION
49A
RIGHT TRUNNION
50
Now: PN09
HEX NUT 5/8-18
Price
N/A
51
TABLE SUPPORT BRACKET
Item is no longer available
Price
N/A
52
RUBBER IDLER ROLLER
53
BALL BEARING 6205RS
Price
N/A
54
Now: PN04
HEX NUT 5/8-11
Price
N/A
55
Now: PSS17
SET SCREW 5/16-18 X 5/16
Price
N/A
56
AUXILIARY TABLE POST
57
ROLLER BLOCK BRACKET
58
CAP SCREW 3/8-16 X 1-1/2
Price
N/A
59
Now: PSS10
SET SCREW 1/4-20 X 5/8
Price
N/A
60
TABLE ADJ SHAFT
61
SPRING 4 X 78
Item is no longer available
Price
N/A
62
LEVELING ARM SHAFT
Item is no longer available
Price
N/A
63
CONTROL SHAFT
Price
N/A
64
Now: PN22
HEX NUT 1-8
Price
N/A
65
Now: PN08
HEX NUT 3/8-16
Price
N/A
66
Now: PB21
HEX BOLT 3/8-16 X 3/4
Price
N/A
67
LEVER
68
PLATE
69
MITER GAUGE BODY
Item is no longer available
Price
N/A
70
TABLE
Item is no longer available
Price
N/A
71
Now: PB03
HEX BOLT 5/16-18 X 1
Price
N/A
71-1
MOTOR ELECTRICAL BOX COVER
Price
N/A
71-2
MOTOR FAN COVER
Price
N/A
71-3
MOTOR FAN
Price
N/A
72
TRUNNION-RIGHT
73
Now: PB09
HEX BOLT 5/16-18 X 1/2
Price
N/A
74
STAND
Item is no longer available
Price
N/A
75
FEET
76
POINTER
Item is no longer available
Price
N/A
77
MOTOR
77-1
MOTOR ELECTRICAL BOX COVER
77-2
MOTOR FAN COVER
Item is no longer available
Price
N/A
77-3
MOTOR FAN
Item is no longer available
Price
N/A
77-4
CAPACITOR COVER
78
Now: PN02
HEX NUT 5/16-18
Price
N/A
79
Now: D2751
Paddle Switch 125V/250V
Price
N/A
80
Now: PW02
FLAT WASHER 3/8
Price
N/A
81
LEFT BRACKET
82
ANGLE SCALE
Item is no longer available
Price
N/A
84
GRAPHITE PAD 6" X 28-3/4"
85
PLATEN TILT SHOP
Item is no longer available
Price
N/A
86
BACK STOP
87
STAND WASHER 5/8 X 30 X 2.7T
Item is no longer available
Price
N/A
88
SWIVEL COLLAR
Item is no longer available
Price
N/A
89
Now: D3376
SHOP FOX NAMEPLATE-MEDIUM
Price
N/A
90
ABRASIVE BELT
Item is no longer available
Price
N/A
91
Now: PB09
HEX BOLT 5/16-18 X 1/2
Price
N/A
92
Now: PR08M
EXT RETAINING RING 19MM
Price
N/A
93
Now: PS50M
PHLP HD SCR M3-.5 X 12
Price
N/A
94
Now: PSS08
SET SCREW 5/16-18 X 1/2
Price
N/A
95
Now: PFH14
FLAT HD SCR 5/16-18 X 3/4
Price
N/A
96
Now: PSS17
SET SCREW 5/16-18 X 5/16
Price
N/A
97
SLEEVE
98
BRACKET
99
LOCK ROD
100
RIVET
Item is no longer available
Price
N/A
101
UNPLUG POWER LABEL
Item is no longer available
Price
N/A
102
MAIN COVER
103
PLATE
104
SHAFT SLIDE
105
SHAFT
106
TILT PLATE
Item is no longer available
Price
N/A
107
TABLE SUPPORT
108
LEVER SCREW
Item is no longer available
Price
N/A
109
SPRING 2 X 114.5
110
NARROW STRIPE TAPE
111
WIDE STRIPE TAPE
112
SAFETY GLASSES LABEL
Item is no longer available
Price
N/A
113
READ MANUAL LABEL
Item is no longer available
Price
N/A
114
SHOCK HAZARD LABEL
Item is no longer available
Price
N/A
115
Now: PB11
HEX BOLT 5/16-18 X 1-1/2
Price
N/A
116
CARTON FOR W1688
Item is no longer available
Price
N/A
117
STYROFOAM
Item is no longer available
Price
N/A
MANUAL
MANUAL FOR W1688 11/02
PKG1
BOX FOR W1688
Item is no longer available
Price
N/A
