Parts for W1851 2 HP 10" Hybrid Cabinet Table Saw with Extension Table

IMPORTANT

Parts may have multiple versions that have changed over time. This will be indicated by V1, V2, V3, etc. in the parts description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 of a part went into use in January 2017. Please reference the manufacture date on the ID Label for your machine to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

1
*DISCD*EXTENSION WING
5
*DISCD*TABLE INSERT (STANDARD)
8
*DISCD*MAIN TABLE
9V2
*DISCD*MOTOR COVER V2.07.18
11
*DISCD*KNOB M6-1
12
*DISCD*RIVETED NUT M6-1 X 15
23
*DISCD*LEADSCREW BRACKET
30
*DISCD*Strain Relief Type-3 M18-1.5
31
*DISCD*TABLE INSERT (DADO)
34
*DISCD*DUST PORT 4" X 1-1/2"
Item is no longer available
Price
N/A
106
*DISCD*MOTOR 2HP 110V/220V 1-PH
Item is no longer available
Price
N/A
106-1
*DISCD*MOTOR FAN COVER
106-4
*DISCD*S CAP 200-240M 250V 1-1/2 X 2-
Item is no longer available
Price
N/A
106-6
*DISCD*R CAPACITOR 40M 450V 2 X 4
Item is no longer available
Price
N/A
116
*DISCD*MOTOR PULLEY
Item is no longer available
Price
N/A
121
*DISCD*ARBOR LOCK
Item is no longer available
Price
N/A
130
*DISCD*ARBOR
Item is no longer available
Price
N/A
132
*DISCD*FRONT TRUNNION
141
*DISCD*MAIN TRUNNION
144
*DISCD*REAR TRUNNION
147
*DISCD*SPREADER BRACKET
151
*DISCD*SAW BLADE 10" X 40T
153
*DISCD*ARBOR NUT M16-2
155
*DISCD*SPREADER ADJUSTMENT BLOCK
159
*DISCD*SPREADER CLAMPING PLATE
168
*DISCD*DUST COLLECTOR CASE
176
*DISCD*TILT LEADSCREW NUT
179
*DISCD*TILT LEADSCREW
187
*DISCD*HANDWHEL LOCK KNOB M8-1.25 5-LOBE
188
*DISCD*HANDWHEL HANDLE 90L, M10-1.5 X 12
Item is no longer available
Price
N/A
222
Now: D4151
Paddle Switch 120/230V
Price
N/A
224
*DISCD*CIRCUIT BREAKR KUOYUH 88 10A 230V
312A
*DISCD*COMPLETE BLADE GUARD ASSEMBLY
315
*DISCD*SPREADER
Item is no longer available
Price
N/A
326
*DISCD*RIVING KNIFE
Item is no longer available
Price
N/A
337
Now: D3122
Push Stick
Price
N/A
400
*DISCD*MITER GAUGE ASSEMBLY
420A
*DISCD*MITER FENCE WITH FLIP STOP ASSY
502
*DISCD*KNURLED NUT M12-1.75
Item is no longer available
Price
N/A
503
*DISCD*GLIDE SCREW M12-1.75 X 16
Item is no longer available
Price
N/A
520
*DISCD*GLIDE SCREW M12-1.75 X 30
Item is no longer available
Price
N/A
521
*DISCD*FENCE FACE
601
*DISCD*GUIDE-TUBE END CAP 50 X 40MM
602
*DISCD*FENCE GUIDE TUBE
603
*DISCD*FRONT FENCE RAIL
604
*DISCD*FENCE SCALE LABEL
612
*DISCD*REAR FENCE RAIL
Item is no longer available
Price
N/A
620
EXTENSION TABLE
701
MACHINE ID LABEL
Item is no longer available
Price
N/A
702
READ MANUAL 1.5W X 2.5H
Price
N/A
705
DISCONNECT 110V 1.5W X 2.5H
Price
N/A
706
ELECTRICITY 0.7W X 0.6H
Price
N/A
707
DOOR CLOSED BLADE 1.5W X 2.5H
Price
N/A
711
GLASSES/RESPIRATOR 2W X 3.3H
Price
N/A
712
Now: D3377
Nameplate - Large
Price
N/A
BOX3
*DISCD*COMPLETE RAIL ASSY BOX3
MAN
MANUAL W1851 MFD-06.17 - 6.18 V1.07.17
MANV2
MANUAL W1851 MFD-07.18 V2.06.18
Item is no longer available
Price
N/A
