Parts for G0855 8" x 72" Jointer w/ Built-in Mobile Base

IMPORTANT

Parts may have multiple versions that have changed over time. This will be indicated by V1, V2, V3, etc. in the parts description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 of a part went into use in January 2017. Please reference the manufacture date on the ID Label for your machine to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

1
FENCE TILT LOCK LEVER 1/2-12
2
Now: PW28M
FLAT WASHER 13MM
Price
N/A
3
STOP BLOCK
4
FENCE CARRIAGE
5
ROUND FEMALE KNOB
Price
N/A
6
ECCENTRIC SHAFT 3/8-16, 5-1/4L
7
DOWEL PIN 5 X 50
8
CAP SCREW 1/4-20 X 1-1/4
Price
N/A
9
Now: PN05
HEX NUT 1/4-20
Price
N/A
10
SHOULDER BOLT 5/16-18 X 11/16, 3/8 X 1
11
Now: PN50
HEX NUT 1/2-20 THIN
Price
N/A
12
FENCE
13
STUD-SE 1/2-20, 1-3/8, 11/16
14
Now: PN02
HEX NUT 5/16-18
Price
N/A
15
Now: PB12
HEX BOLT 5/16-18 X 1-1/4
Price
N/A
16
FLAT HD CAP SCR 5/16-18 X 1-1/2
17
Now: PWF04
FENDER WASHER 1/2
Price
N/A
18
FENCE LINK
19
T-NUT 1/2-12
20
FENCE BLOCK
21
FENCE SWIVEL BASE
22
SET SCR 3/8-16 X 1-1/2, CONE-PT, SLOTTED
23
STUD-DE 3/8-16 X 3-1/8, 3/8
24
HEX NUT 3/8-16 THIN
25
SAFETY PLATE
26
LOCK NUT 1/2-12
Price
N/A
27
CAMLOCK STUD 1/2-12 X 1-1/2, 3-1/2L
28
CAP SCREW 1/4-20 X 1/2
Price
N/A
29
Now: PW06
FLAT WASHER 1/4
Price
N/A
30
FENCE BASE
31
Now: PW02
FLAT WASHER 3/8
Price
N/A
32
ROLL PIN 4 X 20
Price
N/A
33
KEY 9.5 X 9.5 X 268
34
CAP SCREW 3/8-16 X 1-1/2
Price
N/A
35
BEARING BLOCK
36
BALL BEARING 6204-2NSE
Price
N/A
37
Now: PK12M
KEY 5 X 5 X 30
Price
N/A
38
SET SCREW M6-1 X 8
Price
N/A
39
CUTTERHEAD PULLEY
40
CUTTERHEAD 8" 4-KNIFE
40-2
COMPRESSION SPRING
40-3
FLAT HD CAP SCR M5-.8 X 12
Price
N/A
40-4
Now: H4982
8" x 3/4" x 1/8" HSS Jointer Knives, Set of 4
Price
N/A
40-5
KNIFE GIB
40-6
KNIFE GIB BOLT 1/4-28 X 1/4
41
STUD-DE 3/8-24 X 4-3/4, 1/2
41V2
HEX BOLT 3/8-24 X 4-1/4 V2.01.21
42
Now: PN11
HEX NUT 3/8-24
Price
N/A
42V2
LOCK WASHER 9MM V2.01.21
43
BELT COVER
44
KNOB 5/16-18, D1-3/4, ROUND
45
CUTTERHEAD GUARD
45V2
CUTTERHEAD GUARD V2.07.19
46
STANDOFF-HEX MM 5/16-18 X 3/8, 3
47
Now: PSS06
SET SCREW 1/4-20 X 3/4
Price
N/A
48
Now: PN05
HEX NUT 1/4-20
Price
N/A
49
DEPTH STOP BLOCK
50
SHAFT W/HOLE 2-3/4L
51
ROLL PIN 3 X 20
Price
N/A
52
COMPRESSION SPRING
53
SPRING SLEEVE
54
CAP SCREW 3/8-16 X 1-1/4
Price
N/A
55
CAP SCREW 5/16-18 X 3/4
Price
N/A
56
ADJUSTABLE HANDLE 2L, 1/4-20 X 1
57
KNOB 1/4-20, D7/8, BALL
58
SET SCR 5/16-18 X 3/4, 1-5/16, SLOTTED
59
FOLDING HANDLE 2-1/4L, 5/16-18 X 1-3/16
60
SCALE POINTER
61
Now: PW05M
FLAT WASHER 4MM
Price
N/A
62
Now: PS23
PHLP HD SCR 8-32 X 1/4
Price
N/A
63
Now: PS04
PHLP HD SCR 1/4-20 X 1/2
Price
N/A
64
Now: PB18
HEX BOLT 3/8-16 X 1
Price
N/A
65
ROLL PIN 4 X 25
Price
N/A
66
Now: PSS08
SET SCREW 5/16-18 X 1/2
Price
N/A
66V2
ADJUSTABLE HANDLE 5/16-18 X 1", 1-1/2"L
Price
N/A
67
RABBETING TABLE
68
BEARING BLOCK PLATE
69
Now: PLW01
LOCK WASHER 5/16
Price
N/A
70
HANDWHEEL W/HANDLE
71
FENDER WASHER 8.5 X 23 X 2MM
72
Now: PS38
PHLP HD SCR 5/16-18 X 1/2
Price
N/A
73
KNOB BOLT 5-LOBE 3/8-16 X 1, D1-3/4
74
LATCH
75
Now: PN08
HEX NUT 3/8-16
Price
N/A
76
DUST PORT 4"
77
Now: PS04
PHLP HD SCR 1/4-20 X 1/2
Price
N/A
78
LOCK WASHER 10MM
Price
N/A
79
STANDOFF HEX 3/8-16 X 3/4, 3-5/16L
80
CABINET STAND
81
REAR ACCESS PANEL
82
COVER PAD
Price
N/A
83
POLY-V BELT 350J-7 35"
84
Now: PW07
FLAT WASHER 5/16
Price
N/A
85
Now: PB07
HEX BOLT 5/16-18 X 3/4
Price
N/A
85V2
Now: PCB05
CARRIAGE BOLT 5/16-18 X 3/4
Price
N/A
86
MOTOR 3HP 230V 1-PH
86-10
MOTOR FAN COVER
Price
N/A
86-11
MOTOR FAN
Price
N/A
86-12
CONTACT PLATE
86-13
CENTRIFUGAL SWITCH
86-14
S CAPACITOR 400M 125V 1-9/16 X 3-1/2
Price
N/A
86-15
R CAP 70M 250V 1-9/16 X 3-1/2 V2.09.18
Price
N/A
86-16
CAPACITOR COVER (RUN)
Price
N/A
86-17
BALL BEARING 6205ZZ
Price
N/A
86-18
BALL BEARING 6203ZZ
Price
N/A
86-2
Now: PK12M
KEY 5 X 5 X 30
Price
N/A
86-3
MOTOR PULLEY
86-4
SET SCREW M6-1 X 8
Price
N/A
86-5
MOTOR LABEL
86-6
STRAIN RELIEF TYPE-3 PG13.5
86-7
MOTOR CORD 14G 3W 32"
86-8
STRAIN RELIEF TYPE-1 3/4"
86-9
BACKING BOARD
87
WHEEL AXLE 3/8-16 X 1-3/16, 2-1/2L
88
WHEEL
89
Now: PLN01
LOCK NUT 3/8-16
Price
N/A
90
KNOB BOLT 6-LOBE 5/16-18 X 3/4
91
Now: D4159
220V/240V Paddle Switch
Price
N/A
92
CAP SCREW 1/2-12 X 1-3/4
Price
N/A
93
Now: PSS11
SET SCREW 1/4-20 X 1/4
Price
N/A
94
LOCK WASHER 8MM
Price
N/A
95
CAP SCREW M8-1.25 X 70
Price
N/A
96
SWITCH PEDESTAL
97
CAP SCREW M8-1.25 X 20 W/WASHERS
98
Now: PLW04
LOCK WASHER 3/8
Price
N/A
99
Now: PLW07
LOCK WASHER 1/2
Price
N/A
100
Now: PK01M
KEY 5 X 5 X 22
Price
N/A
101
Now: PN02
HEX NUT 5/16-18
Price
N/A
102
TABLE ASSEMBLY
Price
N/A
102A
TABLE ASSEMBLY
103
TABLE ASSEMBLY
Price
N/A
104
TABLE ASSEMBLY
Price
N/A
105
LEADSCREW SUPPORT
106
LEADSCREW BRACKET
107
LEADSCREW
108
LEADSCREW COLLAR
109
TABLE GIB
110
SET SCREW 5/16-18 X 1-1/4 CONE-PT
111
KNIFE-SETTING JIG
112
GUARD PIVOT SHAFT V1
112V2
GUARD PIVOT SHAFT V2.02.19
112V3
GUARD PIVOT SHAFT V3.07.19
113
Now: PR48M
EXT RETAINING RING 11MM
Price
N/A
114
TORSION SPRING
Price
N/A
114V2
TORSION SPRING V2.07.19
115
ROLL PIN 6 X 28
Price
N/A
115V2
ROLL PIN 6 X 25
Price
N/A
115V3
ROLL PIN 6 X 28
Price
N/A
116
ROLL PIN 5 X 28
Price
N/A
116V2
ROLL PIN 5 X 20
Price
N/A
116V3
ROLL PIN 5 X 26
Price
N/A
117
PUSH BLOCKS
118
Now: PW06M
FLAT WASHER 12MM
Price
N/A
119
SWITCH BOX
120
SWITCH PLATE
121
SWITCH CORD 14G 3W 20"
122
POWER CORD 14G 3W 10' 6-20P
123
TAP SCREW M6 X 8
124
ADJUSTABLE FOOT M8-1.25
125
Now: PN03M
HEX NUT M8-1.25
Price
N/A
126
STRAIN RELIEF TYPE-1 5/8"
127
Now: PS18M
PHLP HD SCR M4-.7 X 25
Price
N/A
128
Now: PS17M
PHLP HD SCR M4-.7 X 6
Price
N/A
129
EXT TOOTH WASHER 4MM
Price
N/A
130
HEX WRENCH 3MM
Price
N/A
131
HEX WRENCH 4MM
Price
N/A
132
HEX WRENCH 5MM
Price
N/A
133
WRENCH 8 X 10MM OPEN-ENDS
Price
N/A
134
WRENCH 12 X 14MM OPEN-ENDS
Price
N/A
135
WRENCH 11 X 13MM OPEN-ENDS
Price
N/A
136
HEX WRENCH 6MM
Price
N/A
137
GROUND LABEL
138
BUTTON HD CAP SCR M5-.8 X 8
Price
N/A
139
CUTTERHEAD GUARD WASHER 5.3 X 14 X 1
140
FENDER WASHER 6.7 X 19 X 2MM
141
BUTTON HD CAP SCR M6-1 X 12
Price
N/A
201
MACHINE ID LABEL
202
READ MANUAL 1.5W X 2.5H
Price
N/A
203
CUTTERHEAD WARNING LABEL
204
CUTTERHEAD EXPOSED LABEL
205
ELECTRICITY 0.7W X 0.6H
Price
N/A
206
DISCONNECT 110V 1.5W X 2.5H
Price
N/A
207
CUTTERHEAD GUARD LABEL
208
EYE/EAR/LUNG 1.5W X 2.5H
Price
N/A
209
Now: G8588
Nameplate - Small
Price
N/A
210
MODEL NUMBER LABEL
211
GRIZZLY.COM LABEL
212
PANEL CLOSED WARNING LABEL
213
N/S GRIZZLY GREEN G1023S
Price
N/A
214
GREY PUTTY REF G0504
Price
N/A
BOX2
COMPLETE BOX 2 OF 2 FOR G0855
MAN
MANUAL G0855/G0856 MFD-07.18+ V1.10.18
MANV2
MANUAL G0855/G0856 MFD-02.19-06.19 V2.01
MANV3
MANUAL G0855/G0856 MFD-07.19-12.20 V3.08
MANV4
MANUAL G0855/G0856 MFD-01.21+ V4.04.21
