Parts for G1095 1 HP 4-Speed 4-Roller Power Feeder, Single-Phase

IMPORTANT

Parts may have multiple versions that have changed over time. This will be indicated by V1, V2, V3, etc. in the parts description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 of a part went into use in January 2017. Please reference the manufacture date on the ID Label for your machine to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

1A
SPROCKET CASE KIT RIGHT
1A-1
GREASE NIPPLE M6 X 1.0
Price
N/A
1A-2
SPROCKET CASE
Price
N/A
1A-3
SPRING 38 X 11.4
1A-4
CASE COVER
2A
SPROCKET CASE KIT LEFT
2A-1
GREASE NIPPLE M6 X 1.0
Price
N/A
2A-2
SPROCKET CASE
2A-3
SPRING 38 X 11.4
2A-4
CASE COVER
3A
ROLLER SUPPORT KIT
3A-1
ROLLER SUPPORTER
3A-2
SPROCKET
3A-3
Now: PW03M
FLAT WASHER 6MM
Price
N/A
3A-4
CAP SCREW M6-1 X 16
Price
N/A
3A-5
LOCK WASHER 8MM
Price
N/A
3A-6
CAP SCREW M8-1.25 X 40
Price
N/A
4A
CHAIN KIT 26S
5A
TUBE KIT
5A-1
TUBE
5A-2
Now: PR17M
EXT RETAINING RING 26MM
Price
N/A
6A
SPROCKET SHAFT KIT
6A-1
SPROCKET SHAFT
6A-2
Now: PR47M
EXT RETAINING RING 13MM
Price
N/A
79A-1
HANDWHEEL
7A
SPROCKET SHAFT KIT
7A-1
SPROCKET SHAFT
7A-2
Now: PW01
FLAT WASHER 1/2
Price
N/A
7A-3
Now: PN09M
HEX NUT M12-1.75
Price
N/A
83A-3
STUD-UDE M12-1.75 X 98 20RH / 25RH
83A-4
HANDLE ASSEMBLY
86A-1
HANDWHEEL
8A
SHAFT KIT
Price
N/A
8A-1
GREASE NIPPLE M6 X 1.0
Price
N/A
8A-2
SHAFT
8A-3
LOCK WASHER 12MM
Price
N/A
8A-4
*DISCD*NUT
Item is no longer available
Price
N/A
95A
BACK COVER
95B
KNOB FOR BACK COVER
100
MOTOR 1HP 220V 1-PH AND FEED ASSY
101
BALL BEARING 6203-2RS
Price
N/A
102
GREASE FITTING M6 - 1 STRAIGHT
Price
N/A
103
SPROCKET CASE
Price
N/A
104
TORSION SPRING 3.8 X 102
Price
N/A
105
***USE P1096109***
Price
N/A
107
SPROCKET CASE
Price
N/A
108
TORSION SPRING 3.8 X 102
Price
N/A
109
CASE COVER
Price
N/A
110
ROLLER SUPPORT
Price
N/A
111
SPROCKET
Price
N/A
112
LOCK WASHER 6MM
Price
N/A
113
CAP SCREW M6-1 X 16
Price
N/A
114
LOCK WASHER 8MM
Price
N/A
116
CHAIN 26S
Price
N/A
117
TUBE 27 X 19 X 103L
Price
N/A
118
Now: PR58M
EXT RETAINING RING 24MM
Price
N/A
119
SPROCKET SHAFT
Price
N/A
120
Now: PR47M
EXT RETAINING RING 13MM
Price
N/A
122
Now: PW01
FLAT WASHER 1/2
Price
N/A
123
Now: PN09M
HEX NUT M12-1.75
Price
N/A
124
GREASE NIPPLE M6 X 1.0
Price
N/A
125
ROLLER SPINDLE
Price
N/A
126
SPROCKET CASE HEX BOLT M12-1.75 X 75L
Price
N/A
127
***USE P4176504***
Price
N/A
128
OIL CAP 16MM
Price
N/A
129
O-RING 14.8 X 2.4 P15
Price
N/A
130
CASTING
Price
N/A
131
BUSHING 29D X 23D
Price
N/A
132
SET SCREW M6-1 X 10
Price
N/A
136
SPROCKET 12T X 3/8"
Price
N/A
137
CHAIN 62S
Price
N/A
138
DOUBLE SPROCKET 12T
Price
N/A
139
CHAIN 40S
Price
N/A
144
***USE P4181501***
Price
N/A
150
WORM GEAR BOX COVER O-RING 101.19 X 3.53
Price
N/A
151
WORM GEAR BOX COVER
Price
N/A
152
OIL SEAL 17 X 32 X 7T
Price
N/A
153
CAP SCREW M5-.8 X 16
Price
N/A
155
Now: PW01
FLAT WASHER 1/2
Price
N/A
156
Now: PN09M
HEX NUT M12-1.75
Price
N/A
157
WORM GEAR SHAFT
Price
N/A
158
KEY 6 X 6 X 18L
Price
N/A
162
GEAR 25T
Price
N/A
163
CAP SCREW M8-1.25 X 40
Price
N/A
164
GEAR 40T
Price
N/A
168
LUBRICATOR
Price
N/A
170
MOTOR 1HP 220V 1-PH AND FEED ASSY
Price
N/A
170-1
SWITCH
Price
N/A
170-2
BOX COVER
Price
N/A
170-3
FAN COVER
Price
N/A
170-4
MOTOR FAN
Price
N/A
170-5
R CAPACITOR 35M 250V 1-1/2 X 2-3/4
Price
N/A
170-5V2
R CAPACITOR 35M 400V 1-1/2 X 2-3/4 V2.12.13
170-6
O-RING
Price
N/A
175
O-RING 27.5 X 2.0 S28
Price
N/A
177
CAP
Price
N/A
179
CAP SCREW M5-.8 X 10
Price
N/A
181
BACK COVER
Price
N/A
187
Now: G4182
Extra Roller for G4181 & G7873
Price
N/A
188
LOCK WASHER 12MM
Price
N/A
189
Now: PR09M
EXT RETAINING RING 20MM
Price
N/A
18A
KNOB 2PC
190
Now: PB09M
HEX BOLT M8-1.25 X 20
Price
N/A
191
LOCK WASHER 8MM
Price
N/A
192
GREASE FITTING M6 - 1 STRAIGHT
Price
N/A
193
SPROCKET SHAFT (THREADED)
Price
N/A
200
COLUMN BASE
Price
N/A
200A
***USE P1096200A***
202
STUD-DE M12-1.75 X 70 25RH
Price
N/A
202V2
SHOULDER STUD
Price
N/A
203
Now: PW06M
FLAT WASHER 12MM
Price
N/A
204
***USE P4181678-4***
Price
N/A
205
CAP SCREW M5-.8 X 16
Price
N/A
206
VERTICAL COLUMN 60.5 X 44D X 563L V1
Price
N/A
206V2
VERTICAL COLUMN 560MM V2.12.13
Price
N/A
206V3
VERTICAL COLUMN 560MM V3.08.15
Price
N/A
207
GUIDE 450ML
Price
N/A
210
HORIZ TUBE 60 X 44D X 720L V1
Price
N/A
210V2
OVER ARM 720MM V2.12.13
Price
N/A
212
CAP SCREW M5-.8 X 10
Price
N/A
214
ELEVATION BRACKET
Price
N/A
214A
ELEVATION BRACKET ASSEMBLY
Price
N/A
218
ELEVATION SCREW M19-4 X 380
Price
N/A
219
SET SCREW M8-1.25 X 20
Price
N/A
21A
OIL CAP ASSEMBLY
Price
N/A
21A-1
OIL CAP
Price
N/A
21A-2
O-RING 14.8 X 2.4 P15
Price
N/A
220
LOCK WASHER 8MM
Price
N/A
221
COLUMN CAP V1
Price
N/A
221A
COLUMN CAP ASSEMBLY
Price
N/A
221V2
COLUMN CAP V2.08.15
Price
N/A
222
Now: PN03M
HEX NUT M8-1.25
Price
N/A
224
SWIVEL CONE
Price
N/A
224A
SWIVEL CONE ASSEMBLY
Price
N/A
225
***USE P4181699-4***
Price
N/A
226
T-HANDLE W/HOLE FOR PIN
Price
N/A
228
Now: PW04M
FLAT WASHER 10MM
Price
N/A
229
Now: PB22M
HEX BOLT M8-1.25 X 50
Price
N/A
230
INT TOOTH WASHER 12MM
Price
N/A
231
OVER ARM CONE
Price
N/A
231A
OVER ARM CONE ASSEMBLY
Price
N/A
232
HEX BOLT M12-1.75 X 75
233
ROLL PIN 6 X 36
Price
N/A
234
ROLL PIN 6 X 22
Price
N/A
235
LOCK WASHER 12MM
Price
N/A
240
MOTOR CLAMP
Price
N/A
240A
***USE P4181699***
Price
N/A
241
MOTOR CLAMP CONNECTOR
Price
N/A
24A-1
CASTING
Price
N/A
24A-2
BUSHING
Price
N/A
24A-3
SET SCREW M6-1 X 10
Price
N/A
251
HANDLE M10-1.5 X 70
Price
N/A
252
SET SCREW M8-1.25 X 12 CONE-PT
Price
N/A
254
HAND CRANK
Price
N/A
254A
CRANK ASSEMBLY
Price
N/A
255
ROLL PIN 6 X 36
Price
N/A
256
RACK 650MML
Price
N/A
257
Now: PB73M
HEX BOLT M10-1.5 X 50
Price
N/A
259
PINION
Price
N/A
259A
PINION ASSEMBLY
Price
N/A
25A
BACK COVER KIT
Price
N/A
260
HANDWHEEL W/HANDLE V1
Price
N/A
260A
HANDWHEEL ASSEMBLY
Price
N/A
260V2
***USE P1095079A-1***
Price
N/A
261
STRAIN RELIEF TYPE-6 ST
Price
N/A
262
***USE P0826118***
Price
N/A
263
Now: PW01M
FLAT WASHER 8MM
Price
N/A
264
CAP SCREW M8-1.25 X 25
Price
N/A
265
Now: PW14M
FLAT WASHER 14MM
Price
N/A
266
SPEED CHANGE LABEL
27A
TRANSMISSION KIT
Price
N/A
27A-1
KEY 2.5 X 5 X 21MM
27A-2
CHAIN 62S
27A-3
DOUBLE SPROCKET/KEY 12T X 3/8
Price
N/A
27A-4
CHAIN 40S
28A
*DISCD*WORM GEAR SHAFT KIT-50HZ
Item is no longer available
Price
N/A
28A-1
*DISCD*WORM GEAR SHAFT
Item is no longer available
Price
N/A
28A-2
*DISCD*WASHER
Item is no longer available
Price
N/A
28A-3
*DISCD*NUT
Item is no longer available
Price
N/A
31A
WORM GEAR BOX COVER KIT
31A-1
*DISCD*O-RING 101.1 X 3.53 G102
Price
N/A
31A-2
WORM GEAR BOX COVER
Price
N/A
31A-3
OIL SEAL
Price
N/A
31A-4
CAP SCREW M5-.8 X 16
Price
N/A
32A
WORM GEAR SHAFT KIT 60HZ
Price
N/A
32A-1
WORM GEAR
Price
N/A
32A-2
Now: PW01
FLAT WASHER 1/2
Price
N/A
32A-3
Now: PN09M
HEX NUT M12-1.75
Price
N/A
33A-3
O-RING 11.8 X 2.4 P12
Price
N/A
34A
TUBE KIT 38/48
Price
N/A
34A-1
O-RING 27.5 X 2.0 S28
Price
N/A
34A-2
GEAR LEVER SHAFT
Price
N/A
34A-3
CAP SCREW M5-.8 X 12
Price
N/A
35A
GEAR KIT 25T/40T
35A-1
GEAR 25T
Price
N/A
35A-2
GEAR 40T
Price
N/A
36A
O-RING KIT
38A
GREASE GUN
Price
N/A
45A-1
MOTOR 1HP 220V 1-PH AND FEED ASSY
Price
N/A
45A-10
MOTOR 1HP 220V 1-PH AND FEED ASSY
Price
N/A
45A-11
MOTOR 1HP 220V 1-PH AND FEED ASSY
Price
N/A
45A-2
MOTOR 1HP 220V 1-PH AND FEED ASSY
Price
N/A
45A-3
MOTOR 1HP 220V 1-PH AND FEED ASSY
Price
N/A
45A-4
MOTOR 1HP 220V 1-PH AND FEED ASSY
Price
N/A
45A-5
MOTOR 1HP 220V 1-PH AND FEED ASSY
Price
N/A
45A-6
MOTOR 1HP 220V 1-PH AND FEED ASSY
Price
N/A
45A-7
MOTOR 1HP 220V 1-PH AND FEED ASSY
Price
N/A
45A-8
MOTOR 1HP 220V 1-PH AND FEED ASSY
Price
N/A
45A-9
MOTOR 1HP 220V 1-PH AND FEED ASSY
Price
N/A
45A1
MOTOR 1HP 220V 1-PH AND FEED ASSY
Price
N/A
45A3
MOTOR 1HP 220V 1-PH AND FEED ASSY
Price
N/A
46A
COMPLETE SWITCH BOX ASSY
Price
N/A
46A-1
COMPLETE SWITCH BOX ASSY
Price
N/A
46A-2
COMPLETE SWITCH BOX ASSY
Price
N/A
46A-3
COMPLETE SWITCH BOX ASSY
Price
N/A
46A-4
COMPLETE SWITCH BOX ASSY
Price
N/A
46A-5
COMPLETE SWITCH BOX ASSY
Price
N/A
47A
SWITCH KIT
6203
BEARING #6203
Price
N/A
72A
COVER KIT
Price
N/A
72A-1
O-RING 27.5 X 2.0 S28
Price
N/A
72A-2
COVER
Price
N/A
72A-3
CAP SCREW M5-.8 X 10
Price
N/A
76A
VERTICAL COLUMN KIT
76A-1
VERTICAL COLUMN
76A-2
ELEVATING KEY 450 X 8
Price
N/A
76A-3
CAP SCREW M5-.8 X 10
Price
N/A
76A-4
CAP SCREW M5-.8 X 16
Price
N/A
77A
OVER ARM KIT
77A-1
OVER ARM
77A-2
RACK
77A-3
CAP SCREW M5-.8 X 10
Price
N/A
79A
HANDWHEEL ASSEMBLY
Price
N/A
79A-1
HANDWHEEL
79A-2
ROLL PIN 6 X 36
Price
N/A
80A
PINION KIT
80A-1
PINION
Price
N/A
80A-3
SET SCREW M8-1.25 X 20
Price
N/A
80A-4
LOCK WASHER 8MM
Price
N/A
80A-5
Now: PN03M
HEX NUT M8-1.25
Price
N/A
82A
SWIVEL CONE KIT
82A-1
SWIVEL CONE
Price
N/A
82A-2
SHOULDER STUD
82A-3
HANDLE ASSEMBLY
82A-4
ROLL PIN 6 X 22
Price
N/A
83A
MOTOR CLAMP KIT
83A-1
MOTOR CLAMP
Price
N/A
83A-2
Now: PB22M
HEX BOLT M8-1.25 X 50
Price
N/A
83A-4
T-HANDLE W/THREADS
Price
N/A
83H
CRANK HANDLE KIT
83H-1
CRANK HANDLE
83H-2
CRANK HANDLE LOCK PIN
84A
ELEVATING SCREW M19-4 X 380
Price
N/A
85A
COLUMN CAPE KIT
85A-1
COLUMN CAPE
85A-2
COLUMN CAPE KIT
Price
N/A
85A-3
SET SCREW M8-1.25 X 12
Price
N/A
86A
*DISCD*HANDWHEEL KIT
86A-1
*DISCD*ELEVATING HANDWHEEL
86A-2
*DISCD*LOCK PIN
Item is no longer available
Price
N/A
86A-3
*DISCD*ELEVATING HANDWHEEL
Price
N/A
87A
HANDLE M10-P1.5 X 70L
Price
N/A
90A
COLUMN BASE ASSEMBLY
Price
N/A
90A-1
COLUMN BASE
Price
N/A
90A-2
STUD-DE M12-1.75 X 70 25RH
90A-3
Now: PW01
FLAT WASHER 1/2
Price
N/A
90A-4
HANDLE 200MML
Price
N/A
91A
ELEVATING BRACKET ASSEMBLY
Price
N/A
91A-1
ELEVATING BRACKET
91A-2
THREADED ROD M12-1.75 X 70
91A-3
Now: PW01
FLAT WASHER 1/2
Price
N/A
91A-4
T-HANDLE W/THREADS
Price
N/A
92A
OVER ARM CONE KIT
92A-1
OVER ARM CONE
Price
N/A
92A-2
STUD-SE M 16-1.5 X 90 30
Price
N/A
92A-3
T-HANDLE
Price
N/A
92A-4
ROLL PIN 6 X 22
Price
N/A
92A-5
Now: PW04M
FLAT WASHER 10MM
Price
N/A
92A-6
Now: PB73M
HEX BOLT M10-1.5 X 50
Price
N/A
99A-1
PULL HANDLE
Price
N/A
BOX2
COMPLETE STAND ASSY BOX 2
BZZ-6203
BEARING #6203
BZZ6206
BEARING #6206
MAN
MANUAL FOR G1095 & G1096 06/08
Price
N/A
MANUAL
MANUAL FOR G1095 07/08
MANV2
MANUAL G1095-96 MFD-12.13+ V2.05.14
Price
N/A
RO-12
Now: G4182
Extra Roller for G4181 & G7873
Price
N/A
TEMPLATE
MOUNTING TEMPLATE STICKER
Price
N/A
