Parts for G7948 20" Floor Drill Press

IMPORTANT

Parts may have multiple versions that have changed over time. This will be indicated by V1, V2, V3, etc. in the parts description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 of a part went into use in January 2017. Please reference the manufacture date on the ID Label for your machine to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

1
BASE
2
Now: PB35M
HEX BOLT M12-1.75 X 40
Price
N/A
3
***USE P7947003***
4
COLUMN 7-1/4" V2.09.05
Price
N/A
4A
*DISCD*COLUMN W/COLUMN HOLDER
Item is no longer available
Price
N/A
4B
COLUMN HOLDER W/ COLUMN
5
***USE P7947005***
6
HANDLE ARM
6-1
HANDLE
Price
N/A
7
SET SCREW M8-1.25 X 10
Price
N/A
8
SHAFT
Price
N/A
9
Now: PN01M
HEX NUT M6-1
Price
N/A
10
TABLE PIN
Price
N/A
11
Now: PW13M
FLAT WASHER 20MM
Price
N/A
112
DEGREE SCALE
Price
N/A
113
INDICATOR
Price
N/A
114
SET SCREW M8-1.25 X 25
Price
N/A
115
Now: PN03M
HEX NUT M8-1.25
Price
N/A
116
Now: PLW10
LOCK WASHER 3/4
Price
N/A
12
HEX BOLT M20-2.5 X 45
Price
N/A
13
TABLE BOLT M10 X 30
Price
N/A
14
TABLE ARM BRACKET
15
TABLE
16
CLAMP BOLT M12
Price
N/A
17
***USE P7947017***
18
***USE P7947018***
19
RACK RING
Price
N/A
20
ROLL PIN 4 X 20
Price
N/A
21
SET SCREW M6-1 X 10
Price
N/A
22
FEED SHAFT
Price
N/A
23
*DISCD*SCALE RING
Price
N/A
23A
DEPTH STOP GAUGE ASSY V2.10.02
23A-1
*DISCD*HEEL BLOCK
24
***USE PK07M***
25
HANDLE BODY
Price
N/A
26
HANDLE V2.02.99
Price
N/A
26V2
HANDLE V2.02.99
Price
N/A
27
KNOB M12-1.75 V2.02.99
Price
N/A
27V2
KNOB M12-1.75 V2.02.99
Price
N/A
28
FEED SHAFT CONNECTOR
Price
N/A
29
Now: PB01M
HEX BOLT M10-1.5 X 30
Price
N/A
29A
PLASTIC LOCK CAP
Price
N/A
30
SET SCREW M10-1.5 X 10
Price
N/A
31
ROLL PIN 8 X 26
Price
N/A
32
Now: PR06M
EXT RETAINING RING 16MM
Price
N/A
33
SHIFTER BAR
Price
N/A
34
SLIDE BAR BOLT M10-1.5 X 35
Price
N/A
35
Now: PB26M
HEX BOLT M8-1.25 X 30
Price
N/A
36
Now: PW01M
FLAT WASHER 8MM
Price
N/A
37
Now: PN03M
HEX NUT M8-1.25
Price
N/A
38
Now: PN02M
HEX NUT M10-1.5
Price
N/A
39
SET SCREW M10-1.5 X 30
Price
N/A
40
*DISCD*NUT
Price
N/A
41
Now: PN59M
HEX NUT M16-1.5 THIN
Price
N/A
42
SPRING CAP
Price
N/A
43
TORSION SPRING
Price
N/A
44
SPRING COVER
Price
N/A
45
***USE PS57M***
46
***USE P7943097***
47
Now: G8988
Safety Paddle Switch
Price
N/A
47B
*DISCD*SWITCH HOUSING
Price
N/A
47C
SWITCH PLATE
Price
N/A
47D
TAP SCREW M4 X 12
Price
N/A
47E
YELLOW SWITCH KEY
Price
N/A
48
Now: PS09M
PHLP HD SCR M5-.8 X 10
Price
N/A
49
CORD CLAMP
Price
N/A
50
HEAD CASTING
50A
*DISCD*COMPLETE HEADSTOCK ASSY
Item is no longer available
Price
N/A
51
Now: PB03M
HEX BOLT M8-1.25 X 16
Price
N/A
52
SHIFTER
Price
N/A
53
SLIDE BAR LEFT
Price
N/A
54
SLIDE BAR
Price
N/A
55
***USE P7947055***
56
Now: PW06M
FLAT WASHER 12MM
Price
N/A
57
Now: PN09M
HEX NUT M12-1.75
Price
N/A
58
MOTOR 1-1/2HP 120/240V 1PH
58-1
MOTOR FAN
58-2
CAPACITOR COVER
Price
N/A
58-3
S CAPACITOR 400M 250V 1-3/4 X 3-1/2
Price
N/A
58-4
MOTOR JUNCTION BOX
58-5
MOTOR FAN COVER
58-6
CAST IRON END BELL FOR MOTOR
58A
MOTOR FAN
Price
N/A
58B
CAPACITOR COVER
Price
N/A
58C
S CAPACITOR 400M 250V 1-3/4 X 3-1/2
Price
N/A
59
MOTOR PULLEY
Price
N/A
60
Now: PK23M
KEY 5 X 5 X 25
Price
N/A
61
***USE PSS01M***
62
Now: PVA27
V-BELT A27
Price
N/A
63
CENTER SHAFT
Price
N/A
64
***use P6202zz***
65
BALL BEARING 6202ZZ
Price
N/A
66
Now: PR05M
EXT RETAINING RING 15MM
Price
N/A
67
CENTER PULLEY
Price
N/A
68
Now: PW01M
FLAT WASHER 8MM
Price
N/A
69
Now: PS76M
PHLP HD SCR M8-1.25 X 12
Price
N/A
70
Now: PS09M
PHLP HD SCR M5-.8 X 10
Price
N/A
71
Now: PW02M
FLAT WASHER 5MM
Price
N/A
72
KNOB
Price
N/A
73
PULLEY HOUSING 8-3/4 X 30-1/4"
74
Now: PVA33
V-BELT A33
Price
N/A
75
PULLEY NUT
Price
N/A
76
SPINDLE PULLEY V2.02.99
Price
N/A
76V2
SPINDLE PULLEY V2.02.99
Price
N/A
77
INSERT PULLEY V2.02.99
Price
N/A
77V2
INSERT PULLEY V2.02.99
Price
N/A
78
Now: PR64M
INT RETAINING RING 72MM
Price
N/A
79
BALL BEARING 6207ZZ
Price
N/A
80
SPACER
Price
N/A
81
BALL BEARING 6207ZZ
Price
N/A
82
Now: PR12M
EXT RETAINING RING 35MM
Price
N/A
83
SPANNER NUT
Price
N/A
84
TAB WASHER 8107
Price
N/A
85
BALL BEARING 6206ZZ
Price
N/A
86
THRUST WASHER 72MM RUBBER
Price
N/A
87
***USE P7947087***
88
BALL BEARING 6207ZZ
Price
N/A
89
SPINDLE
89A
SPINDLE ASSY
90
*DISCD*ARBOR MT2 - JT3 V1.03.99
Item is no longer available
Price
N/A
90A
DRILL CHUCK ARBOR MT4 X JT3, 170MM L V2.
91
***USE P7947091***
92
***USE P7943092***
92A
***USE P7943092***
93
SWITCH BOX
Price
N/A
93A
*DISCD*
Item is no longer available
Price
N/A
94
LIGHT SOCKET ASSEMBLY
Price
N/A
94A
Now: PS06M
PHLP HD SCR M5-.8 X 20
Price
N/A
95
LIGHT SOCKET ASSEMBLY
Price
N/A
95A
LIGHT SOCKET ASSEMBLY
Price
N/A
96
LIGHT SOCKET ASSEMBLY
Price
N/A
97
HEX WRENCH 3MM
Price
N/A
98
HEX WRENCH 4MM
Price
N/A
98B
YELLOW SWITCH KEY
Price
N/A
99
WEDGE SHIFTER
Price
N/A
100
POWER CORD 16G X 3W 73"L
Price
N/A
100B
***USE P7947100B***
100C
***USE P7947100C***
100V2
POWER CORD 14G 3W 72" 5-20P V3.01.21
Price
N/A
100V3
***USE P7947100V3***
101
Now: G5715
Morse Taper Sleeve - MT4/MT3
Price
N/A
102
***USE G5715***
103
*DISCD*MACHINE ID LABEL V1
103V2
MACHINE ID LABEL CSA V2.09.17
104
MOTOR FAN COVER
Price
N/A
105
***USE P7947105***
105-1
*DISCD*SCALE
Price
N/A
107
GRIZZLY BLACK/AL LABEL
Price
N/A
108
DP LIGHTS LABEL
Price
N/A
109
*DISCD*DRILL PRESS LABEL
Price
N/A
110
***USE P7943116***
111
Now: PR21M
INT RETAINING RING 35MM
Price
N/A
112
DEGREE SCALE
Price
N/A
113
INDICATOR
Price
N/A
114
SET SCREW M10-1.5 X 28
Price
N/A
115
Now: PN02M
HEX NUT M10-1.5
Price
N/A
116
LOCK WASHER 20MM
Price
N/A
117
Now: PN31M
HEX NUT M12-1.5
Price
N/A
118
Now: PS09M
PHLP HD SCR M5-.8 X 10
Price
N/A
119
***USE PW02M***
120
DEPTH STOP BRACKET
121
DEPTH STOP SCALE STUD
122
Now: PN03M
HEX NUT M8-1.25
Price
N/A
123
QUILL CLAMP
124
CAP SCREW M8-1.25 X 20
Price
N/A
125
***USE P7947125***
126
CHUCK GUARD ASSEMBLY
Price
N/A
126-1
Now: PS51M
PHLP HD SCR M4-.7 X 30
Price
N/A
126-2
Now: PN04M
HEX NUT M4-.7
Price
N/A
126-3
TAP SCREW M2.2 X 4.5
Price
N/A
126-4
HEX BOLT M5-.8 X 12
Price
N/A
126-5
Now: PW05M
FLAT WASHER 4MM
Price
N/A
127
TERMINAL BAR
Price
N/A
128
METAL COVER
Price
N/A
129
Now: PS38M
PHLP HD SCR M4-.7 X 10
Price
N/A
131
Now: PN04M
HEX NUT M4-.7
Price
N/A
132
Now: PW05M
FLAT WASHER 4MM
Price
N/A
133
Now: PS52M
PHLP HD SCR M4-.7 X 20
Price
N/A
135
SUPPORT PLATE
Price
N/A
136
THRUST BEARING 51107
Price
N/A
137
HEX WRENCH 5MM
Price
N/A
191
READ-ENTANGLE-EYE LABEL
Price
N/A
193
ELECTRICITY 0.7W X 0.6H
Price
N/A
194
60W LIGHT BULB NOTICE
Price
N/A
195
N/S GRIZZLY GREEN G1023S
Price
N/A
196
SHOCK PINCH WARNING LABEL
Price
N/A
200
HEAD CASTING
201
SCALE RING V2.06.02
MANUAL
MANUAL G7947-48 MFD-01.07-03.18 V1
Price
N/A
MANV2
***USE P7947MANV2***
