Parts for H2936 - 28" x 39" Downdraft Table
If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.
Please note: All parts ship out of our Springfield, Missouri facility.
| Ref # | Part # | Description | Price | Qty | |
|---|---|---|---|---|---|
| 001 | PH2936001 |
MAIN BASE
|
N/A | ||
| 002 | PH2936002 | DUST COLLECTING PLATE 25-3/8 IN | $15.00 | ||
| 003 | PH2936003 | GROMMET 31 X 22MM | $1.00 | ||
| 004 | PH2936004 | CENTER PANEL | $37.50 | ||
| 005 | PH2936005 |
RIGHT PANEL
|
N/A | ||
| 006 | PH2936006 |
LEFT PANEL
|
N/A | ||
| 007 | PH2936007 |
***USE H4938***
Item is no longer available
PH2936007 Replaced By H4938
|
N/A | View Replacement | |
| 008 | PH2936008 |
OUTLET PLATE V1.02.03
|
N/A | ||
| 008V2 | PH2936008V2 | OUTLET PLATE V2.04.09 | $96.50 | ||
| 009 | PH2936009 |
***USE PB19***
Item is no longer available
PH2936009 Replaced By PB19
|
N/A | View Replacement | |
| 010 | PH2936010 |
***USE PCAP04***
Item is no longer available
PH2936010 Replaced By PCAP04
|
N/A | View Replacement | |
| 011 | PH2936011 | FAN HOUSING V1.02.03 | $152.75 | ||
| 011V2 | PH2936011V2 | FAN HOUSING V2.04.09 | $127.25 | ||
| 012 | PH2936012 | *DISCD*METAL IMPELLER 7 X 9.5 V1.02.03 | $179.75 | ||
| 012A | PH2936012A |
***USE PH2936012V2***
Item is no longer available
PH2936012A Replaced By PH2936012V2
|
N/A | View Replacement | |
| 012V2 | PH2936012V2 | PLASTIC IMPELLER 7"T X 9.5"W V2.12.07 | $127.00 | ||
| 013 | PH2936013 |
*DISCD*MOTOR 1/2HP 110V 1-PH V1.02.03
Item is no longer available
|
N/A | ||
| 013V2 | PH2936013V2 |
***USE PH2936013V3***
Item is no longer available
PH2936013V2 Replaced By PH2936013V3
|
N/A | View Replacement | |
| 013V3 | PH2936013V3 | MOTOR 1/2HP 120V 1-PH V3.06.16 | $210.00 | ||
| 014 | PH2936014 | ANTI SHAKING RUBBER | $1.00 | ||
| 015 | PH2936015 |
***USE PW06***
Item is no longer available
PH2936015 Replaced By PW06
|
N/A | View Replacement | |
| 016 | PH2936016 |
***USE PN05***
Item is no longer available
PH2936016 Replaced By PN05
|
N/A | View Replacement | |
| 017 | PH2936017 | HANDLE | $2.25 | ||
| 018 | PH2936018 | DRAWER | $71.25 | ||
| 019 | PH2936019 | FOOT PAD SCREW 3/8-16 X 2 | $1.25 | ||
| 020 | PH2936020 |
***USE PN08***
Item is no longer available
PH2936020 Replaced By PN08
|
N/A | View Replacement | |
| 021 | PH2936021 |
STRAIN RELIEF
|
N/A | ||
| 022 | PH2936022 |
POWER CORD
|
N/A | ||
| 023 | PH2936023 | SWITCH PLATE | $9.75 | ||
| 024 | PH2936024 |
***USE G8988***
Item is no longer available
PH2936024 Replaced By G8988
|
N/A | View Replacement | |
| 025 | PH2936025 | RECEPTACLE 110V | $1.75 | ||
| 026 | PH2936026 |
***USE PS03***
Item is no longer available
PH2936026 Replaced By PS03
|
N/A | View Replacement | |
| 027 | PH2936027 |
***USE PN03***
Item is no longer available
PH2936027 Replaced By PN03
|
N/A | View Replacement | |
| 028 | PH2936028 |
***USE PS03***
Item is no longer available
PH2936028 Replaced By PS03
|
N/A | View Replacement | |
| 029 | PH2936029 |
POWER CORD CONNECTOR W
|
N/A | ||
| 030 | PH2936030 |
POWER CORD CONNECTOR B
|
N/A | ||
| 031 | PH2936031 |
GROUNDING CONNECTOR
|
N/A | ||
| 032 | PH2936032 |
***USE PN02***
Item is no longer available
PH2936032 Replaced By PN02
|
N/A | View Replacement | |
| 033 | PH2936033 | HANGER | $12.00 | ||
| 034 | PH2936034 |
SHORT CONNECTOR
|
N/A | ||
| 035 | PH2936035 | THERMAL RELAY 12A 125V JOEMEX | $7.50 | ||
| 036 | PH2936036 |
***USE PS12***
Item is no longer available
PH2936036 Replaced By PS12
|
N/A | View Replacement | |
| 037 | PH2936037 | HANDLE | $1.50 | ||
| 038 | PH2936038 |
CAPACITOR COVER
|
N/A | ||
| 039 | PH2936039 |
***USE PTLW01***
Item is no longer available
PH2936039 Replaced By PTLW01
|
N/A | View Replacement | |
| 040 | PH2936040 |
***USE H4961***
Item is no longer available
PH2936040 Replaced By H4961
|
N/A | View Replacement | |
| 041 | PH2936041 |
*DISCD*HANDLE
Item is no longer available
|
N/A | ||
| 042 | PH2936042 |
***USE PS12***
Item is no longer available
PH2936042 Replaced By PS12
|
N/A | View Replacement | |
| 043 | PH2936043 | PANEL PIN | $1.00 | ||
| 045 | PH2936045 |
MACHINE ID LABEL V1
|
N/A | ||
| 045V2 | PH2936045V2 | MACHINE ID LABEL CSA V2.02.12 | $9.50 | ||
| 046 | PH2936046 |
***USE G8588***
Item is no longer available
PH2936046 Replaced By G8588
|
N/A | View Replacement | |
| 047 | PH2936047 |
***USE PLABEL-11***
Item is no longer available
PH2936047 Replaced By PLABEL-11
|
N/A | View Replacement | |
| 048 | PH2936048 |
***USE PLABEL-32A***
Item is no longer available
PH2936048 Replaced By PLABEL-32A
|
N/A | View Replacement | |
| 049 | PH2936049 |
***USE PLABEL-12A***
Item is no longer available
PH2936049 Replaced By PLABEL-12A
|
N/A | View Replacement | |
| 050 | PH2936050 |
NO HANDS IN OUTLET
|
N/A | ||
| 051 | PH2936051 |
MAXIMUM AMPS LABEL 5A V1
|
N/A | ||
| 051V2 | PH2936051V2 |
MAXIMUM AMPS LABEL 3.5A V2.02.12
|
N/A | ||
| 052 | PH2936052 |
***USE PLABEL-14***
Item is no longer available
PH2936052 Replaced By PLABEL-14
|
N/A | View Replacement | |
| 053 | PH2936053 | R CAPACITOR 50M 250V | $9.75 | ||
| 054 | PH2936054 |
***USE PPAINT-1***
Item is no longer available
PH2936054 Replaced By PPAINT-1
|
N/A | View Replacement | |
| 055 | PH2936055 |
***USE PPAINT-11***
Item is no longer available
PH2936055 Replaced By PPAINT-11
|
N/A | View Replacement | |
| 056 | PH2936056 | PLASTIC SPACER | $3.00 | ||
| 057 | PH2936057 |
***USE PCAP68M***
Item is no longer available
PH2936057 Replaced By PCAP68M
|
N/A | View Replacement | |
| 058 | PH2936058 |
***USE PB88***
Item is no longer available
PH2936058 Replaced By PB88
|
N/A | View Replacement | |
| 059 | PH2936059 |
INLET COVER
|
N/A | ||
| MAN | PH2936MAN |
***USE PH2935MAN***
Item is no longer available
PH2936MAN Replaced By PH2935MAN
|
N/A | View Replacement | |
| MANV2 | PH2936MANV2 |
***USE PH2935MANV2***
Item is no longer available
PH2936MANV2 Replaced By PH2935MANV2
|
N/A | View Replacement |
