Parts for H6246 Heavy-Duty Meat Saw w/ Sliding Table

IMPORTANT

Parts may have multiple versions that have changed over time. This will be indicated by V1, V2, V3, etc. in the parts description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 of a part went into use in January 2017. Please reference the manufacture date on the ID Label for your machine to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

1
*DISCD*MEAT SAW FRAME
Item is no longer available
Price
N/A
2
*DISCD*MEAT SAW FRAME
Price
N/A
3
*DISCD*MEAT SAW FRAME
Price
N/A
4
*DISCD*UPPER WHEEL
Item is no longer available
Price
N/A
5
***USE P6202-OPEN***
6
***USE PWN02M***
7
***USE PHTEK17M***
8
***USE PR65M***
9
*DISCD*UPPER BALL BEARING SHAFT
10
*DISCD*WHEEL CARRIER BRACKET
Item is no longer available
Price
N/A
11
***USE PS09M***
12
***USE PN32M***
13
*DISCD*TWO HOLE PLATE
Item is no longer available
Price
N/A
14
***USE PS07M***
15
*DISCD*PARALLEL PIN
16
***USE PCB19M***
17
*DISCD*TENSION BRACKET
Item is no longer available
Price
N/A
18
*DISCD*BLADE TENSIONER ROD
Item is no longer available
Price
N/A
19
***USE PN01M***
20
*DISCD*SLOTTED INSERT
21
***USE PLW06M***
22
*DISCD*LOCKET HOUSING
23
*DISCD*NYLON WASHER 20MM
24
*DISCD*HOUSING NUT M22-1.5
25
*DISCD*TONGUE
26
***USE PTLW05M***
27
***USE PB02M***
28
*DISCD*GUIDE SNAP
Item is no longer available
Price
N/A
29
*DISCD*TOP PLUG
Item is no longer available
Price
N/A
30
*DISCD*BLADE TENSIONER
Item is no longer available
Price
N/A
31
***USE PB02M***
32
***USE PW03M***
33
***USE PB119M***
34
***USE PWN01M***
35
***USE PN01M***
36
*DISCD*HAND KNOB M6-1 X 58
37
*DISCD*BLADE GUIDE
Item is no longer available
Price
N/A
38
*DISCD*GUIDE CARRIER EXTRUSION
Item is no longer available
Price
N/A
39
*DISCD*GUIDE CARRIER MOUNT
Item is no longer available
Price
N/A
40
***USE PCB01M***
41
*DISCD*SQUARE HOLE PLATE
Item is no longer available
Price
N/A
42
*DISCD*MOUNT BLADE GUIDE
43
***USE PW01M***
44
***USE PN03M***
45
*DISCD*UPPER GUIDE BODY
Item is no longer available
Price
N/A
46
***USE PCAP04M***
47
*DISCD*UPPER GUIDE SHAFT
Item is no longer available
Price
N/A
48
*DISCD*UPPER GUIDE BODY BEARING SCREW M6
Item is no longer available
Price
N/A
49
BALL BEARING 626ZZ
Price
N/A
50
***USE PW03M***
51
*DISCD*MOUNT SHAFT-1
52
*DISCD*MOUNT SHAFT-2
Item is no longer available
Price
N/A
53
*DISCD*TENSION BRACKET FRAME
Item is no longer available
Price
N/A
54
*DISCD*BOLT GUIDE M6
Item is no longer available
Price
N/A
55
*DISCD*GUIDE SHAFT LOWER
Item is no longer available
Price
N/A
56
*DISCD*BRACKET BLADE GUIDE
Item is no longer available
Price
N/A
57
***USE PS17M***
58
***USE PB83M***
59
***USE PFN02M***
60
*DISCD*TABLE LEFT RAIL
60-1
*DISCD*TABLE SUPPORT LEFT RAIL
61
*DISCD*RAIL RIGHT FOR TABLE
61-1
*DISCD*RAIL RIGHT FOR TABLE SUPPORT
62
***USE PRP75M***
63
*DISCD*BUSHING
64
*DISCD*SHAFT FOR CHOPPER
65
***use P6203z***
66
*DISCD*BRACKET FOR CHOPPER
Item is no longer available
Price
N/A
67
*DISCD*HOUSE PLATE LOWER
68
*DISCD*BLADE COVER
Item is no longer available
Price
N/A
69
***USE PR05M***
70
***USE PR09M***
71
***USE PK34M***
72
***USE PK12M***
73
*DISCD*DRIVE SHAFT
74
*DISCD*DRIVE PULLEY
75
***use P6004z***
76
*DISCD*BALL BEARING MOUNT PLATE
Item is no longer available
Price
N/A
77
***USE PW04M***
78
***USE PFN01M***
79
*DISCD*LOWER WHEEL
80
Now: PB09M
HEX BOLT M8-1.25 X 20
Price
N/A
81
*DISCD*FLANGE
82
*DISCD*ANGLE PLATE
Item is no longer available
Price
N/A
83
*DISCD*SEPARATE PLATE
Item is no longer available
Price
N/A
84
*DISCD*REIN SLEEVE
85
***USE PB03M***
86
***USE PW01M***
87
***USE PB26M***
88
***USE PW01M***
89
***USE PN03M***
90
***USE PLW07M***
91
***USE PVA36***
92
*DISCD*BLADE 1950
Item is no longer available
Price
N/A
93
***USE PCAP58M***
94
*DISCD*STAND ROD 10"
95
*DISCD*SUPPORTER
96
***USE PH5650011***
97
*DISCD*STAND ROD 7"
98
*DISCD*PUSHER
Item is no longer available
Price
N/A
99
*DISCD*FENCE
100
*DISCD*TABLE
100-1
*DISCD*TABLE SUPPORT BRACE
101
***USE PRP73M***
102
***USE PCAP02M***
103
***USE PB83M***
104
*DISCD*GUIDE MOUNT LOWER
Item is no longer available
Price
N/A
105
*DISCD*FLAT PIECE
Item is no longer available
Price
N/A
106
***use G3845***
107
***USE PB28M***
108
*DISCD*CHARGING HOPPER
109
*DISCD*SHAFT-THRUST
109A
*DISCD*PLASTIC BUSHING
Item is no longer available
Price
N/A
109B
*DISCD*PLASTIC BUSHING 19MM
110
*DISCD*SQUARE HEAD SCREW M10 X 27.5
111
*DISCD*REAMER
112
*DISCD*FILTER COVER
113
*DISCD*LOCK COVER
114
*DISCD*PLASTIC HOPPER COVER
Item is no longer available
Price
N/A
115
*DISCD*MEAT PUSH ROD
116
*DISCD*RUBBER TUBE CONNECTOR
117
*DISCD*FRONT PANEL STAND
118
*DISCD*REAL PANEL STAND
119
*DISCD*PANEL STAND LEFT
120
*DISCD*PANEL STAND RIGHT
121
*DISCD*LEG
Item is no longer available
Price
N/A
122
*DISCD*MOTOR MOUNT
123
*DISCD*MOTOR PULLEY
Item is no longer available
Price
N/A
124
RIVET 3.5 X 8MM BLIND, STEEL
Price
N/A
125
*DISCD*MOTOR 3/4HP 110V 1-PH
125-1
*DISCD*CAPACITOR BOX W/COVER
126
*DISCD*CHIP CONTAINER
127
*DISCD*CHIP CONTAINER RAIL-1
Item is no longer available
Price
N/A
128
*DISCD*CHIP CONTAINER RAIL-2
129
*DISCD*SPACER BUSH
Item is no longer available
Price
N/A
130
***USE PW03M***
131
***USE PB47M***
132
***USE PLW03M***
133
***USE PN06M***
134
***USE PN18M***
135
***USE PS25M***
136
***USE PW02M***
137
*DISCD*CLAMP CORD
Item is no longer available
Price
N/A
138
*DISCD*BOX-SWITCH
Item is no longer available
Price
N/A
139
***USE PHTEK1M***
140
***USE PHTEK29M***
141
***USE PS74M***
142
***USE PTLW01M***
143
*DISCD*COVER-SWITCH
Item is no longer available
Price
N/A
144
*DISCD*LOCK SWITCH
145
*DISCD*STRAIN RELIEF M20 TYPE-6 ST
Item is no longer available
Price
N/A
146
*DISCD*CORD W/PLUG
Item is no longer available
Price
N/A
147
*DISCD*RUBBER FOOT SHOE
MANUAL
MANUAL FOR H6246 09/04
P
*DISCD*CARRIAGE BOLT M8-1.25 X 50
