Item: T23043 | Model: W1762
Image for Shop Fox T23043 - 12" 7-1/2" HP Table Saw with Extension Table
SHOP FOX®'s new 12" table saws are loaded with features you'd expect to find only on machines priced much higher. The Model T23043 offers a step up from the T23042 in both power and panel support with a 7-1/2 HP, 3-phase motor, heavy-duty legs and extension table. Includes a quick release riving knife, splitter, blade guard, digital bevel angle readout, rail-mounted switch, precision-ground cast iron table, cast iron trunnions and a 12" blade.
  • Precision-ground cast iron table
  • Cast iron trunnions
  • 3/8" x 3/4" T-slots & miter gauge
  • 4" dust port
  • Power transfer: V-belt
  • Steel cabinet
  • Hinged motor cover
  • Right hand extension table
  • Magnetic switch with thermal overload protection & large off paddle for safety
  • Quick release steel splitter
  • Digital readout for bevel angle
  • Includes 12" blade
  • Motor: 7-1/2 HP, 220V/440V*, 3-phase
  • Amps: 18.8/9.4
  • Blade tilt: Left
  • Table height from floor: 35-3/4"
  • Table size w/ extension: 30-3/4" x 78-3/4"
  • Arbor speed: 3,600 RPM
  • Arbor size: 1"
  • Maximum dado width: 1"
  • Maximum depth of cut @ 90°: 4"
  • Maximum depth of cut @ 45°: 2-3/4"
  • Maximum rip capacity: 52"
  • Approximate shipping weight: 901 lbs.
  • *440V operation requires the purchase of a 440V thermal relay & magnetic contactor
