Item: T20836 | Model: ST1005
Steelex Machines T20836 - Heavy Duty Mortising Machine with Stand
- For anyone that makes traditional mortises, this Mortiser has all the features you'd want and expect. Handwheel table control, quick-clamping vise, cam lever hold downs, big capacities and a powerful 1 HP motor make mortising quick and easy.
- Motor size: 1HP, 110V, single-phase, 13A, 1,750 RPM.
- Max. stock width: 5 5/8"
- Max. stock thickness: 8 5/8"
- Vertical spindle travel: 8 5/8"
- Chisel size range: 1/4"-1"
- Table size: 5 7/8"Wx15 3/4"L
- Table cross travel: 6 3/4"
- Table longitudinal travel: 6 5/8"
- Floor-to-table height: 32 3/4"
- Approx. shipping weight: 249lbs
SPECIFICATIONS:
