Parts for T32838 Bandsaw Sled

IMPORTANT

Parts may have multiple versions that have changed over time. This will be indicated by V1, V2, V3, etc. in the parts description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 of a part went into use in January 2017. Please reference the manufacture date on the ID Label for your machine to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

1
BASE
2
Now: PW02M
FLAT WASHER 5MM
Price
N/A
3
TRACK GUIDE PLATE
4
TRACK
5
POINTER
6
FRONT RAIL
7
BUMPER
8
CAP SCREW M5-.8 X 16
Price
N/A
9
Now: PN06M
HEX NUT M5-.8
Price
N/A
10
REAR RAIL MOUNTING BRACKET
11
FRONT RAIL MOUNTING BRACKET
12
REAR RAIL
13
KNOB BOLT 5/16-18 X 5/8, 12-LOBE, D1-1/2
14
SQUARE NUT 5/16-18
15
HANDLE PIVOT PIN
16
FIXED HANDLE 29 X 77, M8-1.25 X 40
17
LOCKING CAM
18
PRESSURE PLATE
19
BEARING SHAFT (RIGHT)
20
BEARING SHAFT (LEFT)
21
BALL BEARING 6200ZZ
Price
N/A
22
Now: PR01M
EXT RETAINING RING 10MM
Price
N/A
23
Now: PSS11
SET SCREW 1/4-20 X 1/4
Price
N/A
24
Now: PW06
FLAT WASHER 1/4
Price
N/A
25
Now: PB02
HEX BOLT 1/4-20 X 5/8
Price
N/A
26
Now: PN03M
HEX NUT M8-1.25
Price
N/A
27
BUTTON HD CAP SCR M5-.8 X 10
Price
N/A
28
SCALE
29
Now: PB83M
HEX BOLT M6-1 X 16
Price
N/A
30
HEX WRENCH 3MM
Price
N/A
31
HEX WRENCH 4MM
Price
N/A
32
WRENCH 10MM OPEN-END
MAN
MANUAL T32838 MFD-11.21+ V1.11.21
