Parts for W1676 6" Belt / 10" Disc Combo Sander

IMPORTANT

Parts may have multiple versions that have changed over time. This will be indicated by V1, V2, V3, etc. in the parts description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 of a part went into use in January 2017. Please reference the manufacture date on the ID Label for your machine to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

1
DUST COVER
2
Now: PR03M
EXT RETAINING RING 12MM
Price
N/A
2A
Now: PR05M
EXT RETAINING RING 15MM
Price
N/A
3
BALL BEARING 6201-2RS
Price
N/A
3A
BALL BEARING 6002-2RS
Price
N/A
4
DRIVE SHAFT
5
Now: D1256
6" x 48" A/O Sanding Belt 60 Grit, 2 Pk.
Price
N/A
6
Now: PK02M
KEY 5 X 5 X 40
Price
N/A
7
SNAP RING 16MM
8
SANDING BELT FRAME
Price
N/A
8-1
PLATEN ASSEMBLY
9
BACK STOP
Price
N/A
10
Now: PSS02
SET SCREW 5/16-18 X 3/8
Price
N/A
11
DRIVE ROLLER
11-1
DRIVE ROLLER BUSHING
12
Now: PN02
HEX NUT 5/16-18
Price
N/A
13
Now: PW07
FLAT WASHER 5/16
Price
N/A
14
KNOB 5/16-18
Price
N/A
15
BALL BEARING 6003-2RS W/SNAP RING
Price
N/A
16
COMPLETE MITER GAUGE ASSY
18
Now: PCB06
CARRIAGE BOLT 5/16-18 X 1-1/4
Price
N/A
19
PULLEY COVER
20
MITER BAR
20A
STUD 1/4"
21
CAST IRON DISC 10"
23
TABLE
Price
N/A
24
TRUNNION
Price
N/A
25
Now: PW06
FLAT WASHER 1/4
Price
N/A
26
Now: PS04
PHLP HD SCR 1/4-20 X 1/2
Price
N/A
27
Now: PS18
PHLP HD SCR 10-24 X 1/4
Price
N/A
27A
Now: PS06
PHLP HD SCR 10-24 X 3/8
Price
N/A
27B
Now: PW03
FLAT WASHER #10
Price
N/A
28
MITER GAUGE POINTER
Price
N/A
28-1
MITER POINTER
28-2
LOCK BRACKET
28-3
LOCK PIN
28A
MITER POINTER
Price
N/A
28B
LOCK BRACKET
Price
N/A
28C
LOCK PIN
Price
N/A
29
TABLE SUPPORT BRACKET
30
SUPPORT BAR
Price
N/A
32
Now: PB09
HEX BOLT 5/16-18 X 1/2
Price
N/A
33
TABLE MOUNT L & R (2 PC SET)
Price
N/A
34
Now: PVM24
V-BELT M24 3L240
Price
N/A
35
PULLEY
36
MOTOR PULLEY
Price
N/A
37
KNOB 10-24
Price
N/A
40
BRACKET
Price
N/A
41
Now: PB03
HEX BOLT 5/16-18 X 1
Price
N/A
42
Now: PSS03
SET SCREW 1/4-20 X 3/8
Price
N/A
43
MOTOR 1HP
43-1
MOTOR SPECIFICATION LABEL
43-2
S CAPACITOR
44
LOCK KNOB
45
Now: PLW02
LOCK WASHER 1/4
Price
N/A
46
Now: PW03
FLAT WASHER #10
Price
N/A
49
STRAIN RELIEF FITTINGS
51
Now: PN07
HEX NUT 10-24
Price
N/A
52
BASE
Price
N/A
53
PADDLE SWITCH KEY
Price
N/A
53A
Now: D2751
Paddle Switch 125V/250V
Price
N/A
56
Now: PN04
HEX NUT 5/8-11
Price
N/A
57
HEX BOLT 5/8-11 X 9
Price
N/A
58
RUBBER FOOT
Price
N/A
59
IDLER SHAFT V3.08.97
Price
N/A
62A
ROLLER ADJUST BAR
Price
N/A
64
IDLER ROLLER V3.08.97
Price
N/A
66
Now: PLW04
LOCK WASHER 3/8
Price
N/A
69
MITER BODY
69-1
COMPLETE MITER GAUGE
69-2
Now: PS08
PHLP HD SCR 10-24 X 3/4
Price
N/A
69-3
PIN
69A
Now: PS08
PHLP HD SCR 10-24 X 3/4
Price
N/A
69B
PIN
Price
N/A
70
TILT SCALE
Price
N/A
71
POWER CORD
77
HEX WRENCH 4MM
Price
N/A
80
Now: PK23M
KEY 5 X 5 X 25
Price
N/A
81A
ROCKER PLATE
Price
N/A
82A
SHORT LEVER
Price
N/A
83A
ROCKER ARM
Price
N/A
84A
ECCENTRIC
Price
N/A
85A
LONG LEVER
Price
N/A
86A
KNOB 3/8-16
Price
N/A
87A
SPACER
Price
N/A
88A
Now: PB21
HEX BOLT 3/8-16 X 3/4
Price
N/A
89
CAP SCREW 10-24 X 5/8
Price
N/A
90
MOTOR CORD
90A
MOTOR CORD
91
Now: PB16
HEX BOLT 3/8-16 X 1-1/2
Price
N/A
92
Now: PW02
FLAT WASHER 3/8
Price
N/A
93
WASHER PLATE 19 X 88
Price
N/A
94
KNOB 3/8-24
Price
N/A
95
Now: PLW01
LOCK WASHER 5/16
Price
N/A
96
Now: PSS18
SET SCREW 5/16-18 X 3/4
Price
N/A
97
Now: PW07
FLAT WASHER 5/16
Price
N/A
98
Now: PN11
HEX NUT 3/8-24
Price
N/A
99
GRAPHITE PAD 6"W X 17"L
Price
N/A
99-1
PLATTEN ASSY
99A
PLATTEN ASSY
Price
N/A
100
DUST PORT ABS
101
Now: PW02
FLAT WASHER 3/8
Price
N/A
102
BELT DIRECTION ARROW
Price
N/A
103
TABLE TILT POINTER
Price
N/A
104
LOGO
104-1
LOGO SCREW
104A
LOGO SCREW
Price
N/A
105
Now: PN08
HEX NUT 3/8-16
Price
N/A
106
Now: PN07
HEX NUT 10-24
Price
N/A
107
PHLP HD SCR 3/16-24 X 3/8
110
CABINET
110-1
CABINET DOOR
110-2
DOOR LATCH SYSTEM
110-3
SHELF
110-4
CABINET DOOR HINGE PIN
110A
CABINET DOOR
Price
N/A
110B
DOOR LATCH SYSTEM
Price
N/A
110C
SHELF
Price
N/A
111
SWITCH HOUSING
112
READ MANUAL WARNING LABEL
113
MACHINE ID/WARNING
114
IDLER ROLLER GUARD V1.01.02
114A
IDLER ROLLER GUARD V1.01.02
Price
N/A
114A-1
SLEEVE GUARD
115
LOCK KNOB 1/4-20
Price
N/A
118
Now: PS46
PHLP HD SCR 10-24 X 7/16
Price
N/A
119
Now: W1042
2-1/2" Universal Dust Port for Shop-Vac & Sears
Price
N/A
120
WIRE CONNECTOR 1/2"
121
ELECTRICITY WARNING
122
UNPLUG WARNING
123
SAFETY GLASSES WARNING
124
CARTON FOR W1676
125
STYROFOAM
126
HARDWARE BAG
127
LEVER BAG
128
LOCK KNOB
129
Now: PW03
FLAT WASHER #10
Price
N/A
BOX1
BOX 1 FOR W1676
BOX2
COMPLETE STAND ASSEMBLY BOX 2
MAN
MANUAL FOR W1676 11/01
MANUAL
MANUAL FOR W1676 11/01
