Parts for W1857 8" x 72" Dovetail Jointer with Mobile Base

IMPORTANT

Parts may have multiple versions that have changed over time. This will be indicated by V1, V2, V3, etc. in the parts description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 of a part went into use in January 2017. Please reference the manufacture date on the ID Label for your machine to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

1
FENCE TILT LOCK LEVER 1/2-12
Price
N/A
2
Now: PW28M
FLAT WASHER 13MM
Price
N/A
3
STOP BLOCK
Price
N/A
4
FENCE CARRIAGE
Price
N/A
5
ROUND FEMALE KNOB
Price
N/A
6
ECCENTRIC SHAFT 3/8-16, 5-1/4L
Price
N/A
7
DOWEL PIN 5 X 50
Price
N/A
8
CAP SCREW 1/4-20 X 1-1/4
Price
N/A
9
Now: PN05
HEX NUT 1/4-20
Price
N/A
10
SHOULDER BOLT 5/16-18 X 11/16, 3/8 X 1
Price
N/A
11
Now: PN50
HEX NUT 1/2-20 THIN
Price
N/A
12
FENCE
Price
N/A
13
STUD-SE 1/2-20, 1-3/8, 11/16
Price
N/A
14
Now: PN02
HEX NUT 5/16-18
Price
N/A
15
Now: PB12
HEX BOLT 5/16-18 X 1-1/4
Price
N/A
16
FLAT HD CAP SCR 5/16-18 X 1-1/2
Price
N/A
17
Now: PWF04
FENDER WASHER 1/2
Price
N/A
18
FENCE LINK
19
T-NUT 1/2-12
Price
N/A
20
FENCE BLOCK
Price
N/A
21
FENCE SWIVEL BASE
22
SET SCR 3/8-16 X 1-1/2, CONE-PT, SLOTTED
Price
N/A
23
STUD-DE 3/8-16 X 3-1/8, 3/8
Price
N/A
24
HEX NUT 3/8-16 THIN
Price
N/A
25
SAFETY PLATE
Price
N/A
26
Now: PN06
HEX NUT 1/2-12
Price
N/A
27
CAMLOCK STUD 1/2-12 X 1-1/2, 3-1/2L
Price
N/A
28
CAP SCREW 1/4-20 X 1/2
Price
N/A
29
Now: PW06
FLAT WASHER 1/4
Price
N/A
30
FENCE BASE
31
Now: PW02
FLAT WASHER 3/8
Price
N/A
32
ROLL PIN 4 X 20
Price
N/A
33
KEY 9.5 X 9.5 X 268
Price
N/A
34
CAP SCREW 3/8-16 X 1-1/2
Price
N/A
35
BEARING BLOCK
Price
N/A
36
BALL BEARING 6204-2NSE
Price
N/A
37
Now: PK12M
KEY 5 X 5 X 30
Price
N/A
38
SET SCREW M6-1 X 8
Price
N/A
39
CUTTERHEAD PULLEY
Price
N/A
40
CUTTERHEAD 8" 4-KNIFE
Price
N/A
40-2
COMPRESSION SPRING
Price
N/A
40-3
FLAT HD CAP SCR M5-.8 X 12
Price
N/A
40-4
Now: D3634
8" Jointer Knives - Set of 4 for W1741
Price
N/A
40-5
KNIFE GIB
Price
N/A
40-6
KNIFE GIB BOLT 1/4-28 X 1/4
Price
N/A
41
STUD-DE 3/8-24 X 4-3/4, 1/2
Price
N/A
41V2
HEX BOLT 3/8-24 X 4-1/4 V2.01.21
Price
N/A
42
Now: PN11
HEX NUT 3/8-24
Price
N/A
42V2
LOCK WASHER 9MM V2.01.21
Price
N/A
43
BELT COVER
Price
N/A
44
KNOB 5/16-18, D1-3/4, ROUND
Price
N/A
45
*SEE EXTENDED DESCRIPTION*
Item is no longer available
Price
N/A
45V2
CUTTERHEAD GUARD V2.07.19
46
STANDOFF-HEX MM 5/16-18 X 3/8, 3
Price
N/A
47
Now: PSS06
SET SCREW 1/4-20 X 3/4
Price
N/A
48
Now: PN05
HEX NUT 1/4-20
Price
N/A
49
DEPTH STOP BLOCK
Price
N/A
50
SHAFT W/HOLE 2-3/4L
Price
N/A
51
ROLL PIN 3 X 20
Price
N/A
52
COMPRESSION SPRING
Price
N/A
53
SPRING SLEEVE
Price
N/A
54
CAP SCREW 3/8-16 X 1-1/4
Price
N/A
55
CAP SCREW 5/16-18 X 3/4
Price
N/A
56
ADJUSTABLE HANDLE 2L, 1/4-20 X 1
Price
N/A
57
KNOB 1/4-20, D7/8, BALL
Price
N/A
58
SET SCR 5/16-18 X 3/4, 1-5/16, SLOTTED
Price
N/A
59
FOLDING HANDLE 2-1/4L, 5/16-18 X 1-3/16
Price
N/A
60
SCALE POINTER
Price
N/A
61
Now: PW05M
FLAT WASHER 4MM
Price
N/A
62
Now: PS23
PHLP HD SCR 8-32 X 1/4
Price
N/A
63
Now: PS04
PHLP HD SCR 1/4-20 X 1/2
Price
N/A
64
Now: PB18
HEX BOLT 3/8-16 X 1
Price
N/A
65
ROLL PIN 4 X 25
Price
N/A
66
Now: PSS08
SET SCREW 5/16-18 X 1/2
Price
N/A
66V2
***USE P0495X058***
Price
N/A
67
RABBETING TABLE
68
BEARING BLOCK PLATE
Price
N/A
69
Now: PLW01
LOCK WASHER 5/16
Price
N/A
70
HANDWHEEL W/HANDLE
Price
N/A
71
FENDER WASHER 8MM
Price
N/A
72
Now: PS38
PHLP HD SCR 5/16-18 X 1/2
Price
N/A
73
KNOB BOLT 5-LOBE 3/8-16 X 1, D1-3/4
Price
N/A
74
LATCH
Price
N/A
75
Now: PN08
HEX NUT 3/8-16
Price
N/A
76
DUST PORT 4"
Price
N/A
77
Now: PS04
PHLP HD SCR 1/4-20 X 1/2
Price
N/A
78
LOCK WASHER 10MM
Price
N/A
79
STANDOFF HEX 3/8-16 X 3/4, 3-5/16L
Price
N/A
80
CABINET STAND
81
REAR ACCESS PANEL
82
COVER PAD
Price
N/A
83
POLY-V BELT 350J-7 35"
Price
N/A
84
Now: PW07
FLAT WASHER 5/16
Price
N/A
85
Now: PB07
HEX BOLT 5/16-18 X 3/4
Price
N/A
85V2
Now: PCB05
CARRIAGE BOLT 5/16-18 X 3/4
Price
N/A
86
MOTOR 3HP 230V 1-PH
Price
N/A
86-10
MOTOR FAN COVER
Price
N/A
86-11
MOTOR FAN
Price
N/A
86-12
CONTACT PLATE
Price
N/A
86-13
CENTRIFUGAL SWITCH
Price
N/A
86-14
S CAPACITOR 400M 125V 1-9/16 X 3-1/2
Price
N/A
86-15
***USE P1021Z016V2-7V2***
Price
N/A
86-16
CAPACITOR COVER (RUN)
Price
N/A
86-17
BALL BEARING 6205ZZ
Price
N/A
86-18
BALL BEARING 6203ZZ
Price
N/A
86-2
Now: PK12M
KEY 5 X 5 X 30
Price
N/A
86-3
MOTOR PULLEY
Price
N/A
86-3V2
MOTOR PULLEY V2.02.22
86-4
SET SCREW M6-1 X 8
Price
N/A
86-5
MOTOR LABEL
86-6
STRAIN RELIEF TYPE-3 PG13.5
Price
N/A
86-7
MOTOR CORD 14G 3W 32"
Price
N/A
86-8
STRAIN RELIEF TYPE-1 3/4"
Price
N/A
86-9
BACKING BOARD
Price
N/A
87
WHEEL AXLE 3/8-16 X 1-3/16, 2-1/2L
Price
N/A
88
WHEEL
Price
N/A
89
Now: PLN01
LOCK NUT 3/8-16
Price
N/A
90
KNOB BOLT 6-LOBE 5/16-18 X 3/4
Price
N/A
91
***USE D4159***
Price
N/A
92
CAP SCREW 1/2-12 X 1-3/4
Price
N/A
93
Now: PSS11
SET SCREW 1/4-20 X 1/4
Price
N/A
94
LOCK WASHER 8MM
Price
N/A
95
CAP SCREW M8-1.25 X 70
Price
N/A
96
SWITCH PEDESTAL
97
CAP SCREW M8-1.25 X 20 W/WASHERS
Price
N/A
98
Now: PLW04
LOCK WASHER 3/8
Price
N/A
99
Now: PLW07
LOCK WASHER 1/2
Price
N/A
100
Now: PK01M
KEY 5 X 5 X 22
Price
N/A
101
Now: PN02
HEX NUT 5/16-18
Price
N/A
102
TABLE BASE
103
INFEED TABLE
104
OUTFEED TABLE
105
LEADSCREW SUPPORT
Price
N/A
106
LEADSCREW BRACKET
Price
N/A
107
LEADSCREW
Price
N/A
108
LEADSCREW COLLAR
Price
N/A
109
TABLE GIB
Price
N/A
110
SET SCREW 5/16-18 X 1-1/4 CONE-PT
Price
N/A
111
KNIFE-SETTING JIG
Price
N/A
112
GUARD PIVOT SHAFT V1
Price
N/A
112V2
GUARD PIVOT SHAFT V2.02.19
Price
N/A
112V3
GUARD PIVOT SHAFT V3.07.19
Price
N/A
113
Now: PR48M
EXT RETAINING RING 11MM
Price
N/A
114
TORSION SPRING
Price
N/A
114V2
TORSION SPRING V2.07.19
Price
N/A
115
ROLL PIN 6 X 28
Price
N/A
115V2
ROLL PIN 6 X 25
Price
N/A
115V3
ROLL PIN 6 X 28
Price
N/A
116
ROLL PIN 5 X 28
Price
N/A
116V2
ROLL PIN 5 X 20
Price
N/A
116V3
ROLL PIN 5 X 26
Price
N/A
117
Now: W1400
Safety Push Block - Small
Price
N/A
118
Now: PW06M
FLAT WASHER 12MM
Price
N/A
119
SWITCH BOX
Price
N/A
120
SWITCH PLATE
121
SWITCH CORD 14G 3W 20"
Price
N/A
122
POWER CORD 14G 3W 10' 6-20P
Price
N/A
123
TAP SCREW M6 X 8
Price
N/A
124
ADJUSTABLE FOOT M8-1.25
Price
N/A
125
Now: PN03M
HEX NUT M8-1.25
Price
N/A
126
STRAIN RELIEF TYPE-1 5/8"
Price
N/A
127
Now: PS18M
PHLP HD SCR M4-.7 X 25
Price
N/A
128
Now: PS17M
PHLP HD SCR M4-.7 X 6
Price
N/A
129
EXT TOOTH WASHER 4MM
Price
N/A
130
HEX WRENCH 3MM
Price
N/A
131
HEX WRENCH 4MM
Price
N/A
132
HEX WRENCH 5MM
Price
N/A
133
WRENCH 8 X 10MM OPEN-ENDS
Price
N/A
134
WRENCH 12 X 14MM OPEN-ENDS
Price
N/A
135
WRENCH 11 X 13MM OPEN-ENDS
Price
N/A
136
HEX WRENCH 6MM
Price
N/A
137
GROUND LABEL
Price
N/A
138
BUTTON HD CAP SCR M5-.8 X 8
Price
N/A
139
CUTTERHEAD GUARD WASHER 5.3 X 14 X 1
Price
N/A
140
FENDER WASHER 6.7 X 19 X 2MM
Price
N/A
141
BUTTON HD CAP SCR M6-1 X 12
Price
N/A
201
MACHINE ID LABEL
202
READ MANUAL 1.5W X 2.5H
Price
N/A
203
CUTTERHEAD WARNING LABEL
Price
N/A
204
CUTTERHEAD EXPOSED LABEL
Price
N/A
205
ELECTRICITY 1.4W X 1.2H
Price
N/A
206
DISCONNECT 110V 1.5W X 2.5H
Price
N/A
207
CUTTERHEAD GUARD LABEL
Price
N/A
208
EYE/EAR/LUNG 1.5W X 2.5H
Price
N/A
209
MODEL NUMBER LABEL
210
Now: D3377
Nameplate - Large
Price
N/A
211
PANEL CLOSED WARNING LABEL
Price
N/A
212
SHOP FOX WHITE M1006
Price
N/A
213
BLACK TRIM TAPE
214
GLOSSY BLACK
Price
N/A
BOX2
COMPLETE STAND BOX 2
MAN
MANUAL W1857/W1858 MFD-09.18+ V1.10.18
MANV2
MANUAL W1857/W1858 MFD-02.19+ V2.01.19
MANV3
MANUAL W1857/W1858 MFD-07.19+ V3.07.19
MANV4
MANUAL W1857/W1858 MFD-01.21+ V4.05.21
