Parts for W2005 Classic Fence w/ Standard Rails

IMPORTANT

Parts may have multiple versions that have changed over time. This will be indicated by V1, V2, V3, etc. in the parts description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 of a part went into use in January 2017. Please reference the manufacture date on the ID Label for your machine to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

1
FENCE LOCKING TAB
2
KNOB 3/8-16, D1-9/16, TAPERED BALL V2.04.07
Price
N/A
2A
KNOB 3/8-16, D1-9/16, TAPERED BALL V2.04.07
3
BEARING PAD
4
LOCKING LEVER
5
MAGNIFIED CURSOR V2.03.04
Price
N/A
6
COMPLETE FENCE
6A
EXTENSION LEG
8
FENCE BODY
8-1
FENCE FACING
8A
FENCE FACING
Price
N/A
11
SCALE
Price
N/A
12
*DISCD*HAIRLINE INDICATOR V1.01.00
Item is no longer available
Price
N/A
12A
MAGNIFIED CURSOR V2.03.04
13
*DISCD*SPACER
Item is no longer available
Price
N/A
14
ADJUSTABLE FOOT
14-1
SCALE
Price
N/A
14A
SCALE
15A
FRONT RAIL TUBE
16
Now: PB19
HEX BOLT 1/4-20 X 1/2
Price
N/A
16A
FRONT RAIL SUPPORT
17
CAP SCREW 1/4-20 X 1-3/4
Price
N/A
17A
REAR RAIL
18
Now: PB18
HEX BOLT 3/8-16 X 1
Price
N/A
18-1
Now: PB32M
HEX BOLT M10-1.5 X 25
Price
N/A
20
CAP SCREW 3/8-16 X 1-1/2
Price
N/A
21
Now: PS33
PHLP HD SCR 4-40 X 1/4
Price
N/A
22
Now: PS06
PHLP HD SCR 10-24 X 3/8
Price
N/A
23
Now: PSS15
SET SCREW 3/8-16 X 3/8
Price
N/A
26
Now: PFH05
FLAT HD SCR 1/4-20 X 3/4
Price
N/A
27
Now: PLN02
LOCK NUT 1/4-20
Price
N/A
28
Now: PLN01
LOCK NUT 3/8-16
Price
N/A
29
Now: PW16
FLAT WASHER #6
Price
N/A
30
Now: PW03
FLAT WASHER #10
Price
N/A
31
Now: PW06
FLAT WASHER 1/4
Price
N/A
32
Now: PW02
FLAT WASHER 3/8
Price
N/A
33
Now: PW06
FLAT WASHER 1/4
Price
N/A
34
Now: PN07
HEX NUT 10-24
Price
N/A
35
V-CLAMP
36
L-BRACKET
37
LOCKING PLATE
38
Now: PB26
HEX BOLT 1/4-20 X 1-1/2
Price
N/A
39
Now: PW06
FLAT WASHER 1/4
Price
N/A
40
Now: PN05
HEX NUT 1/4-20
Price
N/A
41
Now: PB07
HEX BOLT 5/16-18 X 3/4
Price
N/A
42
Now: PW07
FLAT WASHER 5/16
Price
N/A
43
Now: PN02
HEX NUT 5/16-18
Price
N/A
44
MAGNET
45
Now: PS22
PHLP HD SCR 10-24 X 5/8
Price
N/A
46
DRILL & TAP 3/8-16
47
SHOP FOX LOGO LABEL
48
WARNING LABEL
49
CARTON FOR W2005
50
STYROFOAM 3 PC FOR W2005
BAG1
BLADE GUARD CLAIM HARDWARE BAG
BAG2
RAIL MOUNTING HARDWARE BAG
MAN
MANUAL FOR W2005
