Parts for W2006 - The Classic Fence w/ 7' Rails & Legs

Part Diagram for W2006
Part Diagram for W2006
Part Diagram for W2006
Part Diagram for W2006
Part Diagram for W2006
Part Diagram for W2006

IMPORTANT: Parts may have multiple versions that have changed over time. This will be indicated by V1, V2, V3, etc. in the parts description, followed by the version month and year that it was first used. Example: V2.01.17 indicates version 2 of a part went into use in January 2017. Please reference the manufacture date on the ID Label for your machine to ensure you are selecting the correct part when multiple versions are indicated.

If you cannot locate your part below, please contact our tech support department at techsupport@grizzly.com or 570-546-9663.

Please note: All parts ship out of our Springfield, Missouri facility.

Ref #
Part #
Description
1
FENCE LOCKING TAB
Price
N/A
2
KNOB 3/8-16, D1-9/16, TAPERED BALL V2.04.07
Price
N/A
3
BEARING PAD
Price
N/A
4
LOCKING LEVER
Price
N/A
5
MAGNIFIED CURSOR V2.03.04
Price
N/A
6
EXTENSION LEG
Price
N/A
7
FRONT RAIL TUBE
Price
N/A
8
FENCE BODY
Price
N/A
8A
FENCE FACING
Price
N/A
10
REAR RAIL
Price
N/A
10A
FRONT RAIL SUPPORT
Price
N/A
11
SCALE 53" FOR LONG RAILS
Price
N/A
12
MAGNIFIED CURSOR V2.03.04
Price
N/A
13
*DISCD*SPACER
Price
N/A
14
ADJUSTABLE FOOT
Price
N/A
15A
*DISCD*FRONT RAIL TUBE
Item is no longer available
Price
N/A
16A
*DISCD*FRONT RAIL SUPPORT
Item is no longer available
Price
N/A
17
CAP SCREW 1/4-20 X 1-3/4
Price
N/A
17A
*DISCD*REAR RAIL
Item is no longer available
Price
N/A
18
CAP SCREW 3/8-16 X 1
Price
N/A
19
X2006019
Now: PN06
HEX NUT 1/2-12
Price
N/A
20
CAP SCREW 3/8-16 X 1-1/2
Price
N/A
21
X2006021
Now: PS33
PHLP HD SCR 4-40 X 1/4
Price
N/A
22
X2006022
Now: PS06
PHLP HD SCR 10-24 X 3/8
Price
N/A
23
SET SCREW 3/8-16 X 3/8
Price
N/A
24
X2006024
Now: PN24
HEX NUT 4-40
Price
N/A
26
X2006026
Now: PS08
PHLP HD SCR 10-24 X 3/4
Price
N/A
27
LOCK NUT 1/4-20
Price
N/A
28
LOCK NUT 3/8-16
Price
N/A
29
X2006029
Now: PW16
FLAT WASHER #6
Price
N/A
30
X2006030
Now: PW03
FLAT WASHER #10
Price
N/A
31
X2006031
Now: PW06
FLAT WASHER 1/4
Price
N/A
32
X2006032
Now: PW02
FLAT WASHER 3/8
Price
N/A
33
X2006033
Now: PW03
FLAT WASHER #10
Price
N/A
34
X2006034
Now: PN07
HEX NUT 10-24
Price
N/A
35
X2006035
Now: PB65
HEX BOLT 3/8-16 X 5/8
Price
N/A
36
X2006036
Now: PB21
HEX BOLT 3/8-16 X 3/4
Price
N/A
44
MAGNET
Price
N/A
45
X2006045
Now: PS22
PHLP HD SCR 10-24 X 5/8
Price
N/A
46
X2006046
Now: PW02
FLAT WASHER 3/8
Price
N/A
47
X2006047
Now: PN05
HEX NUT 1/4-20
Price
N/A
48
BRACE
Price
N/A
BOX2
W2006 BX 2 OF 2 RAILS
Price
N/A
MAN
MANUAL FOR W2005
Price
N/A
MANUAL
MANUAL FOR W2005
Price
N/A
PKG1
Price
$38.10
